Pick up to 4tractors and we'll lay every spec sheet out side by side. Same data we publish on the individual model pages, stacked in columns so you can compare numbers at a glance.
No photo
—
TYMT654
No photo
—
TYMT554
Comparison loaded for 2 tractors.
Spec
TYMT654
TYMT554
PTO Power
61.9 hp (46.1 kW)
45.6 hp (33.5 kW)
Alternator
12 V, 95 A
12 V, 70 A
Air Cleaner
Dual dry
Dual dry
Engine Type
4-cylinder, turbocharged diesel
4-cylinder, turbocharged diesel
Fuel System
CRDI
CRDI
Displacement
177 in³ (2,900 cc)
127.6 in³ (2,091 cc)
No. of Cylinders
4
4
Rated Engine Speed
2,200 rpm
2,800 rpm
Cooling System Type
Not Published
Not Published
Engine Manufacturer
Deutz
Yanmar
Engine Emissions Constraints
Diesel Oxidation Catalyst (DOC)
Not Published
Engine Power (Gross vs. Net HP)
Gross: 67 hp (50 kW)
Gross: 55.9 hp (41.1 kW)
Tractor Weight with Loader
7,140 lb (3,239 kg)
5,075 lb (2,302 kg)
Weight with Cab and Loader
7,140 lb (3,239 kg)
Not Applicable
Weight with ROPS and Loader
Not Applicable
5,075 lb (2,302 kg)
Pump Type
Dual gear pump
Dual gear pump
Steering Flow
22.0 L/min (5.8 gpm)
17.3 L/min (4.6 gpm)
Implement Flow
39.1 L/min (10.3 gpm)
35.7 L/min (9.5 gpm)
Total Hydraulic Flow
61.1 L/min (16.1 gpm)
52.9 L/min (14.1 gpm)
Hydraulic System Type
Not Published
Not Published
Rear Remote Hydraulic Flow
Not Published
Not Published
Overall Hydraulic Pump Flow
61.1 L/min (16.1 gpm)
52.9 L/min (14.1 gpm)
No. of Optional Remote Valves
Not Published
Not Published
No. of Standard Remote Valves
2
2
R3 Turf - Rear
Not Published
Multi-Trac CS 44x18.00-20 NHS TL 4PR
R3 Turf - Front
Not Published
Multi-Trac CS 27x10.50-15 NHS TL 4PR
Tire Size & Options
R1 Agricultural, R4 Industrial
R1 Agricultural, R3 Turf, R4 Industrial
R4 Industrial - Rear
Xtra Grip 18.4-24 NHS TL 8PR
Xtra Grip 17.5L-24 NHS TL 6PR
R4 Industrial - Front
Trac Chief 10.5/80-18 NHS TL 10PR
Trac Chief 12-16.5 NHS TL 6PR
R1 Agricultural - Rear
FSTR 380/85R28 TL (14.9R28)
Farm Specialist 13.6-26 NHS TL 6PR
R1 Agricultural - Front
FSTR 9.5 R20 TL
Farm Specialist 9.5-16 NHS TL 6PR
PTO Rear
540/750/1,000 rpm
540 rpm
PTO Type
Independent
Independent
Lift Control Type
Position/Draft/Mech
Position/Draft
Hitch Lift Capacity
4,270 lb (1,937 kg)
3,314 lb (1,503 kg)
Mid-PTO Availability
Not Published
Not Published
Category, 3-Point Hitch
Category II
Category I
Hitch Lift Capacity (at 24”)
3,153 lb (1,430 kg)
2,945 lb (1,336 kg)
Rear 3-Point Hitch Lift Capacity
4,270 lb (1,937 kg)
3,314 lb (1,503 kg)
Coolant Capacity
10.6 qt (10 L)
9 qt (8.5 L)
Crankcase Capacity
8.5 qt (8 L)
7.1 qt (6.7 L)
Fuel Tank Capacity
18.5 gal (70 L)
17.0 gal (60 L)
Front Axle Fluid Capacity
17.3 qt (16.3 L)
10.5 qt (9.9 L)
Transmission / Hydraulic System Capacity
11.0 gal (41.6 L)
9.2 gal (34.8 L)
Loader Lift Height
124.8 in (3,169 mm)
109.1 in (2,770 mm)
Loader Breakout Force
5,225 lb (2,370 kg)
4,938 lb (2,240 kg)
Price for Backhoe Option
Not Published
Not Published
Price for Mid-Mount Mower
Not Published
Not Published
Quick Attach Loader System
TX65SL: Quick attachment (Skid/Euro type)
TX55: Quick attach mechanism
Loader Lift Capacity (Full Height)
3,122 lb (1,416 kg)
2,478 lb (1,124 kg)
Clutch
M: Dry Single Plate; PS: Wet Multi Plate
Dry single plate
No. of Speeds
F24 x R24
F16 x R16
Transmission Type
Synchro-shuttle
Synchro-Shuttle
Max Travel Speed (Forward)
20.2 mph (32.5 km/h)
18.4 mph (29.7 km/h)
Max Travel Speed (Reverse)
Not Published
Not Published
Differential Lock & Limited Slip Options
Differential lock
Not Published
Brakes
Wet disc
Wet disc
Steering
Hydrostatic
Hydrostatic
Frame Type
Not Published
Not Published
Front Axle Type
Not Published
Not Published
Drawbar Capacity
Not Published
Not Published
Front Axle Rating
Not Published
Not Published
Seat Suspension & Adjustability
Suspension seat
Not Published
Wheelbase
84.6 in (2,150 mm)
76.2 in (1,935 mm)
Overall Width
72.4 in (1,840 mm)
63.8 in (1,620 mm)
Ground Clearance
17.1 in (435 mm)
13.8 in (350 mm)
Height to Top of ROPS
Not Applicable
102.1 in (2,594 mm)
Height to Top of Cab Model
100.2 in (2,545 mm)
Not Applicable
Height to Top of ROPS (folded)
Not Applicable
Not Published
Min. Turn Radius without Brakes
162.2 in (4,120 mm)
150.4 in (3,820 mm)
Overall Length with 3-Point Hitch
155.6 in (3,952 mm)
141.3 in (3,590 mm)
Financing Options
0% financing for up to 72 months and instant cash rebates. Contact dealer for more information.
0% financing for up to 72 months and instant cash rebates. Contact dealer for more information.
Base Price with Loader
Not Published
Not Published
Warranty Length & Coverage
Up to 2 years or until the 2,000 hours mark, bumper-to-bumper warranty; 3000 hours maximum coverage period for parts and labour on drivetrains or powertrains; 12-months warranty period for implements, including loaders and backhoes.
Up to 2 years or until the 2,000 hours mark, bumper-to-bumper warranty; 3000 hours maximum coverage period for parts and labour on drivetrains or powertrains; 12-months warranty period for implements, including loaders and backhoes.
