▶ EngineEngine Manufacturer Yanmar Kubota Engine Model 4TN98CT-7PKTF V3307-CR-TE4 Engine Type 4-cylinder, water-cooled, turbocharged diesel Liquid-cooled, diesel, 4-cylinder, Turbocharged No. of Cylinders 4 4 Displacement 202.5 in³ 203 in³ Rated Engine Speed 2400 rpm 2400 rpm Engine Power (Gross) 71.5 hp 72.1 hp PTO Power 60.2 hp 62 hp Engine Emissions Constraints Tier 4 Tier 4 Cooling System Type Water-cooled Liquid-cooled Air Cleaner PowerCore Type Dry paper, dual element, 8 in diameter, with pre-cleaner Fuel System CRDI Common Rail System (CRS) Alternator 70 A, 12 V 45 A, 12 V ▶ HydraulicsPump Type Dual gear pump Gear Implement Flow 10.3 gpm 11.0 gpm Steering Flow 5.8 gpm 6.1 gpm Total Hydraulic Flow 16.1 gpm 17.1 gpm Overall Hydraulic Pump Flow 16.1 gpm 17.1 gpm Hydraulic System Type Not Published Open Center Rear Remote Hydraulic Flow Not Published 11.0 gpm No. of Standard Remote Valves Not Published 1 (SCD) No. of Optional Remote Valves Not Published 2nd, 3rd (optional) ▶ Fluid CapacityFuel Tank Capacity 19 gal 18.5 gal Coolant Capacity 3 gal 8.5 qt Crankcase Capacity Not Published 12.7 qt Transmission / Hydraulic System Capacity 13.7 gal 14.8 gal Front Axle Fluid Capacity 2.4 gal 5.8 qt (differential) plus 3.7 qt (each bevel gear case) ▶ PTO & HitchPTO Type Independent Live-independent PTO, electro-hydraulic clutch with brake PTO Rear 540/750 rpm 540 rpm (540/540E optional) Mid-PTO Availability Not Published Not Published Category, 3-Point Hitch Category II I / II Hitch Lift Capacity 4,329 lb 4,189 lb Hitch Lift Capacity (at 24”) 3,159 lb 3,307 lb Lift Control Type Position/Draft Position, Draft (Top Link Sensing) & Mixed Control ▶ Transmission & DrivetrainTransmission Type Power shuttle Hydraulic-shuttle (F8/R8), fully synchronized (4-speed main) No. of Speeds F12 x R12 F8/R8 Max Travel Speed (Forward) 13.5 mph 18.8 mph Max Travel Speed (Reverse) Not Published 18.5 mph Clutch Wet Multi Plate Multiple wet disc Differential Lock & Limited Slip Options Not Published Front: limited slip differential; Rear: mechanical ▶ Chassis, Steering & ControlsFrame Type Not Published Two-post foldable ROPS Steering Hydrostatic Hydrostatic power steering Brakes Wet disc Mechanical wet disc Seat Suspension & Adjustability Adjustable sliding seat with backrest angle and cushion firmness adjustment Suspension seat, adjustable (travel, suspension tension, backrest tilt, armrests); optional air-suspension seat on cab models Front Axle Type Not Published Bevel gear type with 55 degree turning angle (4WD) Front Axle Rating Not Published 5,290 lb (6,615 lb with loader) Drawbar Capacity Not Published 2,200 lb ▶ Dimensions & ManeuverabilityOverall Width 81.4 in 73.0 in Wheelbase 84.6 in 83.1 in Ground Clearance 17.6 in 14.3 in Min. Turn Radius without Brakes 164.2 in; 169.3 in 11.8 ft Height to Top of ROPS 106.8 in 97.2 in Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model Not Published n/a (ROPS model) Overall Length 148.1 in (with 3-point hitch) 138.0 in ▶ WeightTractor Weight (Base) 5,463 lb (with ROPS) 5,027 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options Not Published Standard: 9.5-24 front, 16.9-30 rear R1 Agricultural - Front 11.2-24 9.5-24 R1 Agricultural - Rear 16.9-30 16.9-30 R3 Turf - Front Not Published 9.5-24 or LSW305-521 R3 Turf - Rear Not Published 18.4-26 or LSW570-648 R4 Industrial - Front 15-19.5 14-17.5 R4 Industrial - Rear 18.4-24 16.9-24 ▶ Loader & AttachmentsQuick Attach Loader System Not Published LA1154A: 2-Lever Quick Coupler Loader Model L5074SL LA1154A Loader Lift Height Not Published Height position: 132.7 in; Power position: 117.2 in Loader Lift Capacity (Full Height) Not Published Height position: 2,469 lb; Power position: 2,928 lb Loader Breakout Force Not Published Height position: 4,230 lbf; Power position: 5,354 lbf ▶ WarrantyWarranty Length & Coverage Basic 24 months or 2,000 hours, parts and labor; loaders, backhoes and mid-mount mowers 12 months Basic 24 months or 2,000 hours, powertrain 36 months or 3,000 hours ▶ ITC Company AccessoriesAccessories that fit None tagged yet
