▶ EngineEngine Manufacturer Deutz Deutz Engine Model TCD 2.9L TCD2.9 L4 Engine Type 4-cylinder, turbocharged, liquid-cooled diesel Turbocharged No. of Cylinders 4 4 Displacement 178.5 in³ 177.0 in³ Rated Engine Speed 2200 rpm 2200 rpm Engine Power (Gross) 74.3 hp 74 hp PTO Power 67.1 hp 64.1 hp Engine Emissions Constraints Tier 4 Tier 4 Cooling System Type Liquid-cooled Liquid-cooled Air Cleaner Dual dry Not Published Fuel System CRDI Common Rail Direct Injection Alternator 95 A, 12 V 95 A, 12 V ▶ HydraulicsPump Type Dual gear pump Not Published Implement Flow 10.3 gpm 10.3 gpm Steering Flow 5.8 gpm 5.8 gpm Total Hydraulic Flow 16.1 gpm 16.1 gpm Overall Hydraulic Pump Flow 16.1 gpm 16.1 gpm Hydraulic System Type Not Published Open center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves 4 2 No. of Optional Remote Valves Not Published Not Published ▶ Fluid CapacityFuel Tank Capacity 23.7 gal 23.8 gal Coolant Capacity 11.1 qt 10.6 qt Crankcase Capacity 9 qt 8.5 qt Transmission / Hydraulic System Capacity 17.4 gal 18.0 gal Front Axle Fluid Capacity 17.3 qt 17.4 qt ▶ PTO & HitchPTO Type Independent Independent PTO Rear 540/750 rpm 540/750 rpm Mid-PTO Availability Not Published No mid-PTO offered Category, 3-Point Hitch Category II Category II Hitch Lift Capacity 5,115 lb 5,115 lb Hitch Lift Capacity (at 24”) 3,418 lb 3,414 lb Lift Control Type Position/Draft Position / Draft / Mechanical ▶ Transmission & DrivetrainTransmission Type Synchro or power shuttle RK74 Power Shuttle Cab (RK74PSC): 16F/16R power shuttle with creeper; RK74 Shuttle Shift Cab: 16F/16R synchronized shuttle with creeper No. of Speeds F16 x R16 (Creep interlock) 16 forward, 16 reverse (creeper interlock) Max Travel Speed (Forward) 22.7 mph 18.9 mph Max Travel Speed (Reverse) Not Published Not Published Clutch M: Dry Single Plate; PS: Wet Multi Plate Single plate dry clutch (11.81 in diameter); hydraulic clutch assembly for Independent PTO models Differential Lock & Limited Slip Options Not Published 4WD, differential lock ▶ Chassis, Steering & ControlsFrame Type Not Published Unit frame: engine, clutch housing, transmission and front axle support bolted into one rigid assembly Steering Hydrostatic Hydrostatic power steering Brakes Wet, Multi-disc Wet disc Seat Suspension & Adjustability Suspension seat High-back suspension seat with extension Front Axle Type Not Published Center-pivot, reverse Eliot type (4WD) Front Axle Rating Not Published Not Published Drawbar Capacity Not Published Not Published ▶ Dimensions & ManeuverabilityOverall Width 92.3 in 76.4 in Wheelbase 86.1 in 86.1 in Ground Clearance 18.4 in 18.3 in Min. Turn Radius without Brakes 161.4 in 162.8 in Height to Top of ROPS Not Published Not Published Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model 104.9 in 103.3 in Overall Length 168.1 in (with 3-point hitch) 157.5 in (with 3-point hitch) ▶ WeightTractor Weight (Base) 6,316 lb (with cab) 6,052 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options Not Published Titan (USA): R4 Industrial (Std), R3 Turf (Opt), R1 Agricultural (Opt) R1 Agricultural - Front 280/85R24 11.2-24 R1 Agricultural - Rear 420/85R30 16.9-30 R3 Turf - Front Not Published 12.0-20.5 R3 Turf - Rear Not Published 22.4-25.5 R4 Industrial - Front 15-19.5 15-19.5 R4 Industrial - Rear 18.4-24 18.4-24 ▶ Loader & AttachmentsQuick Attach Loader System Not Published L135SL: Skid-steer compatible quick coupler, self-leveling Loader Model L5075SL L135SL Loader Lift Height L5075SL: 133.8 in L135SL: 135.5 in Loader Lift Capacity (Full Height) L5075SL: 3,325 lb (at pivot pin) L135SL: 3,223 lb at pivot pin to full height Loader Breakout Force L5075SL: 5,485 lb (at pivot pin, ground level) L135SL: 5,335 lb at pivot pin ▶ WarrantyWarranty Length & Coverage Basic 24 months or 2,000 hours, parts and labor; loaders, backhoes and mid-mount mowers 12 months Government and non-institutional: basic 24 months or 2,000 hours, powertrain 60 months or 3,000 hours; all other use: basic 24 months or 2,000 hours, powertrain 36 months or 3,000 hours
