▶ EngineEngine Manufacturer Deutz FPT Engine Model TCD2.9L4 F5C Engine Type 4-cylinder, turbocharged, liquid-cooled diesel 4-cylinder diesel, turbocharged No. of Cylinders 4 4 Displacement 177 in³ 207 in³ Rated Engine Speed 2200 rpm 2300 rpm Engine Power (Gross) 74 hp 74 hp PTO Power 64.1 hp 65 hp Engine Emissions Constraints Tier 4 US EPA Tier 4B Cooling System Type Liquid-cooled Liquid-cooled Air Cleaner Dual dry Dry Fuel System CRDI Common rail fuel injection Alternator 95 A, 12 V 120 A ▶ HydraulicsPump Type Dual gear pump Open center, dual pumps: implement pump plus dedicated steering and services pump Implement Flow 10.3 gpm 12.5 gpm Steering Flow 5.8 gpm 7.3 gpm (mechanical shuttle); 9.5 gpm (power shuttle) Total Hydraulic Flow 16.1 gpm 19.8 gpm (mechanical shuttle; 12.5 + 7.3, computed); 22.0 gpm (power shuttle; 12.5 + 9.5, computed) Overall Hydraulic Pump Flow 16.1 gpm 19.8 gpm (mechanical shuttle; 12.5 + 7.3, computed); 22.0 gpm (power shuttle; 12.5 + 9.5, computed) Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves 2 Not Published No. of Optional Remote Valves Not Published Up to 3 rear remotes ▶ Fluid CapacityFuel Tank Capacity 23.8 gal 23.8 gal Coolant Capacity 10.6 qt Not Published Crankcase Capacity 8.5 qt Not Published Transmission / Hydraulic System Capacity 18 gal Not Published Front Axle Fluid Capacity 17.3 qt Not Published ▶ PTO & HitchPTO Type Independent Fully independent PTO Rear 540/750 rpm; 540/1000 rpm (Opt) 540 rpm at 1,958 engine rpm (standard); 540E at 1,592 engine rpm (optional) Mid-PTO Availability Not Published Not Published Category, 3-Point Hitch Category II Category II / I Hitch Lift Capacity 5,115 lb Not Published Hitch Lift Capacity (at 24”) 3,418 lb 3,664 lb Lift Control Type Position/Draft/Elec Mechanical draft control; top link draft sensing ▶ Transmission & DrivetrainTransmission Type Synchro-shuttle 8x8 mechanical synchro shuttle (standard); 8x8 hydraulic power shuttle, 12x12 mechanical synchro shuttle or 12x12 hydraulic power shuttle (optional); creeper available with the power shuttle transmissions No. of Speeds F16 x R16 (Creep interlock) 8F/8R (standard); 12F/12R (optional); 12F/12R or 20F/20R with creeper (optional) Max Travel Speed (Forward) 24.1 mph 20.1 mph (8x8 and 12x12, 20 mph transmissions); 24.1 mph (optional 24 mph 12x12 transmission, 4WD only) Max Travel Speed (Reverse) Not Published 20.1 mph Clutch M: Dry Single Plate; PS: Wet Multi Plate Mechanical dry disc (mechanical shuttle); wet disc (power shuttle) Differential Lock & Limited Slip Options Not Published Mechanical rear differential lock ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Hydrostatic Hydrostatic power steering Brakes Wet disc Hydraulic wet disc Seat Suspension & Adjustability Suspension seat Optional deluxe air suspension seat with fully integrated armrest and 10° swivel to the right; full-size instructor seat with seatbelt Front Axle Type MFWD (4WD) Heavy-duty 2WD front axle; electronic 4WD front axle (optional) Front Axle Rating Not Published Not Published Drawbar Capacity Not Published Not Published ▶ Dimensions & ManeuverabilityOverall Width 76.4 in Not Published Wheelbase 86.1 in 85.8 in (2WD); 83.9 in (4WD) Ground Clearance 18.3 in Not Published Min. Turn Radius without Brakes 162.8 in 134 in (2WD front axle) Height to Top of ROPS Not Published Not Published Height to Top of ROPS (folded) Not Published 76 to 78.9 in Height to Top of Cab Model 103.3 in 94.8 to 97.8 in Overall Length 155.7 in (with 3-point hitch) 151 in ▶ WeightTractor Weight (Base) 6,052 lb (weight with cab) 5,027 lb (2WD ROPS); 5,952 lb (4WD ROPS) Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader 7,904 lb (6,052 + 1,852, computed) Not Published ▶ Tire OptionsTire Size & Options R1 Agricultural, R4 Industrial Not Published R1 Agricultural - Front FSTR 280/85R24 TL (11R24) Not Published R1 Agricultural - Rear FSTR 420/85R30 TL (16.9R30) Not Published R3 Turf - Front Not Published Not Published R3 Turf - Rear Not Published Not Published R4 Industrial - Front Trac Chief 15-19.5 NHS TL 6PR Not Published R4 Industrial - Rear Xtra Grip 18.4-24 NHS TL 8PR Not Published ▶ Loader & AttachmentsQuick Attach Loader System TX75SL: Quick attach mechanism Skid-steer-style or Euro-style quick attach faceplate Loader Model TX75SL Factory-fit: 655TL (NSL or MSL); field-fit: 622TL (NSL), 627TL (MSL) Loader Lift Height TX75SL: 133.8 in 655TL NSL: 126 in; 655TL MSL: 125 in; 622TL: 121 in; 627TL: 121 in Loader Lift Capacity (Full Height) TX75SL: 3,325 lb (at pivot pin) 655TL NSL: 2,478 lb; 655TL MSL: 3,179 lb; 622TL: 1,830 lb; 627TL: 2,557 lb (to max height, at 31.5 in from pivot point) Loader Breakout Force TX75SL: 5,485 lb (at pivot pin, ground level) 655TL NSL: 3,739 lb; 655TL MSL: 4,665 lb; 622TL: 3,042 lb; 627TL: 3,307 lb ▶ WarrantyWarranty Length & Coverage Basic 2 years or 2,000 hours; powertrain 3,000 hours maximum, parts and labor; loaders and backhoes 12 months Not Published
