▶ EngineEngine Manufacturer Deutz Kukje Engine Model TCD3.6 7845C: D3400T10-UTC-3; 7845R: D3400T1-UTR-3 Engine Type 4-cylinder, turbocharged diesel Turbocharged, direct injection, liquid-cooled diesel No. of Cylinders 4 4 Displacement 220 in³ 208 in³ Rated Engine Speed 2200 rpm 2500 rpm Engine Power (Gross) 111 hp 78 hp PTO Power 107.3 hp 64 hp Engine Emissions Constraints Tier 4 Not Published Cooling System Type Liquid-cooled Liquid-cooled Air Cleaner Dual dry Dry, double filter element Fuel System CRDI Direct injection Alternator 120 A, 12 V 70 A, 12 V ▶ HydraulicsPump Type Dual gear pump Dual pumps (separate steering and main pumps) Implement Flow 14.3 gpm Not Published Steering Flow 7.1 gpm Not Published Total Hydraulic Flow 21.4 gpm 19.3 gpm Overall Hydraulic Pump Flow 21.4 gpm Not Published Hydraulic System Type Not Published Electric over hydraulic control (position, draft & mixed) Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves 6 Not Published No. of Optional Remote Valves Not Published Not Published ▶ Fluid CapacityFuel Tank Capacity 31.43 gal 23.8 gal Coolant Capacity 4.8 gal Not Published Crankcase Capacity 2.11 gal Not Published Transmission / Hydraulic System Capacity 23.8 gal Not Published Front Axle Fluid Capacity 4.6 gal Not Published ▶ PTO & HitchPTO Type Independent Independent (6-spline shaft) PTO Rear 540/750/1000 rpm Not Published Mid-PTO Availability Not Published Not Published Category, 3-Point Hitch Category II Category II Hitch Lift Capacity 7,295 lb 3,820 lb Hitch Lift Capacity (at 24”) 6,007 lb 2,526 lb Lift Control Type Position/Draft Position, draft & mixed ▶ Transmission & DrivetrainTransmission Type Power shuttle, Power shift Power shuttle (hydraulic shuttle); main shifting fully synchronized (4-speed) No. of Speeds F32 x R32 16F/16R Max Travel Speed (Forward) 23 mph 24.8 mph Max Travel Speed (Reverse) Not Published 25.6 mph Clutch Wet Multi, wet Differential Lock & Limited Slip Options Not Published Not Published ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Hydrostatic Hydrostatic Brakes Hydraulic Wet disc Seat Suspension & Adjustability Air-ride full suspension seat Deluxe seat with lumbar adjustment Front Axle Type Not Published 4WD, heavy-duty front axle, 56-degree steering angle each direction, no drag link Front Axle Rating Not Published Not Published Drawbar Capacity Not Published Not Published ▶ Dimensions & ManeuverabilityOverall Width 91.33 in 74.5 in Wheelbase 93.7 in 86.6 in Ground Clearance 16.7 in 18.3 in Min. Turn Radius without Brakes 159.5 in (left); 161 in (right) Not Published Height to Top of ROPS Not Published 102.6 in Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model 112.59 in 107.8 in Overall Length 167.32 in (with 3-point hitch) 152.7 in ▶ WeightTractor Weight (Base) 8,939 lb (weight with cab) 7845C: 6,250 lb; 7845R: 5,752 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options Not Published Agricultural: 11.2x24 front / 16.9x30 rear R1 Agricultural - Front 13.6-24 8PR 11.2x24 R1 Agricultural - Rear 18.4-34 10PR 16.9x30 R3 Turf - Front Not Published Not Published R3 Turf - Rear Not Published Not Published R4 Industrial - Front Not Published Not Published R4 Industrial - Rear Not Published Not Published ▶ Loader & AttachmentsQuick Attach Loader System Not Published BL45: Quick attachment bucket mount Loader Model Not Published BL45 Loader Lift Height Not Published BL45: 111.7 in Loader Lift Capacity (Full Height) Not Published BL45: 2,804 lb (at pivot pins, full height) Loader Breakout Force Not Published BL45: 5,467 lbf (at pivot pin, ground level) ▶ WarrantyWarranty Length & Coverage Basic 2 years or 2,000 hours; powertrain 3,000 hours maximum, parts and labor; loaders and backhoes 12 months Four-year limited warranty
