▶ EngineEngine Manufacturer YANMAR Yanmar Engine Model 3TNM74F 3TNM74F Engine Type 4-cycle inline, water-cooled diesel, naturally aspirated Not Published No. of Cylinders 3 3 Displacement 60.6 in³ 60.6 in³ Rated Engine Speed 3200 rpm 3200 rpm Engine Power (Gross) 21.5 hp 21.5 hp PTO Power 15.6 hp 15.2 hp Engine Emissions Constraints Not Published Tier 4 Cooling System Type Liquid cooled Water-cooled Air Cleaner Not Published Single dry Fuel System Not Published Indirect fuel injection Alternator 40 A 40 A, 12 V ▶ HydraulicsPump Type Not Published Single gear pump with flow divider Implement Flow 4.3 gpm 4.59 gpm Steering Flow 3.7 gpm 2.11 gpm Total Hydraulic Flow 8.0 gpm (4.3 + 3.7, computed) 6.71 gpm Overall Hydraulic Pump Flow 8.0 gpm (4.3 + 3.7, computed) 6.71 gpm Hydraulic System Type Open center Live, independent Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves Not Published Not Published No. of Optional Remote Valves Not Published Not Published ▶ Fluid CapacityFuel Tank Capacity 6.1 gal 6.6 gal Coolant Capacity 3.0 qt 3.7 qt Crankcase Capacity 3.1 qt 2.1 qt Transmission / Hydraulic System Capacity 4.1 gal 3.6 gal Front Axle Fluid Capacity 3.17 qt 2.6 qt ▶ PTO & HitchPTO Type Independent, hydraulic clutch Independent PTO Rear 554 rpm @ 3,200 engine rpm; 1.4 in OD, 6 splines 540 rpm Mid-PTO Availability Independent mid-PTO, 2,057 rpm at 3,200 engine rpm, SAE 16/32, 15 splines 2,000 rpm Category, 3-Point Hitch Limited Category I Category I Hitch Lift Capacity Not Published 1,100 lb Hitch Lift Capacity (at 24”) 660 lb 679 lb Lift Control Type Position control Position ▶ Transmission & DrivetrainTransmission Type Hydrostatic transmission, dual range speeds 2-range hydrostatic No. of Speeds Infinite forward and reverse (hydrostatic); 2 ranges 2 Range Max Travel Speed (Forward) 9.5 mph (high range, with R4 tires) 8.4 mph Max Travel Speed (Reverse) 6.6 mph (high range, with R4 tires) Not Published Clutch Not Published Electro-hydraulic PTO clutch assembly (hydrostatic drive, no traction clutch) Differential Lock & Limited Slip Options Differential lock 4WD with differential lock ▶ Chassis, Steering & ControlsFrame Type Full-frame chassis Unit frame: engine, transmission and front axle support bolted together into a rigid assembly Steering Hydrostatic power steering Hydrostatic power steering Brakes Wet disc Wet disc Seat Suspension & Adjustability Fore-and-aft adjustable operator seat Suspension seat with armrests & retractable seat belt Front Axle Type Not Published 4WD, center-pivot reverse Eliot type Front Axle Rating Not Published Not Published Drawbar Capacity Not Published Not Published ▶ Dimensions & ManeuverabilityOverall Width 47.3 in (with R4 tires) 44.5 in Wheelbase 57.9 in 53.1 in Ground Clearance 6.4 in (with R4 tires) 8.3 in Min. Turn Radius without Brakes 7.87 ft 86.6 in Height to Top of ROPS 82.3 in (with R4 tires) 86.6 in Height to Top of ROPS (folded) 66.3 in (folded ROPS, top of steering wheel, R4 tires) Not Published Height to Top of Cab Model Not Published Not Published Overall Length 102.1 in (with 3-point hitch) 94.2 in (with 3-point hitch) ▶ WeightTractor Weight (Base) 1,537 lb (with ROPS, R4 tires) 1,472 lb Weight with ROPS and Loader 1,962 lb (1,537 + 425, computed) Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options R3 Turf; R4 Industrial Titan: R4 Industrial (Std), R3 Turf (Opt), R14 (Opt) R1 Agricultural - Front Not Published n/a R1 Agricultural - Rear Not Published n/a R3 Turf - Front 18x8.50-10 4PR 18x8.5-10 R3 Turf - Rear 26x12.0-12 4PR Not Published R4 Industrial - Front 18x8.50-10 6PR Not Published R4 Industrial - Rear 26x12.0-12 4PR Not Published ▶ Loader & AttachmentsQuick Attach Loader System YL110: YANMAR quick attachment system L72: skid-steer compatible quick-attach Loader Model YL110 L72 Loader Lift Height YL110: 71 in to pivot pin (51 in under level bucket) L72: 72 in (maximum lift height) Loader Lift Capacity (Full Height) YL110: 825 lb at pivot pin L72: 617 lb (to full height) Loader Breakout Force YL110: 1,342 lb at pivot pin L72: 1,285 lb ▶ WarrantyWarranty Length & Coverage Private individual use: basic 24 months or 2,000 hours, powertrain 10 years or 3,000 hours; attachments 1 year Government and non-institutional: basic 24 months or 2,000 hours, powertrain 96 months or 3,000 hours; all other use: basic 24 months or 2,000 hours, powertrain 36 months or 3,000 hours
