▶ EngineEngine Manufacturer Deutz TYM Engine Model TCD 2.9L T2300T1-UTC_4 Engine Type 4-cylinder, turbocharged, liquid-cooled diesel 4-cylinder, turbocharged diesel No. of Cylinders 4 4 Displacement 178.5 in³ 139.5 in³ Rated Engine Speed 2200 rpm 2600 rpm Engine Power (Gross) 74.3 hp 58 hp PTO Power 67.1 hp 48 hp Engine Emissions Constraints Tier 4 Tier 4 Cooling System Type Liquid-cooled Not Published Air Cleaner Dual dry Dry element Fuel System CRDI IDI Alternator 95 A, 12 V 70 A, 12 V ▶ HydraulicsPump Type Dual gear pump Single gear pump Implement Flow 10.3 gpm 11.4 gpm Steering Flow 5.8 gpm 5.13 gpm Total Hydraulic Flow 16.1 gpm 16.5 gpm Overall Hydraulic Pump Flow 16.1 gpm 16.5 gpm Hydraulic System Type Not Published Not Published Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves 4 Loader: 6; Rear: 6 No. of Optional Remote Valves Not Published Not Published ▶ Fluid CapacityFuel Tank Capacity 23.7 gal 15.3 gal Coolant Capacity 11.1 qt 6.2 qt Crankcase Capacity 9 qt 4.8 qt Transmission / Hydraulic System Capacity 17.4 gal 11.62 gal Front Axle Fluid Capacity 17.3 qt 6.8 qt ▶ PTO & HitchPTO Type Independent Independent PTO Rear 540/750 rpm 540 rpm Mid-PTO Availability Not Published Not Published Category, 3-Point Hitch Category II Category II Hitch Lift Capacity 5,115 lb 4,409 lb Hitch Lift Capacity (at 24”) 3,418 lb 3,748 lb Lift Control Type Position/Draft Position and draft control (electronic) ▶ Transmission & DrivetrainTransmission Type Synchro or power shuttle Power shuttle No. of Speeds F16 x R16 (Creep interlock) F12 x R12 Max Travel Speed (Forward) 22.7 mph 24.04 mph Max Travel Speed (Reverse) Not Published Not Published Clutch M: Dry Single Plate; PS: Wet Multi Plate Wet, multi-disc Differential Lock & Limited Slip Options Not Published Standard differential lock ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Hydrostatic Hydrostatic Brakes Wet, Multi-disc Wet, multi-disc Seat Suspension & Adjustability Suspension seat Suspension seat Front Axle Type Not Published 4WD (selectable 2WD/4WD) Front Axle Rating Not Published Not Published Drawbar Capacity Not Published Not Published ▶ Dimensions & ManeuverabilityOverall Width 92.3 in 68.9 in Wheelbase 86.1 in 78.7 in Ground Clearance 18.4 in 18.1 in Min. Turn Radius without Brakes 161.4 in L: 139.7 in; R: 141.9 in Height to Top of ROPS Not Published Not Published Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model 104.9 in 99.2 in Overall Length 168.1 in (with 3-point hitch) 141.5 in (with 3-point hitch) ▶ WeightTractor Weight (Base) 6,316 lb (with cab) 4,952 lb (weight with cab) Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published 6,252 lb (4,952 + 1,300, computed; L4058PC loader total weight) ▶ Tire OptionsTire Size & Options Not Published R1 Agricultural, R4 Industrial, Golf tires R1 Agricultural - Front 280/85R24 9.5-20 R1 Agricultural - Rear 420/85R30 14.9-28 R3 Turf - Front Not Published 29x12.5-15 (golf tire) R3 Turf - Rear Not Published 44x18.00-20 (golf tire) R4 Industrial - Front 15-19.5 10.5/80-18 R4 Industrial - Rear 18.4-24 16.9-24 ▶ Loader & AttachmentsQuick Attach Loader System Not Published L4058PC: Quick attach mechanism Loader Model L5075SL L4058PC Loader Lift Height L5075SL: 133.8 in L4058PC: 117.5 in Loader Lift Capacity (Full Height) L5075SL: 3,325 lb (at pivot pin) L4058PC: 3,437 lb (at pivot pin) Loader Breakout Force L5075SL: 5,485 lb (at pivot pin, ground level) L4058PC: 4,742 lb (at pivot pin, ground level) ▶ WarrantyWarranty Length & Coverage Basic 24 months or 2,000 hours, parts and labor; loaders, backhoes and mid-mount mowers 12 months Basic 2 years or 2,000 hours; powertrain 3,000 hours maximum, parts and labor; loaders and backhoes 12 months
