▶ EngineEngine Manufacturer Deutz FPT Engine Model TCD3.6 F5 Engine Type 4-cylinder, turbocharged diesel Turbocharged 4-cylinder diesel No. of Cylinders 4 4 Displacement 220 in³ 207 in³ Rated Engine Speed 2200 rpm 2300 rpm Engine Power (Gross) 111 hp 112 hp PTO Power 107.3 hp 92 hp Engine Emissions Constraints Tier 4 Tier 4B Cooling System Type Liquid-cooled Liquid-cooled Air Cleaner Dual dry Not Published Fuel System CRDI Not Published Alternator 120 A, 12 V 120 A ▶ HydraulicsPump Type Dual gear pump Not Published Implement Flow 14.3 gpm 16.9 gpm (21.6 gpm optional) Steering Flow 7.1 gpm 9.7 gpm Total Hydraulic Flow 21.4 gpm 26.6 gpm (16.9 + 9.7, computed) Overall Hydraulic Pump Flow 21.4 gpm 26.6 gpm (16.9 + 9.7, computed) Hydraulic System Type Not Published Open center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves 6 2 or 3 No. of Optional Remote Valves Not Published Not Published ▶ Fluid CapacityFuel Tank Capacity 31.43 gal ROPS: 24 gal; Cab: 29 gal Coolant Capacity 4.8 gal Not Published Crankcase Capacity 2.11 gal Not Published Transmission / Hydraulic System Capacity 23.8 gal Not Published Front Axle Fluid Capacity 4.6 gal Not Published ▶ PTO & HitchPTO Type Independent Independent wet clutch PTO, hydraulically engaged PTO Rear 540/750/1000 rpm 540 (base); 540/540E or 540/1000 (optional) Mid-PTO Availability Not Published Not Published Category, 3-Point Hitch Category II Category II/I Hitch Lift Capacity 7,295 lb Not Published Hitch Lift Capacity (at 24”) 6,007 lb 3,200 lb (6,200 lb with optional ram) Lift Control Type Position/Draft Lift-O-Matic rear hitch control ▶ Transmission & DrivetrainTransmission Type Power shuttle, Power shift 12x12 power shuttle No. of Speeds F32 x R32 12F/12R Max Travel Speed (Forward) 23 mph Not Published Max Travel Speed (Reverse) Not Published Not Published Clutch Wet Not Published Differential Lock & Limited Slip Options Not Published Not Published ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Hydrostatic Power steering Brakes Hydraulic Wet disc Seat Suspension & Adjustability Air-ride full suspension seat Cab: cloth air-suspension seat with fold-back instructor seat; ROPS: vinyl air-suspension seat Front Axle Type Not Published 4WD front axle, electronic engagement (standard) Front Axle Rating Not Published Not Published Drawbar Capacity Not Published Not Published ▶ Dimensions & ManeuverabilityOverall Width 91.33 in Not Published Wheelbase 93.7 in Cab: 88.9 in; ROPS: 83.7 in Ground Clearance 16.7 in Not Published Min. Turn Radius without Brakes 159.5 in (left); 161 in (right) Not Published Height to Top of ROPS Not Published 103.0 in Height to Top of ROPS (folded) Not Published Low-Profile ROPS: 68.4 in to ROPS pivot (500/60-22.5 R1 tires); 71.9 in (19.5L24 R4 tires) Height to Top of Cab Model 112.59 in 105.4 in Overall Length 167.32 in (with 3-point hitch) 161.1 in (4WD) ▶ WeightTractor Weight (Base) 8,939 lb (weight with cab) Cab/4WD: 8,367 lb; ROPS/4WD: 7,738 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options Not Published R1 rear: 18.4x30 (cab and all-purpose ROPS), 500/60-22.5 (low-profile ROPS); R4 rear: 19.5L24 R1 Agricultural - Front 13.6-24 8PR 12.4x24 (with 18.4x30 rear); 11.2-24 (with 16.9-30 rear); 11.5/80-18 (with 500/60-22.5 low-profile rear) R1 Agricultural - Rear 18.4-34 10PR 18.4x30 (cab and all-purpose ROPS); 500/60-22.5 (low-profile ROPS) R3 Turf - Front Not Published Not Published R3 Turf - Rear Not Published Not Published R4 Industrial - Front Not Published 12.5/80-18 R4 Industrial - Rear Not Published 19.5L24 ▶ Loader & AttachmentsQuick Attach Loader System Not Published Skid-steer style (84 in bucket standard); Euro-style quick attach available Loader Model Not Published 632TL (NSL); 637TL (MSL) Loader Lift Height Not Published 632TL: 134.5 in; 637TL: 134.5 in Loader Lift Capacity (Full Height) Not Published 632TL: 2,028 lb; 637TL: 3,174 lb (at 31.5 in from bucket pivot pin to max height) Loader Breakout Force Not Published Not Published ▶ WarrantyWarranty Length & Coverage Basic 2 years or 2,000 hours; powertrain 3,000 hours maximum, parts and labor; loaders and backhoes 12 months Not Published
