Pick up to 4tractors and we'll lay every spec sheet out side by side. Same data we publish on the individual model pages, stacked in columns so you can compare numbers at a glance.
No photo
—
TYMT574C
No photo
—
TYM5835
Comparison loaded for 2 tractors.
Spec
TYMT574C
TYM5835
PTO Power
44.7 hp (32.9 kW)
48 hp (35 kW)
Alternator
12 V, 70 A
12 V, 70 A
Air Cleaner
Single dry
Dry element
Engine Type
4-cylinder, turbocharged diesel
4-cylinder, turbocharged diesel
Fuel System
IDI
IDI
Displacement
139.5 in³ (2,286 cc)
139.5 in³ (2,286 cc)
No. of Cylinders
4
4
Rated Engine Speed
2,600 rpm
2,600 rpm
Cooling System Type
Not Published
Not Published
Engine Manufacturer
TYM
TYM
Engine Emissions Constraints
Tier 4
Tier 4
Engine Power (Gross vs. Net HP)
Gross: 55 hp (41 kW)
Gross: 58 hp (42.5 kW)
Tractor Weight with Loader
5,353 lb (2,428 kg)
Not Published
Weight with Cab and Loader
5,353 lb (2,428 kg)
Not Applicable
Weight with ROPS and Loader
Not Applicable
Not Published
Pump Type
Dual gear pump
Single gear pump
Steering Flow
17.8 L/min (4.3 gpm)
19.4 L/min (5.2 gpm)
Implement Flow
29 L/min (7.7 gpm)
43.2 L/min (11.4 gpm)
Total Hydraulic Flow
46.8 L/min (11.9 gpm)
62.6 L/min (16.5 gpm)
Hydraulic System Type
Not Published
Not Published
Rear Remote Hydraulic Flow
Not Published
Not Published
Overall Hydraulic Pump Flow
46.8 L/min (11.9 gpm)
62.6 L/min (16.5 gpm)
No. of Optional Remote Valves
Not Published
Not Published
No. of Standard Remote Valves
2
Loader: 4; Rear: 2
R3 Turf - Rear
Multi-Trac CS 44x18.00-20 NHS TL 4PR
Not Published
R3 Turf - Front
Multi-Trac CS 27x10.50-15 NHS TL 4PR
Not Published
Tire Size & Options
R1 Agricultural, R3 Turf, R4 Industrial
R1 Agricultural, R4 Industrial
R4 Industrial - Rear
Xtra Grip 17.5Lx24 NHS TL 6PR
16.9–24
R4 Industrial - Front
Trac Chief 12-16.5 NHS TL 6PR
10.5/80-18
R1 Agricultural - Rear
Farm Specialist 13.6-26 NHS TL 6PR
14.9–28
R1 Agricultural - Front
Farm Specialist 9.5-16 NHS TL 6PR
9.5–20
PTO Rear
540 rpm
540 rpm
PTO Type
Independent
Independent
Lift Control Type
Position/Draft
Mechanical
Hitch Lift Capacity
3,822 lb (1,733 kg)
4,409 lb (2,000 kg)
Mid-PTO Availability
Available (Mid-PTO kit)
Not Published
Category, 3-Point Hitch
Category I
Category II
Hitch Lift Capacity (at 24”)
3,050.6 lb (1,387 kg)
3,748 lb (1,700 kg)
Rear 3-Point Hitch Lift Capacity
3,822 lb (1,733 kg)
4,409 lb (2,000 kg)
Coolant Capacity
6.9 qt (6.5 L)
6.2 qt (5.9 L)
Crankcase Capacity
6.8 qt (6.4 L)
4.8 qt (4.5 L)
Fuel Tank Capacity
17.0 gal (60 L)
15.3 gal (58 L)
Front Axle Fluid Capacity
10.5 qt (9.9 L)
6.8 qt (6.4 L)
Transmission / Hydraulic System Capacity
9.2 gal (34.8 L)
11.6 gal (44 L)
Loader Lift Height
109.4 in (2,780 mm)
117.5 in (2,984 mm)
Loader Breakout Force
5,316 lb (2,411 kg)
4,742 lb (2,151 kg)
Price for Backhoe Option
Not Published
BH350
Price for Mid-Mount Mower
Not Published
Not Published
Quick Attach Loader System
TX57: Quick attachment (Skid/Euro type)
BL350: Quick attachment assembly
Loader Lift Capacity (Full Height)
2,790 lb (1,266 kg)
3,437 lb (1,559 kg)
Clutch
Dry single plate
Wet, multi-disc
No. of Speeds
F8 x R8
F12 x R12
Transmission Type
Synchro-shuttle
Power shuttle
Max Travel Speed (Forward)
18.6 mph (30.0 km/h)
19.9 mph (32 km/h)
Max Travel Speed (Reverse)
Not Published
Not Published
Differential Lock & Limited Slip Options
Not Published
Not Published
Brakes
Wet disc
Wet, multi-disc
Steering
Hydrostatic
Hydrostatic
Frame Type
Not Published
Not Published
Front Axle Type
Not Published
Not Published
Drawbar Capacity
Not Published
Not Published
Front Axle Rating
Not Published
Not Published
Seat Suspension & Adjustability
Not Published
Suspension seat
Wheelbase
76.2 in (1,935 mm)
78.7 in (2,000 mm)
Overall Width
63.8 in (1,620 mm)
68.9 in (1,750 mm)
Ground Clearance
13.8 in (350 mm)
18.1 in (460 mm)
Height to Top of ROPS
Not Applicable
102.8 in (2,611 mm)
Height to Top of Cab Model
98 in (2,490 mm)
Not Applicable
Height to Top of ROPS (folded)
Not Applicable
Not Published
Min. Turn Radius without Brakes
131.5 in (3,340 mm)
L: 124.4 in (3,160 mm); R: 124.0 in (3,150 mm)
Overall Length with 3-Point Hitch
141.3 in (3,590 mm)
136.4 in (3,465 mm)
Financing Options
0% financing for up to 72 months and instant cash rebates. Contact dealer for more information.
0% financing for up to 72 months and instant cash rebates. Contact dealer for more information.
Base Price with Loader
Not Published
Not Published
Warranty Length & Coverage
Up to 2 years or until the 2,000 hours mark, bumper-to-bumper warranty; 3000 hours maximum coverage period for parts and labour on drivetrains or powertrains; 12-months warranty period for implements, including loaders and backhoes.
Up to 2 years or until the 2,000 hours mark, bumper-to-bumper warranty; 3000 hours maximum coverage period for parts and labour on drivetrains or powertrains; 12-months warranty period for implements, including loaders and backhoes.
