▶ EngineEngine Manufacturer TYM LS Mtron Engine Model T2300T2 L3CRV-T7 Engine Type 4-cylinder, turbocharged, liquid-cooled diesel 3-cylinder, turbocharged, liquid-cooled diesel No. of Cylinders 4 3 Displacement 139.5 in³ 114.7 in³ Rated Engine Speed 2600 rpm 2600 rpm Engine Power (Gross) 55 hp 55 hp PTO Power 44.1 hp Gear: 46.7 hp; HST: 44 hp Engine Emissions Constraints Tier 4 Tier 4B (final) Cooling System Type Liquid-cooled Liquid cooled Air Cleaner Single dry Replaceable primary and inner elements Fuel System IDI Electronically controlled common rail direct injection Alternator 70 A, 12 V ROPS: 70 A; Cab: 85 A ▶ HydraulicsPump Type Dual gear pump Gear Implement Flow 7.7 gpm 8.2 gpm Steering Flow 4.3 gpm Gear: 4.2 gpm; HST: 5.3 gpm Total Hydraulic Flow 11.9 gpm Gear: 12.4 gpm; HST: 13.5 gpm Overall Hydraulic Pump Flow 11.9 gpm Gear: 12.4 gpm; HST: 13.5 gpm Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves 2 1 No. of Optional Remote Valves Not Published Up to 2 (second valve optional) ▶ Fluid CapacityFuel Tank Capacity 15.9 gal ROPS: 10.5 gal; Cab: 12.4 gal Coolant Capacity 6.9 qt 2.3 gal Crankcase Capacity 6.8 qt 5.8 qt Transmission / Hydraulic System Capacity 9.2 gal 11.4 gal Front Axle Fluid Capacity 10.5 qt 2.2 gal ▶ PTO & HitchPTO Type Independent Independent, electro-hydraulic engagement PTO Rear 540 rpm 540 rpm Mid-PTO Availability Optional (Mid-PTO kit) Standard (2000 rpm) Category, 3-Point Hitch Category I Category I Hitch Lift Capacity 3,822 lb 2,756 lb Hitch Lift Capacity (at 24”) 3,051 lb 2,116 lb Lift Control Type Position/Draft Position control (draft control optional) ▶ Transmission & DrivetrainTransmission Type Synchro-shuttle Gear: 16x16 synchronized shuttle shift (SSS); HST: 3-range hydrostatic, dual pedal No. of Speeds F8 x R8 Gear: 16F/16R; HST: 3-range Max Travel Speed (Forward) 18.6 mph Gear: 17.0 mph; HST: 17.9 mph Max Travel Speed (Reverse) Not Published Gear: 15.3 mph; HST: 11.37 mph Clutch Dry single plate Gear: dry single disc (10.8 in); HST: n/a Differential Lock & Limited Slip Options Rear differential lock, pedal operated Mechanical rear differential lock (pedal) ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Hydrostatic Power steering Brakes Wet disc Wet multi-disc Seat Suspension & Adjustability Not Published ROPS: adjustable suspension seat (fore/aft, weight and height adjustment); Cab: cloth suspension seat with weight control, fore/aft adjustment and adjustable armrests Front Axle Type 4WD, heavy-duty front axle Four-wheel drive (FWD) Front Axle Rating Not Published Not Published Drawbar Capacity Not Published Short position: 2,317 lb; Regular position: 1,598 lb; Extended position: 1,091 lb ▶ Dimensions & ManeuverabilityOverall Width 63.8 in 69.1 in Wheelbase 76.2 in 73.2 in Ground Clearance 13.8 in 15 in Min. Turn Radius without Brakes 131.5 in 111.8 in (right turn); 123.2 in (left turn) (with brake applied) Height to Top of ROPS 102.1 in 97.1 in Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model Not Published 94 in Overall Length 141.3 in (with 3-point hitch) 128.1 in ▶ WeightTractor Weight (Base) 3,887 lb (with ROPS) ROPS Gear: 3,424 lb; ROPS HST: 3,490 lb; Cab: 4,194 lb Weight with ROPS and Loader 5,007 lb (3,887 + 1,120, computed) Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options R1 Agricultural, R3 Turf, R4 Industrial R1 Agricultural, R3 Turf, R4 Industrial R1 Agricultural - Front Farm Specialist 9.5-16 NHS TL 6PR 9.5-16 R1 Agricultural - Rear Farm Specialist 13.6-26 NHS TL 6PR 13.6-24 R3 Turf - Front Multi-Trac CS 27x10.50-15 NHS TL 4PR 28x8.50-15 R3 Turf - Rear Multi-Trac CS 44x18.00-20 NHS TL 4PR 41x14.00-20 R4 Industrial - Front Trac Chief 12-16.5 NHS TL 6PR 12x16.5 R4 Industrial - Rear Xtra Grip 17.5Lx24 NHS TL 6PR 17.5Lx24 ▶ Loader & AttachmentsQuick Attach Loader System TX57: Quick attach mechanism Tool-free loader mount; optional skid-steer quick-attach plates Loader Model TX57 260TLA Loader Lift Height TX57: 109.4 in 260TLA: 109 in (at pivot pin) Loader Lift Capacity (Full Height) TX57: 2,790 lb (at pivot pin) 260TLA: 2,371 lb (at bucket pivot pin, max height) Loader Breakout Force TX57: 5,316 lb (at pivot pin, ground level) 260TLA: 4,081 lb (at bucket pivot pin) ▶ WarrantyWarranty Length & Coverage Basic 24 months or 2,000 hours, parts and labor; non-commercial, 20 to 70 engine hp: powertrain 72 months or 3,000 hours; loaders and backhoes 12 months Basic 2 years or 750 hours; powertrain 4 more years (6 years or 1,500 hours total) ▶ ITC Company AccessoriesAccessories that fit None tagged yet
