▶ EngineEngine Manufacturer TYM TYM Engine Model T2300T1-UTC_4 T2300T1-UTR_4 Engine Type 4-cylinder, turbocharged diesel 4-cylinder, turbocharged diesel No. of Cylinders 4 4 Displacement 139.5 in³ 139.5 in³ Rated Engine Speed 2600 rpm 2600 rpm Engine Power (Gross) 58 hp 58 hp PTO Power 48 hp 48 hp Engine Emissions Constraints Tier 4 Tier 4 Cooling System Type Not Published Not Published Air Cleaner Dry element Dry element Fuel System IDI IDI Alternator 70 A, 12 V 70 A, 12 V ▶ HydraulicsPump Type Single gear pump Single gear pump Implement Flow 11.4 gpm 11.4 gpm Steering Flow 5.13 gpm 5.13 gpm Total Hydraulic Flow 16.5 gpm 16.5 gpm Overall Hydraulic Pump Flow 16.5 gpm 16.5 gpm Hydraulic System Type Not Published Not Published Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves Loader: 6; Rear: 6 Loader: 4; Rear: 4 No. of Optional Remote Valves Not Published Not Published ▶ Fluid CapacityFuel Tank Capacity 15.3 gal 15.32 gal Coolant Capacity 6.2 qt 6.2 qt Crankcase Capacity 4.8 qt 4.7 qt Transmission / Hydraulic System Capacity 11.62 gal 11.6 gal Front Axle Fluid Capacity 6.8 qt 6.8 qt ▶ PTO & HitchPTO Type Independent Independent PTO Rear 540 rpm 540 rpm Mid-PTO Availability Not Published Not Published Category, 3-Point Hitch Category II Category II Hitch Lift Capacity 4,409 lb 4,409 lb Hitch Lift Capacity (at 24”) 3,748 lb 3,748 lb Lift Control Type Position and draft control (electronic) Position and draft control (electronic) ▶ Transmission & DrivetrainTransmission Type Power shuttle Power shuttle No. of Speeds F12 x R12 F12 x R12 Max Travel Speed (Forward) 24.04 mph 24.04 mph Max Travel Speed (Reverse) Not Published Not Published Clutch Wet, multi-disc Wet, multi-disc Differential Lock & Limited Slip Options Standard differential lock Standard differential lock ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Hydrostatic Hydrostatic Brakes Wet, multi-disc Wet, multi-disc Seat Suspension & Adjustability Suspension seat Suspension seat Front Axle Type 4WD (selectable 2WD/4WD) 4WD (selectable 2WD/4WD) Front Axle Rating Not Published Not Published Drawbar Capacity Not Published Not Published ▶ Dimensions & ManeuverabilityOverall Width 68.9 in 68.9 in Wheelbase 78.7 in 78.7 in Ground Clearance 18.1 in 18.1 in Min. Turn Radius without Brakes L: 139.7 in; R: 141.9 in L: 139.7 in; R: 141.9 in Height to Top of ROPS Not Published 104.7 in Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model 99.2 in Not Published Overall Length 141.5 in (with 3-point hitch) 141.5 in (with 3-point hitch) ▶ WeightTractor Weight (Base) 4,952 lb (weight with cab) 4,506 lb (weight with ROPS) Weight with ROPS and Loader Not Published 5,806 lb (4,506 + 1,300, computed; L4058P loader total weight) Weight with Cab and Loader 6,252 lb (4,952 + 1,300, computed; L4058PC loader total weight) Not Published ▶ Tire OptionsTire Size & Options R1 Agricultural, R4 Industrial, Golf tires R1 Agricultural, R4 Industrial, Golf tires R1 Agricultural - Front 9.5-20 9.5-20 R1 Agricultural - Rear 14.9-28 14.9-28 R3 Turf - Front 29x12.5-15 (golf tire) 29x12.5-15 (golf tire) R3 Turf - Rear 44x18.00-20 (golf tire) 44x18.00-20 (golf tire) R4 Industrial - Front 10.5/80-18 10.5/80-18 R4 Industrial - Rear 16.9-24 16.9-24 ▶ Loader & AttachmentsQuick Attach Loader System L4058PC: Quick attach mechanism L4058P: Quick attach mechanism Loader Model L4058PC L4058P Loader Lift Height L4058PC: 117.5 in L4058P: 117.5 in Loader Lift Capacity (Full Height) L4058PC: 3,437 lb (at pivot pin) L4058P: 3,437 lb (at pivot pin) Loader Breakout Force L4058PC: 4,742 lb (at pivot pin, ground level) L4058P: 4,742 lb (at pivot pin, ground level) ▶ WarrantyWarranty Length & Coverage Basic 2 years or 2,000 hours; powertrain 3,000 hours maximum, parts and labor; loaders and backhoes 12 months Basic 2 years or 2,000 hours; powertrain 3,000 hours maximum, parts and labor; loaders and backhoes 12 months
