▶ EngineEngine Manufacturer Deutz John Deere Engine Model TCD2.9L4 PowerTech 3029 (2.9L) EWR Engine Type 4-cylinder, turbocharged, liquid-cooled diesel Diesel, turbocharged No. of Cylinders 4 3 Displacement 177 in³ 179 in³ Rated Engine Speed 2200 rpm 2100 rpm Engine Power (Gross) 67 hp 67.6 hp PTO Power 61.9 hp PR/TSS OOS: 55.3 hp; PR/TSS Cab: 53.3 hp; eHydro: 44.5 hp Engine Emissions Constraints Tier 4 Tier 4 Cooling System Type Liquid-cooled Liquid cooled Air Cleaner Dual dry Dry type with safety element Fuel System CRDI Electronically controlled, high-pressure common rail Alternator 95 A, 12 V 110 A ▶ HydraulicsPump Type Dual gear pump PR/TSS: tandem gear pump (implement + steering); eHydro: three pumps Implement Flow 10.3 gpm 11.4 gpm Steering Flow 5.8 gpm 6.8 gpm Total Hydraulic Flow 16.1 gpm PR/TSS: 18.2 gpm; eHydro: 29.6 gpm Overall Hydraulic Pump Flow 16.1 gpm PR/TSS: 18.2 gpm; eHydro: 29.6 gpm Hydraulic System Type Open center Open Center Rear Remote Hydraulic Flow Not Published 11.4 gpm at a single rear SCV No. of Standard Remote Valves 2 1 No. of Optional Remote Valves Not Published Not Published ▶ Fluid CapacityFuel Tank Capacity 18.5 gal OOS: 19 gal; Cab: 21 gal Coolant Capacity 10.6 qt Not Published Crankcase Capacity 8.5 qt 9.0 qt (with filter) Transmission / Hydraulic System Capacity 11 gal Not Published Front Axle Fluid Capacity 17.3 qt DANA: 1.18 gal diff + 0.21 gal per hub; Carraro: 1.03 gal diff + 0.15 gal per side ▶ PTO & HitchPTO Type Independent Independent PTO Rear 540/750/1000 rpm 540 rpm (SyncShuttle); 540/540E rpm (PowrReverser) Mid-PTO Availability Not Published Not Published Category, 3-Point Hitch Category II Category II, convertible to I Hitch Lift Capacity 4,270 lb 3,968 lb Hitch Lift Capacity (at 24”) 3,153 lb 3,192 lb Lift Control Type Position/Draft/Mech Position control, draft control, adjustable rate of drop ▶ Transmission & DrivetrainTransmission Type Synchro-shuttle SyncShuttle (standard); PowrReverser or eHydro (optional) No. of Speeds F24 x R24 9F/3R (SyncShuttle); 12F/12R (PowrReverser) Max Travel Speed (Forward) 20.2 mph 15.5 mph (SyncShuttle) Max Travel Speed (Reverse) Not Published Not Published Clutch M: Dry Single Plate; PS: Wet Multi Plate SyncShuttle: dry; PowrReverser: wet; eHydro: hydrostatic Differential Lock & Limited Slip Options Differential lock Mechanical, rear ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Hydrostatic Hydrostatic power steering Brakes Wet disc Hydraulically actuated wet disc brakes, self-equalizing and self-adjusting Seat Suspension & Adjustability Suspension seat Not Published Front Axle Type MFWD (4WD) 2WD or MFWD Front Axle Rating Not Published Not Published Drawbar Capacity Not Published Adjustable drawbar with interchangeable hitch balls ▶ Dimensions & ManeuverabilityOverall Width 72.4 in Not Published Wheelbase 84.6 in 80.7 in Ground Clearance 17.1 in Not Published Min. Turn Radius without Brakes 162.2 in 11.5 ft (2WD); 15.3 ft (MFWD) Height to Top of ROPS Not Published Not Published Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model 100.2 in Not Published Overall Length 155.6 in (with 3-point hitch) 144.5 in ▶ WeightTractor Weight (Base) 5,555 lb (weight with cab) 5,555 to 6,812 lb (shipping weight) Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader 7,140 lb (5,555 + 1,585, computed) Not Published ▶ Tire OptionsTire Size & Options R1 Agricultural, R4 Industrial Not Published R1 Agricultural - Front FSTR 9.5 R20 TL MFWD: 11.2-24; 12.4-24 R1 Agricultural - Rear FSTR 380/85R28 TL (14.9R28) 16.9-28 R3 Turf - Front Not Published Not Published R3 Turf - Rear Not Published Not Published R4 Industrial - Front Trac Chief 10.5/80-18 NHS TL 10PR Not Published R4 Industrial - Rear Xtra Grip 18.4-24 NHS TL 8PR Not Published ▶ Loader & AttachmentsQuick Attach Loader System TX65SL: Quick attach mechanism 520M and H240 loaders (Loader Prep Package includes loader mounting frames and hood guard); not compatible with the 512 loader Loader Model TX65SL 500E, 500M or 520M Loader Lift Height TX65SL: 124.8 in 500M: 124 in Loader Lift Capacity (Full Height) TX65SL: 3,122 lb (at pivot pin) 500M: 3,225 lb (at pivot, full height) Loader Breakout Force TX65SL: 5,225 lb (at pivot pin, ground level) 500M: 4,354 lb (at pivot) ▶ WarrantyWarranty Length & Coverage Basic 2 years or 2,000 hours; powertrain 3,000 hours maximum, parts and labor; loaders and backhoes 12 months Not Published
