▶ EnginePTO Power 18.1 hp 18.2 hp Alternator 40 A, 12 V 40 A Air Cleaner Not Published Dual element with mechanical restriction indicator Engine Type 3-cylinder, naturally aspirated diesel Diesel Fuel System Diesel Indirect injection Displacement 77.2 in³ 77.3 in³ No. of Cylinders 3 3 Rated Engine Speed 3200 rpm 3200 rpm Cooling System Type Liquid cooled Water pump Engine Manufacturer YANMAR Yanmar Engine Power (Gross) 23.9 hp 23.9 hp @ 200 rpm Engine Emissions Constraints Tier 4 Tier 4 ▶ WeightWeight with ROPS and Loader 1,715 lb approx. 1,444 lb shipping weight open station (no loader); operating weight with loader approx. 1,556 lb shipping Weight with Cab and Loader Not Applicable approx. 1,996 lb shipping weight with cab Tractor Weight (Base) — Open station: 1556 lb ▶ WarrantyWarranty Length & Coverage Tractor (private individual usage): 24 months or 2,000 hours; Powertrain (engine and transmission core components): 10 years or 3,000 hours; Attachments: 1-year limited warranty 6-year / 2,000-hour powertrain warranty (standard); PowerGard extended warranty available ▶ HydraulicsPump Type open center Single gear Steering Flow 3.7 US gal/min 3.5 gpm Implement Flow 4.3 US gal/min 3.5 gpm Total Hydraulic Flow 8.0 gpm (implement + steering combined) 6.3 gpm 23.8 lpm Hydraulic System Type Position Control, Open Center Open center Rear Remote Hydraulic Flow 4.3 gpm (implement circuit); 3.7 gpm dedicated to steering 3.5 gpm per pump (implement circuit); total system output 6.3 gpm Overall Hydraulic Pump Flow 8 gpm 3.5 gpm 13.2 lpm No. of Optional Remote Valves Not Published Three No. of Standard Remote Valves 2 (dual rear remote valves, standard) — System Operating Pressure — 2000 psi ▶ PTO & HitchPTO Rear 1.4 in OD, 6 Splines; Independent; 554 RPM @ 3,200 Engine RPM 540 rpm PTO Type Hydraulic Clutch, Independent Independent Lift Control Type Position Control position control Hitch Lift Capacity 1,209 lb 758 lb Mid-PTO Availability SAE16/32, 15 Splines; Independent; 2,057 RPM @ 3,200 Engine RPM 2100 rpm Category, 3-Point Hitch Limited Category 1 Limited Category 1 Hitch Lift Capacity (at 24”) 1,209 lb 758 lb ▶ Tire OptionsR3 Turf - Rear 33x12.5-16.5 4PR 26x12-12 R3 Turf - Front 23x8.50-12 4PR 18x8.50-10 Tire Size & Options R3 Turf or R4 Industrial standard; R4 front: 23x8.50-12 4PR, R4 rear: 12-16.5 10PR Front: R3 Turf 18x8.50-10, R3 Turf Radial 18x8.50-10, R4 18x8.5-10 | Rear: R3 Turf 26x12-12, R4 26x12-12 R4 Industrial - Rear 12-16.5 10PR 26x12-12 R4 Industrial - Front 23x8.50-12 4PR 18x8.5-10 R1 Agricultural - Rear Not Applicable 26x12.00-12 (R4 Industrial standard; R1 Agricultural not a standard listed option) R1 Agricultural - Front Not Applicable 18x8.50-10 (R3 Turf / R4 Industrial listed; R1 Agricultural not a standard listed option) ▶ Fluid CapacityCoolant Capacity 3.0 US qt 0.98 gal Crankcase Capacity 3.6 US qt 0.71 gal Fuel Tank Capacity 6.1 US gal 5.6 gal Front Axle Fluid Capacity 3.7 US gal 0.74 gal Transmission / Hydraulic System Capacity 4.1 US gal 3.3 gal ▶ Loader & AttachmentsLoader Lift Height 79 in. to pivot pin; 58 in. under level bucket 72 in to maximum height at pivot pin (120R loader) Loader Breakout Force 2,090 lb at pivot pin 120R: 1,823 lbf at pivot point; H120: 1,724 lbf at pivot point Quick Attach Loader System Quick Attach 120R Quik-Park Loader System Loader Lift Capacity (Full Height) 1,200 lb at pivot pin 120R: 754 lb at pivot point to max height; H120: 703 lb at pivot point to max height ▶ Transmission & DrivetrainClutch Not Applicable wet disc No. of Speeds 2 ranges Infinite (hydrostatic), 2-range (Hi/Lo) forward and reverse Transmission Type Hydrostatic Transmission, Dual Range Speeds hydrostatic Max Travel Speed (Forward) Low: 0-5.9 mph (0-5.8 mph), High: 0-12.3 mph (0-12.2 mph) 9.1 mph Max Travel Speed (Reverse) Low: 0-4.1 mph (0-4.1 mph), High: 0-8.5 mph (0-8.5 mph) 9.1 mph Differential Lock & Limited Slip Options Differential Lock Differential lock Yes; Limited slip differential No ▶ Chassis, Steering & ControlsBrakes Wet Disk Wet disc (left-hand pedal) Steering Hydrostatic Power Power Frame Type Full Frame Chassis Semi-flat platform; two-post folding ROPS; 4WD with mechanical front-wheel drive Front Axle Type Yanmar-designed 4WD front axle with oscillation Four-wheel drive Drawbar Capacity Not Published — Front Axle Rating Not Published Front 1349 lb Seat Suspension & Adjustability High-back seat with armrests on spring suspension platform; fore-and-aft adjustment; swivels for backhoe operation Premium seat; adjusts fore/aft; seat flips forward; high seat back and armrests; retractable seat belt ▶ Dimensions & ManeuverabilityWheelbase 63.0 in. 57.1 inches 57.1 in Overall Width 54.6 in. with R4 Tires 47 in Ground Clearance 8.5 in. with R4 Tires 7.7 in. Height to Top of ROPS 85.8 in. with R4 Tires — Height to Top of Cab Model Not Applicable — Height to Top of ROPS (folded) 70.4 in. with Folded ROPS, R4 Tires, Top of Steering Wheel — Min. Turn Radius without Brakes 8.5 ft. (2.6 m) 2.51 m 8.2 ft Overall Length with 3-Point Hitch 105.8 in. —
