▶ EngineEngine Manufacturer YANMAR Yanmar Engine Model 3TNM74F 3TNV76F Engine Type 4-cycle inline, water-cooled diesel, naturally aspirated 3-cylinder, indirect injection (swirl chamber), water-cooled No. of Cylinders 3 3 Displacement 60.6 in³ 68.0 in³ Rated Engine Speed 3200 rpm 3000 rpm Engine Power (Gross) 21.5 hp 21.5 hp PTO Power 15.6 hp 15 hp Engine Emissions Constraints Not Published Tier 4 Cooling System Type Liquid cooled Water-cooled Air Cleaner Not Published Dry Fuel System Not Published In-line injection pump Alternator 40 A 40 A, 12 V ▶ HydraulicsPump Type Not Published Gear pump, transmission driven Implement Flow 4.3 gpm 4.6 gpm Steering Flow 3.7 gpm 2.1 gpm Total Hydraulic Flow 8.0 gpm (4.3 + 3.7, computed) 6.7 gpm Overall Hydraulic Pump Flow 8.0 gpm (4.3 + 3.7, computed) 6.7 gpm Hydraulic System Type Open center Open center system, position control Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves Not Published None No. of Optional Remote Valves Not Published 1 set (2 quick couplers, optional) ▶ Fluid CapacityFuel Tank Capacity 6.1 gal 6.6 gal Coolant Capacity 3.0 qt 0.9 gal Crankcase Capacity 3.1 qt 0.8 gal Transmission / Hydraulic System Capacity 4.1 gal 3.0 gal (3.4 gal with front-end loader; 4.7 gal with front-end loader and backhoe) Front Axle Fluid Capacity 3.17 qt 0.5 gal ▶ PTO & HitchPTO Type Independent, hydraulic clutch Independent (electro-hydraulic) PTO Rear 554 rpm @ 3,200 engine rpm; 1.4 in OD, 6 splines Standard (540 rpm) Mid-PTO Availability Independent mid-PTO, 2,057 rpm at 3,200 engine rpm, SAE 16/32, 15 splines Standard (2,500 rpm) Category, 3-Point Hitch Limited Category I Category I Hitch Lift Capacity Not Published 992 lb Hitch Lift Capacity (at 24”) 660 lb 728 lb Lift Control Type Position control Position control ▶ Transmission & DrivetrainTransmission Type Hydrostatic transmission, dual range speeds Hydrostatic Drive No. of Speeds Infinite forward and reverse (hydrostatic); 2 ranges 2 ranges Max Travel Speed (Forward) 9.5 mph (high range, with R4 tires) 8.70 mph Max Travel Speed (Reverse) 6.6 mph (high range, with R4 tires) 5.22 mph Clutch Not Published N/A Differential Lock & Limited Slip Options Differential lock Mechanical pedal type ▶ Chassis, Steering & ControlsFrame Type Full-frame chassis Not Published Steering Hydrostatic power steering Hydrostatic power steering Brakes Wet disc Wet, multi-disc Seat Suspension & Adjustability Fore-and-aft adjustable operator seat High-back seat, folding armrest, retractable seat belt, fore-aft adjustment Front Axle Type Not Published Front wheel mechanical assist (4WD) Front Axle Rating Not Published Not Published Drawbar Capacity Not Published Hitch: 882 lb vertical, 3,527 lb horizontal; drawbar with clevis: 772 lb vertical, 3,527 lb horizontal ▶ Dimensions & ManeuverabilityOverall Width 47.3 in (with R4 tires) 47 in Wheelbase 57.9 in 56 in Ground Clearance 6.4 in (with R4 tires) Not Published Min. Turn Radius without Brakes 7.87 ft 7.87 ft Height to Top of ROPS 82.3 in (with R4 tires) 87 in Height to Top of ROPS (folded) 66.3 in (folded ROPS, top of steering wheel, R4 tires) Not Published Height to Top of Cab Model Not Published Not Published Overall Length 102.1 in (with 3-point hitch) 97 in (bumper to link) ▶ WeightTractor Weight (Base) 1,537 lb (with ROPS, R4 tires) 1,433 lb Weight with ROPS and Loader 1,962 lb (1,537 + 425, computed) Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options R3 Turf; R4 Industrial Front 18x8.50-10, rear 26x12.0-12; offered in industrial or turf R1 Agricultural - Front Not Published Not Published R1 Agricultural - Rear Not Published Not Published R3 Turf - Front 18x8.50-10 4PR 18x8.50-10 R3 Turf - Rear 26x12.0-12 4PR 26x12.0-12 R4 Industrial - Front 18x8.50-10 6PR 18x8.50-10 R4 Industrial - Rear 26x12.0-12 4PR 26x12.0-12 ▶ Loader & AttachmentsQuick Attach Loader System YL110: YANMAR quick attachment system LL1102: quick attachment (ISO 24410 attachments only), latch handle with latch pin Loader Model YL110 LL1102; LL1700; LL1001 Loader Lift Height YL110: 71 in to pivot pin (51 in under level bucket) LL1001: 72.6 in (at pivot pin) Loader Lift Capacity (Full Height) YL110: 825 lb at pivot pin LL1001: 902 lb (at pivot pin, maximum height) Loader Breakout Force YL110: 1,342 lb at pivot pin LL1001: 1,836 lb (at pivot pin) ▶ WarrantyWarranty Length & Coverage Private individual use: basic 24 months or 2,000 hours, powertrain 10 years or 3,000 hours; attachments 1 year 6-year limited warranty
