TYM T554 vs Mahindra 5155 Shuttle | Side-by-side comparison | ITC Resource Center
Compare Tractors
See horsepower, lift capacity, hydraulic flow, and the numbers that matter to your work. Up to 4 machines, side by side, in graphs built to show which tractor is better at what.
CAT I & II with telescopic stabilizers & flex links
Hitch Lift Capacity
3,314 lb
Not Published
Hitch Lift Capacity (at 24”)
2,945 lb
3,748 lb
Lift Control Type
Position/Draft
Position control
Transmission Type
Synchro-Shuttle
Full synchromesh with forward/reverse synchro shuttle and constant-mesh range
No. of Speeds
F16 x R16
12F / 12R
Max Travel Speed (Forward)
18.4 mph
17.9 mph
Max Travel Speed (Reverse)
Not Published
Not Published
Clutch
Dry single plate
Dual dry with cerametallic lining
Differential Lock & Limited Slip Options
Rear differential lock, pedal operated
Not Published
Frame Type
Not Published
Not Published
Steering
Hydrostatic
Power steering with tilt steering wheel
Brakes
Wet disc
Fully-enclosed, 7-in diameter, dry disc
Seat Suspension & Adjustability
Not Published
Adjustable seat with contoured cushions, armrests and a soft-coil suspension
Front Axle Type
4WD, center-pivot reverse Elliot type
Not Published
Front Axle Rating
Not Published
Not Published
Drawbar Capacity
Not Published
Not Published
Overall Width
63.8 in
74.8 in
Wheelbase
76.2 in
77.9 in
Ground Clearance
13.8 in
16.4 in
Min. Turn Radius without Brakes
150.4 in
10.8 ft (3.29 m)
Height to Top of ROPS
102.1 in
Not Published
Height to Top of ROPS (folded)
Not Published
Not Published
Height to Top of Cab Model
Not Published
Not Published
Overall Length
141.3 in (with 3-point hitch)
136.6 in
Tractor Weight (Base)
3,814 lb (with ROPS)
5,390 lb
Weight with ROPS and Loader
Not Published
6,690 lb
Weight with Cab and Loader
Not Published
Not Published
Tire Size & Options
R1 Agricultural, R3 Turf, R4 Industrial
R1 Agricultural or R4 Industrial
R1 Agricultural - Front
Farm Specialist 9.5-16 NHS TL 6PR
9.5 x 20
R1 Agricultural - Rear
Farm Specialist 13.6-26 NHS TL 6PR
14.9 x 28
R3 Turf - Front
Multi-Trac CS 27x10.50-15 NHS TL 4PR
Not Published
R3 Turf - Rear
Multi-Trac CS 44x18.00-20 NHS TL 4PR
Not Published
R4 Industrial - Front
Trac Chief 12-16.5 NHS TL 6PR
10.5/80 x 18
R4 Industrial - Rear
Xtra Grip 17.5L-24 NHS TL 6PR
16.9 x 24
Quick Attach Loader System
TX55: Quick attach mechanism
Skid-steer style quick-attach coupler
Loader Model
TX55
5155-4L (front loader); 65B (rear backhoe)
Loader Lift Height
TX55: 109.1 in
122 in
Loader Lift Capacity (Full Height)
TX55: 2,478 lb (at pivot pin)
3,100 lb
Loader Breakout Force
TX55: 4,938 lb (at pivot pin, ground level)
5,200 lb
Warranty Length & Coverage
Basic 24 months or 2,000 hours, parts and labor; non-commercial, 20 to 70 engine hp: powertrain 72 months or 3,000 hours; loaders and backhoes 12 months
