TYM T5068 vs Kubota M6060 | Side-by-side comparison | ITC Resource Center
Compare Tractors
See horsepower, lift capacity, hydraulic flow, and the numbers that matter to your work. Up to 4 machines, side by side, in graphs built to show which tractor is better at what.
Bevel gear type with 55 degree turning angle (4WD)
Front Axle Rating
Not Published
5,290 lb (6,615 lb with loader)
Drawbar Capacity
Not Published
2,200 lb
Overall Width
72.4 in
73.0 in
Wheelbase
84.7 in
83.1 in
Ground Clearance
17.1 in
18.1 in (crop clearance at front axle); 15.4 in (minimum ground clearance)
Min. Turn Radius without Brakes
162.2 in
11.8 ft
Height to Top of ROPS
Not Published
96.9 in
Height to Top of ROPS (folded)
Not Published
Not Published
Height to Top of Cab Model
103 in
n/a (ROPS model)
Overall Length
155.6 in (with 3-point hitch)
138 in
Tractor Weight (Base)
5,556 lb (with cab)
5,005 lb
Weight with ROPS and Loader
Not Published
Not Published
Weight with Cab and Loader
Not Published
Not Published
Tire Size & Options
Not Published
Standard: 9.5-24 front, 16.9-28 rear
R1 Agricultural - Front
9.5R20
9.5-24
R1 Agricultural - Rear
Not Published
16.9-28/14.9-28
R3 Turf - Front
Not Published
LSW305-521
R3 Turf - Rear
Not Published
LSW570-648
R4 Industrial - Front
Not Published
12.5/80-18
R4 Industrial - Rear
18.4-24
16.9-24
Quick Attach Loader System
Not Published
LA1154A: 2-Lever Quick Coupler
Loader Model
L5068SL
LA1154A
Loader Lift Height
L5068SL: 124.8 in
Height position: 132.7 in; Power position: 117.2 in
Loader Lift Capacity (Full Height)
L5068SL: 3,122 lb (at pivot pin)
Height position: 2,469 lb; Power position: 2,928 lb
Loader Breakout Force
L5068SL: 5,225 lb (at pivot pin, ground level)
Height position: 4,230 lbf; Power position: 5,354 lbf
Warranty Length & Coverage
Basic 24 months or 2,000 hours, parts and labor; non-commercial, 20 to 70 engine hp: powertrain 72 months or 3,000 hours; loaders, backhoes and mid-mount mowers 12 months
Basic 24 months or 2,000 hours, powertrain 36 months or 3,000 hours
