▶ EngineEngine Manufacturer YANMAR YANMAR Engine Model 3TNV80F 3TNM74F Engine Type 4-cycle inline, water-cooled diesel, naturally aspirated 4-cycle inline, water-cooled diesel, naturally aspirated No. of Cylinders 3 3 Displacement 77.2 in³ 60.6 in³ Rated Engine Speed 3200 rpm 3200 rpm Engine Power (Gross) 23.9 hp 21.5 hp PTO Power 18.1 hp 15.6 hp Engine Emissions Constraints Tier 4 Tier 4 Cooling System Type Liquid cooled Liquid cooled Air Cleaner Not Published Not Published Fuel System Diesel Not Published Alternator 40 A 40 A ▶ HydraulicsPump Type Not Published Dual hydraulic pump Implement Flow 4.3 gpm 4.3 gpm Steering Flow 3.7 gpm 3.7 gpm Total Hydraulic Flow 8.0 gpm (4.3 + 3.7, computed) 8.0 gpm (4.3 + 3.7, computed) Overall Hydraulic Pump Flow 8.0 gpm (4.3 + 3.7, computed) 8.0 gpm (4.3 + 3.7, computed) Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves Not Published Not Published No. of Optional Remote Valves Not Published Not Published ▶ Fluid CapacityFuel Tank Capacity 6.1 gal 6.1 gal Coolant Capacity 3.0 qt 3.0 qt Crankcase Capacity 3.6 qt 3.1 qt Transmission / Hydraulic System Capacity 4.1 gal 4.1 gal Front Axle Fluid Capacity 3.7 qt 3.2 qt ▶ PTO & HitchPTO Type Independent, hydraulic clutch Independent PTO Rear 554 rpm @ 3,200 engine rpm; 1.4 in OD, 6 splines 554 rpm @ 3200 engine rpm Mid-PTO Availability Independent mid-PTO, 2,057 rpm at 3,200 engine rpm, SAE 16/32, 15 splines Independent mid-PTO, 2057 rpm at 3200 engine rpm Category, 3-Point Hitch Limited Category I Limited Category I Hitch Lift Capacity Not Published Not Published Hitch Lift Capacity (at 24”) 1,209 lb 660 lb Lift Control Type Position control Select control ▶ Transmission & DrivetrainTransmission Type Hydrostatic transmission, dual range speeds Hydrostatic transmission No. of Speeds Infinite forward and reverse (hydrostatic); 2 ranges Infinite forward and reverse (hydrostatic); 1 range Max Travel Speed (Forward) 12.3 mph (high range, with R4 tires) 8.6 mph (with R4 tires) Max Travel Speed (Reverse) 8.5 mph (high range, with R4 tires) 6.3 mph (with R4 tires) Clutch Not Published Not Published Differential Lock & Limited Slip Options Differential lock Differential lock pedal (optional) ▶ Chassis, Steering & ControlsFrame Type Full-frame chassis Full-frame chassis Steering Hydrostatic power steering Hydrostatic power steering Brakes Wet disc Wet disc Seat Suspension & Adjustability Fore-and-aft adjustable operator seat Fore-and-aft adjustable operator seat Front Axle Type Yanmar-designed, selectable 4WD front axle Selectable 2WD/4WD Front Axle Rating Not Published Not Published Drawbar Capacity Not Published Not Published ▶ Dimensions & ManeuverabilityOverall Width 54.6 in (with R4 tires) 47.3 in (with R4 tires) Wheelbase 63.0 in 57.9 in Ground Clearance 8.5 in (with R4 tires) 6.4 in (with R4 tires) Min. Turn Radius without Brakes 8.5 ft 7.87 ft Height to Top of ROPS 85.8 in (with R4 tires) 82.3 in (with R4 tires) Height to Top of ROPS (folded) 70.4 in (folded ROPS, top of steering wheel, R4 tires) 66.3 in (folded ROPS, top of steering wheel, R4 tires) Height to Top of Cab Model Not Published Not Published Overall Length 105.8 in (with 3-point hitch) 102.1 in (with 3-point hitch) ▶ WeightTractor Weight (Base) 1,715 lb (with ROPS, R4 tires) 1,537 lb (with ROPS, R4 tires) Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options R3 Turf; R4 Industrial R3 Turf; R4 Industrial R1 Agricultural - Front Not Published Not Published R1 Agricultural - Rear Not Published Not Published R3 Turf - Front 23x8.50-12 4PR 18x8.50-10 4PR R3 Turf - Rear 33x12.5-16.5 4PR 26x12.0-12 4PR R4 Industrial - Front 23x8.50-12 4PR 18x8.50-10 6PR R4 Industrial - Rear 12-16.5 10PR 26x12.0-12 4PR ▶ Loader & AttachmentsQuick Attach Loader System YL210: YANMAR quick attachment system YL110: YANMAR quick attachment system Loader Model YL210 YL110 Loader Lift Height YL210: 79 in to pivot pin (58 in under level bucket) YL110: 71 in to pivot pin (51 in under level bucket) Loader Lift Capacity (Full Height) YL210: 1,200 lb at pivot pin YL110: 825 lb at pivot pin Loader Breakout Force YL210: 2,090 lb at pivot pin YL110: 1,342 lb at pivot pin ▶ WarrantyWarranty Length & Coverage Private individual use: basic 24 months or 2,000 hours, powertrain 10 years or 3,000 hours; attachments 1 year Private individual use: basic 24 months or 2,000 hours, powertrain 10 years or 3,000 hours; attachments 1 year
