▶ EngineEngine Manufacturer TYM Mahindra Engine Model T2300N2 MDI 2700 R1 Engine Type 4-cylinder, naturally aspirated diesel Four-stroke, direct-injection water-cooled, diesel No. of Cylinders 4 4 Displacement 139.5 in³ 166.7 in³ Rated Engine Speed 2600 rpm 2300 rpm Engine Power (Gross) 48.3 hp 48 hp PTO Power 35.9 hp 38 hp Engine Emissions Constraints Tier 4 Tier 4 Cooling System Type Liquid-cooled Water-cooled Air Cleaner Single dry Dry type with safety cartridge and dust unloader valve Fuel System IDI Direct injection Alternator 70 A, 12 V 45 A, 12 V ▶ HydraulicsPump Type Dual gear pump Not Published Implement Flow 7.7 gpm 8.7 gpm Steering Flow 4.2 gpm 5.0 gpm Total Hydraulic Flow 11.9 gpm Not Published Overall Hydraulic Pump Flow 11.9 gpm Not Published Hydraulic System Type Open center Open center, full-live hydraulic with position and draft controls Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves 1 1 (spool) standard No. of Optional Remote Valves 2 (double rear remote with detent, accessory) Not Published ▶ Fluid CapacityFuel Tank Capacity 9.0 gal 14.55 gal Coolant Capacity 6.9 qt 2.25 gal Crankcase Capacity 6.8 qt 2.14 gal Transmission / Hydraulic System Capacity 8.5 gal 10.57 gal Front Axle Fluid Capacity 8.7 qt 2.24 gal ▶ PTO & HitchPTO Type Independent Live PTO Rear 540 rpm 540 rpm @ 2058 engine rpm Mid-PTO Availability Optional (Mid-PTO kit accessory) Not Published Category, 3-Point Hitch Category I Category I & II adjustable, with telescopic stabilizers Hitch Lift Capacity 2,689.6 lb 3527 lb Hitch Lift Capacity (at 24”) 1,764 lb Not Published Lift Control Type Position control Position & draft control ▶ Transmission & DrivetrainTransmission Type Mechanical synchro shuttle Full constant mesh No. of Speeds 12 forward / 12 reverse 8F / 2R Max Travel Speed (Forward) 14.9 mph 17.6 mph Max Travel Speed (Reverse) Not Published 7.53 mph Clutch Dry single plate Dual Differential Lock & Limited Slip Options Differential lock (pedal) Foot-operated differential lock ▶ Chassis, Steering & ControlsFrame Type Unitized: transmission case, clutch housing, engine and front axle support bolted into a rigid unit Not Published Steering Hydrostatic Hydrostatic power steering Brakes Wet disc Fully enclosed dry disc Seat Suspension & Adjustability Fore and aft sliding seat with cushion strength adjustment mComfort mechanical suspension seat Front Axle Type 4WD center-pivot, reverse Elliott type Not Published Front Axle Rating Not Published Not Published Drawbar Capacity Not Published Not Published ▶ Dimensions & ManeuverabilityOverall Length with 3-Point Hitch 131 in 127.0 in Overall Width 54.5 in 82.6 in Wheelbase 69.7 in 76.7 in Ground Clearance 12.8 in 8.7 in Min. Turn Radius without Brakes 117.5 in 147.63 in Height to Top of ROPS 94.5 in 93.7 in Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model Not Published Not Published ▶ WeightTractor Weight (Base) 3,289 lb 5192 lb Weight with ROPS and Loader 4,310 lb 6746 lb Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options R1 Agricultural, R3 Turf, R4 Industrial R4 Industrial (standard); R1 Agricultural (optional) R1 Agricultural - Front Farm Specialist 8.0-16 NHS TL 6PR (standard); Farm Specialist 7-16 NHS TL 6PR (option) 9.5X16 R1 Agricultural - Rear Farm Specialist 12.4-24 NHS TL 6PR (standard); Farm Specialist 11.2-24 NHS TL 6PR (option) 12.4X28 R3 Turf - Front Multi-Trac CS 27x10.5-15 NHS TL 4PR (standard); Multi-Trac CS 27x8.50-15 NHS TL 4PR (option) Not Published R3 Turf - Rear 12.5x20 (standard); Multi-Trac CS 41x14.00-20 NHS TL 4PR (option) Not Published R4 Industrial - Front Trac Chief 10-16.50 NHS TL 6PR 12.6X16.5 R4 Industrial - Rear Xtra Grip 43x16.00-20 NHS TL 6PR 16.9X24 ▶ Loader & AttachmentsQuick Attach Loader System TX47: skid steer type quick attach (TX47-E: Euro type) Skid-steer style quick-attach coupler Loader Model TX47 4550-4L Loader Lift Height TX47: 105.6 in 4550-4L: 116.6 in Loader Lift Capacity (Full Height) TX47: 2,152 lb 4550-4L: 2,866 lb at pivot pins to full height Loader Breakout Force TX47: 3,198 lb 4550-4L: 4,978 lb at pivot pins ▶ WarrantyWarranty Length & Coverage Bumper-to-bumper 24 months or 2,000 hours (parts and labor); powertrain 72 months or 3,000 hours for non-commercial use (36 months or 2,000 hours rental and commercial); loaders and backhoes 12 months 7-Year Limited Powertrain Warranty ▶ ITC Company AccessoriesAccessories that fit None tagged yet
