▶ EngineEngine Manufacturer YANMAR Yanmar Engine Model 3TNM74F 3TNM74F-CJT Engine Type 4-cycle inline, water-cooled diesel, naturally aspirated 3-cylinder, liquid-cooled diesel No. of Cylinders 3 3 Displacement 60.6 in³ 60.6 in³ Rated Engine Speed 3200 rpm 3200 rpm Engine Power (Gross) 21.5 hp 21.5 hp PTO Power 15.6 hp 16 hp Engine Emissions Constraints Not Published Tier 4 Cooling System Type Liquid cooled Liquid-cooled Air Cleaner Not Published Dry with safety element Fuel System Not Published Indirect injection Alternator 40 A 40 A, 12 V ▶ HydraulicsPump Type Not Published Gear Implement Flow 4.3 gpm 3.5 gpm Steering Flow 3.7 gpm 3.5 gpm Total Hydraulic Flow 8.0 gpm (4.3 + 3.7, computed) 7 gpm Overall Hydraulic Pump Flow 8.0 gpm (4.3 + 3.7, computed) 7 gpm Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow Not Published 3.5 gpm implement circuit No. of Standard Remote Valves Not Published Not Published No. of Optional Remote Valves Not Published 1 additional (optional 3rd SCV kit; standard is 2 mid-SCVs) ▶ Fluid CapacityFuel Tank Capacity 6.1 gal 6.3 gal Coolant Capacity 3.0 qt 3.9 qt Crankcase Capacity 3.1 qt 2.9 qt Transmission / Hydraulic System Capacity 4.1 gal 3.25 gal Front Axle Fluid Capacity 3.17 qt 3.0 qt ▶ PTO & HitchPTO Type Independent, hydraulic clutch Independent PTO Rear 554 rpm @ 3,200 engine rpm; 1.4 in OD, 6 splines 540 rpm Mid-PTO Availability Independent mid-PTO, 2,057 rpm at 3,200 engine rpm, SAE 16/32, 15 splines Standard, 2100 rpm Category, 3-Point Hitch Limited Category I Limited Category I Hitch Lift Capacity Not Published 1,177 lb Hitch Lift Capacity (at 24”) 660 lb 758 lb Lift Control Type Position control Select control ▶ Transmission & DrivetrainTransmission Type Hydrostatic transmission, dual range speeds Hydrostatic - 2 range No. of Speeds Infinite forward and reverse (hydrostatic); 2 ranges Infinite (hydrostatic), 2 ranges forward and reverse Max Travel Speed (Forward) 9.5 mph (high range, with R4 tires) 9.1 mph Max Travel Speed (Reverse) 6.6 mph (high range, with R4 tires) 9.1 mph Clutch Not Published Wet disk Differential Lock & Limited Slip Options Differential lock Standard rear differential lock ▶ Chassis, Steering & ControlsFrame Type Full-frame chassis Open center frame with two-post foldable ROPS Steering Hydrostatic power steering Power steering Brakes Wet disc Wet disk, left-hand pedal Seat Suspension & Adjustability Fore-and-aft adjustable operator seat Adjustable seat (no deluxe seat, tilt steering, or floor mat) Front Axle Type Not Published 4WD (MFWD), on-the-go engagement Front Axle Rating Not Published 1,349 lb Drawbar Capacity Not Published 2,017 lb ▶ Dimensions & ManeuverabilityOverall Width 47.3 in (with R4 tires) 47.22 in (R3 tires); 47.32 in (R4 tires) Wheelbase 57.9 in 57.1 in Ground Clearance 6.4 in (with R4 tires) 7.7 in (front axle) Min. Turn Radius without Brakes 7.87 ft 7.4 ft (no brakes, no MFWD) Height to Top of ROPS 82.3 in (with R4 tires) 90 in (ROPS extended, R4 tires) Height to Top of ROPS (folded) 66.3 in (folded ROPS, top of steering wheel, R4 tires) 73 in Height to Top of Cab Model Not Published Not Published Overall Length 102.1 in (with 3-point hitch) 102.6 in (with 3-point hitch) ▶ WeightTractor Weight (Base) 1,537 lb (with ROPS, R4 tires) 1,446 lb Weight with ROPS and Loader 1,962 lb (1,537 + 425, computed) Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options R3 Turf; R4 Industrial Standard R4, optional R3 R1 Agricultural - Front Not Published Not Published R1 Agricultural - Rear Not Published Not Published R3 Turf - Front 18x8.50-10 4PR 18x8.5-10 R3 Turf - Rear 26x12.0-12 4PR 26x12-12 R4 Industrial - Front 18x8.50-10 6PR 18x8.5-10 R4 Industrial - Rear 26x12.0-12 4PR 26x12-12 ▶ Loader & AttachmentsQuick Attach Loader System YL110: YANMAR quick attachment system Tool-free attach and park Loader Model YL110 120R or 120E Loader Lift Height YL110: 71 in to pivot pin (51 in under level bucket) 120R: 72 in; 120E: 71.2 in Loader Lift Capacity (Full Height) YL110: 825 lb at pivot pin 120R (MSL): 680 lb; 120E (NSL): 519 lb (at 19.7 in ahead of pivot) Loader Breakout Force YL110: 1,342 lb at pivot pin 120R: 1,823 lbf (at pivot point) ▶ WarrantyWarranty Length & Coverage Private individual use: basic 24 months or 2,000 hours, powertrain 10 years or 3,000 hours; attachments 1 year Powertrain 6 years, standard at no cost, covers residential and commercial use
