TYM T474 vs Bad Boy Tractors 5055 | Side-by-side comparison | ITC Resource Center
Compare Tractors
See horsepower, lift capacity, hydraulic flow, and the numbers that matter to your work. Up to 4 machines, side by side, in graphs built to show which tractor is better at what.
Up to 2 years or until the 2,000 hours mark, bumper-to-bumper warranty; 3000 hours maximum coverage period for parts and labour on drivetrains or powertrains; 12-months warranty period for implements, including loaders and backhoes.
6-year powertrain warranty
Pump Type
Dual gear pump
Hydrostatic Power Steering
Steering Flow
4.2 gpm
5.0 gpm
Implement Flow
7.7 gpm
5055S: 11.4 gpm; 5055H: 10.7 gpm
Total Hydraulic Flow
11.9 gpm
5055S: 16.4 gpm; 5055H: 15.7 gpm
Hydraulic System Type
Open center
Not Published
Rear Remote Hydraulic Flow
Not Published
Not Published
Overall Hydraulic Pump Flow
11.9 gpm
5055S: 16.4 gpm; 5055H: 15.7 gpm
No. of Optional Remote Valves
Not Published
Up to 2 rear SCVs
No. of Standard Remote Valves
1
Not Published
PTO Rear
540 rpm
540 / 540E rpm
PTO Type
Independent
Independent
Lift Control Type
Position control
Not Published
Hitch Lift Capacity
2,689.6 lb
3,306 lb
Mid-PTO Availability
Available (Mid-PTO kit)
Not Published
Category, 3-Point Hitch
Category I
Category 1
Hitch Lift Capacity (at 24”)
1,764 lb
2,425 lb
R3 Turf - Rear
12.5x20
Not Published
R3 Turf - Front
Multi-Trac CS 27x10.5-15 NHS TL 4PR
Not Published
Tire Size & Options
R1 Agricultural, R3 Turf, R4 Industrial
Not Published
R4 Industrial - Rear
Xtra Grip 43x16.00-20 NHS TL 6PR
Not Published
R4 Industrial - Front
Trac Chief 10-16.50 NHS TL 6PR
Not Published
R1 Agricultural - Rear
Farm Specialist 12.4-24 NHS TL 6PR
Not Published
R1 Agricultural - Front
Farm Specialist 8.0-16 NHS TL 6PR
Not Published
Coolant Capacity
6.9 qt
CABIN: 1.56 gal, ROPS: 2.08 gal
Crankcase Capacity
6.8 qt
1.20 gal
Fuel Tank Capacity
9.0 gal
11.8 gal
Front Axle Fluid Capacity
8.7 qt
1.90 gal
Transmission / Hydraulic System Capacity
8.5 gal
10.04 gal
Loader Lift Height
105.6 in
107.7 in (pivot pin)
Loader Breakout Force
3,198 lb
3,660 lb
Quick Attach Loader System
TX47: Quick attachment (Skid/Euro type)
SSQA
Loader Lift Capacity (Full Height)
2,152 lb
2,701 lb
Clutch
Dry single plate
Not Published
No. of Speeds
F12 x R12
5055S: 16F/16R; 5055H: 4-range
Transmission Type
Mechanical
Synchromesh (Mechanical models) or HST (Hydrostatic models)
