▶ EngineEngine Manufacturer Yanmar TYM Engine Model 4TN98CT-7PKTF T2300T1-UTC_4 Engine Type 4-cylinder, water-cooled, turbocharged diesel 4-cylinder, turbocharged diesel No. of Cylinders 4 4 Displacement 202.5 in³ 139.5 in³ Rated Engine Speed 2400 rpm 2600 rpm Engine Power (Gross) 71.5 hp 58 hp PTO Power 60.2 hp 48 hp Engine Emissions Constraints Tier 4 Tier 4 Cooling System Type Water-cooled Not Published Air Cleaner PowerCore Type Dry element Fuel System CRDI IDI Alternator 70 A, 12 V 70 A, 12 V ▶ HydraulicsPump Type Dual gear pump Single gear pump Implement Flow 10.3 gpm 11.4 gpm Steering Flow 5.8 gpm 5.13 gpm Total Hydraulic Flow 16.1 gpm 16.5 gpm Overall Hydraulic Pump Flow 16.1 gpm 16.5 gpm Hydraulic System Type Not Published Not Published Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves Not Published Loader: 6; Rear: 6 No. of Optional Remote Valves Not Published Not Published ▶ Fluid CapacityFuel Tank Capacity 19 gal 15.3 gal Coolant Capacity 3 gal 6.2 qt Crankcase Capacity Not Published 4.8 qt Transmission / Hydraulic System Capacity 13.7 gal 11.62 gal Front Axle Fluid Capacity 2.4 gal 6.8 qt ▶ PTO & HitchPTO Type Independent Independent PTO Rear 540/750 rpm 540 rpm Mid-PTO Availability Not Published Not Published Category, 3-Point Hitch Category II Category II Hitch Lift Capacity 4,329 lb 4,409 lb Hitch Lift Capacity (at 24”) 3,159 lb 3,748 lb Lift Control Type Position/Draft Position and draft control (electronic) ▶ Transmission & DrivetrainTransmission Type Power shuttle Power shuttle No. of Speeds F12 x R12 F12 x R12 Max Travel Speed (Forward) 13.5 mph 24.04 mph Max Travel Speed (Reverse) Not Published Not Published Clutch Wet Multi Plate Wet, multi-disc Differential Lock & Limited Slip Options Not Published Standard differential lock ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Hydrostatic Hydrostatic Brakes Wet disc Wet, multi-disc Seat Suspension & Adjustability Adjustable sliding seat with backrest angle and cushion firmness adjustment Suspension seat Front Axle Type Not Published 4WD (selectable 2WD/4WD) Front Axle Rating Not Published Not Published Drawbar Capacity Not Published Not Published ▶ Dimensions & ManeuverabilityOverall Width 81.4 in 68.9 in Wheelbase 84.6 in 78.7 in Ground Clearance 17.6 in 18.1 in Min. Turn Radius without Brakes 164.2 in; 169.3 in L: 139.7 in; R: 141.9 in Height to Top of ROPS 106.8 in Not Published Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model Not Published 99.2 in Overall Length 148.1 in (with 3-point hitch) 141.5 in (with 3-point hitch) ▶ WeightTractor Weight (Base) 5,463 lb (with ROPS) 4,952 lb (weight with cab) Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published 6,252 lb (4,952 + 1,300, computed; L4058PC loader total weight) ▶ Tire OptionsTire Size & Options Not Published R1 Agricultural, R4 Industrial, Golf tires R1 Agricultural - Front 11.2-24 9.5-20 R1 Agricultural - Rear 16.9-30 14.9-28 R3 Turf - Front Not Published 29x12.5-15 (golf tire) R3 Turf - Rear Not Published 44x18.00-20 (golf tire) R4 Industrial - Front 15-19.5 10.5/80-18 R4 Industrial - Rear 18.4-24 16.9-24 ▶ Loader & AttachmentsQuick Attach Loader System Not Published L4058PC: Quick attach mechanism Loader Model L5074SL L4058PC Loader Lift Height Not Published L4058PC: 117.5 in Loader Lift Capacity (Full Height) Not Published L4058PC: 3,437 lb (at pivot pin) Loader Breakout Force Not Published L4058PC: 4,742 lb (at pivot pin, ground level) ▶ WarrantyWarranty Length & Coverage Basic 24 months or 2,000 hours, parts and labor; loaders, backhoes and mid-mount mowers 12 months Basic 2 years or 2,000 hours; powertrain 3,000 hours maximum, parts and labor; loaders and backhoes 12 months
