▶ EngineEngine Manufacturer TYM Kubota Engine Model T2300N2 V2403-CR-E5 Engine Type 4-cylinder, naturally aspirated diesel Direct injection, vertical, water-cooled 4-cycle, diesel No. of Cylinders 4 4 Displacement 139.5 in³ 148.5 in³ Rated Engine Speed 2600 rpm 2600 rpm Engine Power (Gross) 48.3 hp 48.4 hp PTO Power 35.4 hp 39 hp Engine Emissions Constraints Tier 4 Not Published Cooling System Type Liquid-cooled Water-cooled Air Cleaner Single dry Dry type, primary and secondary element Fuel System IDI Direct injection Alternator 70 A, 12 V 45 A, 12 V ▶ HydraulicsPump Type Dual gear pump Not Published Implement Flow 7.7 gpm 7.8 gpm Steering Flow 4.2 gpm 4.7 gpm Total Hydraulic Flow 11.9 gpm 12.5 gpm (7.8 + 4.7, computed) Overall Hydraulic Pump Flow 11.9 gpm 12.5 gpm (7.8 + 4.7, computed) Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves 1 Not Published No. of Optional Remote Valves Double rear remote with detent (accessory) Optional: double-acting valve, or double-acting valve with float position (float valve as second segment only) ▶ Fluid CapacityFuel Tank Capacity 9.0 gal 13.5 gal Coolant Capacity 6.9 qt 6.9 qt Crankcase Capacity 6.8 qt 8.7 qt Transmission / Hydraulic System Capacity 8.5 gal 10.6 gal Front Axle Fluid Capacity 8.7 qt 6.9 qt ▶ PTO & HitchPTO Type Independent Live independent PTO with hydraulic clutch PTO Rear 540 rpm 540 rpm Mid-PTO Availability Optional (Mid-PTO kit accessory) Not Published Category, 3-Point Hitch Category I SAE Category I Hitch Lift Capacity 2,690 lb 2,870 lb Hitch Lift Capacity (at 24”) 1,764 lb 2,320 lb Lift Control Type Position control Position control ▶ Transmission & DrivetrainTransmission Type Mechanical Hydrostatic transmission (3-range) No. of Speeds 12 forward / 12 reverse 3-range Max Travel Speed (Forward) 14.9 mph 15.8 mph Max Travel Speed (Reverse) Not Published 14.2 mph Clutch Dry single plate Not Applicable Differential Lock & Limited Slip Options Differential lock (pedal) Rear differential lock, pedal operated ▶ Chassis, Steering & ControlsFrame Type Transmission case, clutch, clutch housing, engine and front axle support bolted together to form a rigid unit Not Published Steering Hydrostatic Hydrostatic power steering Brakes Wet disc Mechanical, wet disc type Seat Suspension & Adjustability Fore and aft sliding seat with cushion strength adjustment Suspension seat with fore/aft travel adjustment and suspension tension adjustment Front Axle Type 4WD center-pivot, reverse Elliott type Cast-iron front axle Front Axle Rating Not Published Not Published Drawbar Capacity Not Published 1,430 lb ▶ Dimensions & ManeuverabilityOverall Width 54.5 in 62.2 in Wheelbase 69.7 in 72.6 in Ground Clearance 12.8 in 15.2 in Min. Turn Radius without Brakes 117.5 in 8.5 ft (with brake applied) Height to Top of ROPS Not Published 91.7 in Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model 92.5 in Not Published Overall Length 131 in (with 3-point hitch) 120.3 in (without 3-point hitch) ▶ WeightTractor Weight (Base) 3,607 lb 3,549 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader 4,628 lb (3,607 + 1,021, computed; TX47 loader with bucket) Not Published ▶ Tire OptionsTire Size & Options R1 Agricultural, R3 Turf, R4 Industrial Agricultural; Turf; Industrial (R4) R1 Agricultural - Front Farm Specialist 8.0-16 NHS TL 6PR (standard); Farm Specialist 7-16 NHS TL 6PR (option) 8.3-16 R1 Agricultural - Rear Farm Specialist 12.4-24 NHS TL 6PR (standard); Farm Specialist 11.2-24 NHS TL 6PR (option) 14.9-24 R3 Turf - Front Multi-Trac CS 27x10.5-15 NHS TL 4PR (standard); Multi-Trac CS 27x8.50-15 NHS TL 4PR (option) 27X10.5-15 R3 Turf - Rear 12.5x20 (standard); Multi-Trac CS 41x14.00-20 NHS TL 4PR (option) 44X18-20 R4 Industrial - Front Trac Chief 10-16.50 NHS TL 6PR 10.0-16.5 R4 Industrial - Rear Xtra Grip 43x16.00-20 NHS TL 6PR 17.5L-24 ▶ Loader & AttachmentsQuick Attach Loader System TX47: Quick attach mechanism LA766 2-Lever Quick Coupler Loader Model TX47 LA766 Loader Lift Height TX47: 105.6 in 105.2 in (at pivot pin) Loader Lift Capacity (Full Height) TX47: 2,152 lb (at pivot pin) 1,676 lb (at pivot pin, max. height) Loader Breakout Force TX47: 3,198 lb (at pivot pin, ground level) Not Published ▶ WarrantyWarranty Length & Coverage Basic 24 months or 2,000 hours, parts and labor; non-commercial: powertrain 72 months or 3,000 hours; rental and commercial: powertrain 36 months or 2,000 hours; loaders and backhoes 12 months Basic 24 months or 1,500 hours, powertrain 72 months or 2,000 hours; commercial: powertrain 36 months or 2,000 hours ▶ ITC Company AccessoriesAccessories that fit
