▶ EngineEngine Manufacturer Deutz John Deere Engine Model TCD2.9L4 John Deere PowerTech 3029 Engine Type 4-cylinder, turbocharged, liquid-cooled diesel Diesel, turbocharged, liquid-cooled No. of Cylinders 4 3 Displacement 177 in³ 179 in³ Rated Engine Speed 2200 rpm 2100 rpm Engine Power (Gross) 67 hp 67 hp PTO Power 61.9 hp 49 hp Engine Emissions Constraints Tier 4 Tier 4 Cooling System Type Liquid-cooled Liquid-cooled Air Cleaner Dual dry Dry type, dual element (primary and secondary) Fuel System CRDI Not Published Alternator 95 A, 12 V 40 A ▶ HydraulicsPump Type Dual gear pump Not Published Implement Flow 10.3 gpm 11.4 gpm Steering Flow 5.8 gpm 6.8 gpm Total Hydraulic Flow 16.1 gpm 18.2 gpm Overall Hydraulic Pump Flow 16.1 gpm 18.2 gpm Hydraulic System Type Open center Open Center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves 2 1 No. of Optional Remote Valves Not Published 2 ▶ Fluid CapacityFuel Tank Capacity 18.5 gal 19.6 gal Coolant Capacity 10.6 qt 10 qt Crankcase Capacity 8.5 qt 9 qt Transmission / Hydraulic System Capacity 11 gal 10.3 gal Front Axle Fluid Capacity 17.3 qt Dana axle: differential housing 1.18 gal, wheel hub (each) 0.21 gal; Carraro axle: differential housing 1.03 gal, reduction gear oil (each side) 0.15 gal ▶ PTO & HitchPTO Type Independent Independent; mechanical engagement (SyncShuttle); electrohydraulic engagement (PowrReverser) PTO Rear 540/750/1000 rpm 540 rpm (540E optional with PowrReverser) Mid-PTO Availability Not Published Not Published Category, 3-Point Hitch Category II Category II, convertible to I Hitch Lift Capacity 4,270 lb Not Published Hitch Lift Capacity (at 24”) 3,153 lb 3,192 lb Lift Control Type Position/Draft/Mech Position control with top link draft sensing ▶ Transmission & DrivetrainTransmission Type Synchro-shuttle SyncShuttle (standard); PowrReverser (optional) No. of Speeds F24 x R24 9F/3R (SyncShuttle); 12F/12R (PowrReverser optional) Max Travel Speed (Forward) 20.2 mph Not Published Max Travel Speed (Reverse) Not Published Not Published Clutch M: Dry Single Plate; PS: Wet Multi Plate Dry (SyncShuttle); wet (12F/12R PowrReverser) Differential Lock & Limited Slip Options Differential lock Differential lock, standard; pedal-operated, mechanical ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Hydrostatic Power steering Brakes Wet disc Hydraulic wet disc brakes Seat Suspension & Adjustability Suspension seat Not Published Front Axle Type MFWD (4WD) 2WD or MFWD Front Axle Rating Not Published Not Published Drawbar Capacity Not Published 1,675 lb (fully extended); 2,470 lb (short position) ▶ Dimensions & ManeuverabilityOverall Width 72.4 in 57.3 in Wheelbase 84.6 in 80.7 in Ground Clearance 17.1 in 2WD: 18.8 in; MFWD: 13.4 in Min. Turn Radius without Brakes 162.2 in 11.5 ft (2WD); 15.3 ft (4WD); 12.8 ft (4WD, Carraro axle) Height to Top of ROPS Not Published 98.4 in Height to Top of ROPS (folded) Not Published 78.5 in Height to Top of Cab Model 100.2 in 95.6 in Overall Length 155.6 in (with 3-point hitch) 137.8 in ▶ WeightTractor Weight (Base) 5,555 lb (weight with cab) 2WD: 4,634 lb; MFWD: 5,621 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader 7,140 lb (5,555 + 1,585, computed) Not Published ▶ Tire OptionsTire Size & Options R1 Agricultural, R4 Industrial Not Published R1 Agricultural - Front FSTR 9.5 R20 TL MFWD: 9.5-24; 280/85R24 (11.2R24) R1W Radial R1 Agricultural - Rear FSTR 380/85R28 TL (14.9R28) 16.9-28 R3 Turf - Front Not Published 9.5-16 (MFWD) R3 Turf - Rear Not Published 21.5L-16.1; 22.5LL-16.1 (Turf Special) R4 Industrial - Front Trac Chief 10.5/80-18 NHS TL 10PR 12.5/80-18 (MFWD) R4 Industrial - Rear Xtra Grip 18.4-24 NHS TL 8PR 16.9-24 ▶ Loader & AttachmentsQuick Attach Loader System TX65SL: Quick attach mechanism 520M; H240 (NSL or MSL) Loader Model TX65SL H240NSL Loader Lift Height TX65SL: 124.8 in 131 in Loader Lift Capacity (Full Height) TX65SL: 3,122 lb (at pivot pin) 3,671 lb (H240NSL, at pivot) Loader Breakout Force TX65SL: 5,225 lb (at pivot pin, ground level) 4,504 lb (H240NSL, at pivot) ▶ WarrantyWarranty Length & Coverage Basic 2 years or 2,000 hours; powertrain 3,000 hours maximum, parts and labor; loaders and backhoes 12 months Not Published
