▶ EngineEngine Manufacturer YANMAR Yanmar Engine Model 3TNV80F 3TNV80F-CJT Engine Type 4-cycle inline, water-cooled diesel, naturally aspirated 3-cylinder, liquid-cooled diesel No. of Cylinders 3 3 Displacement 77.2 in³ 77.3 in³ Rated Engine Speed 3200 rpm 3200 rpm Engine Power (Gross) 23.9 hp 23.9 hp PTO Power 18.1 hp 18 hp Engine Emissions Constraints Not Published Tier 4 Cooling System Type Liquid cooled Liquid-cooled Air Cleaner Not Published Dry with safety element Fuel System Not Published Indirect injection Alternator 40 A 40 A, 12 V ▶ HydraulicsPump Type Dual hydraulic pump Gear Implement Flow 4.3 gpm 3.3 gpm Steering Flow 3.7 gpm 3.3 gpm Total Hydraulic Flow 8.0 gpm (4.3 + 3.7, computed) 6.5 gpm Overall Hydraulic Pump Flow 8.0 gpm (4.3 + 3.7, computed) 6.5 gpm Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow Not Published 3.5 gpm per pump (implement circuit); total system output 6.3 gpm No. of Standard Remote Valves Not Published Not Published No. of Optional Remote Valves Not Published Three ▶ Fluid CapacityFuel Tank Capacity 6.1 gal 5.6 gal Coolant Capacity 3.0 qt 3.9 qt Crankcase Capacity 3.6 qt 2.9 qt Transmission / Hydraulic System Capacity 4.1 gal 3.25 gal Front Axle Fluid Capacity 3.7 qt 3.0 qt ▶ PTO & HitchPTO Type Independent, hydraulic clutch Independent PTO Rear 554 rpm @ 3,200 engine rpm; 1.4 in OD, 6 splines 540 rpm Mid-PTO Availability Independent mid-PTO, 2,057 rpm @ 3,200 engine rpm, SAE 16/32, 15 splines Standard, 2100 rpm Category, 3-Point Hitch Limited Category I Limited Category I Hitch Lift Capacity Not Published 1177 lb Hitch Lift Capacity (at 24”) 1,209 lb 758 lb Lift Control Type Position control Position control ▶ Transmission & DrivetrainTransmission Type Hydrostatic transmission, dual range speeds Hydrostatic - 2 range No. of Speeds Infinite forward and reverse (hydrostatic); 2 ranges Infinite (hydrostatic), 2 ranges forward and reverse Max Travel Speed (Forward) 13.1 mph (high range, with R4 tires) 9.1 mph Max Travel Speed (Reverse) 9.1 mph (high range, with R4 tires) 9.1 mph Clutch Not Published wet disc Differential Lock & Limited Slip Options Differential lock Standard rear differential lock ▶ Chassis, Steering & ControlsFrame Type Full-frame chassis Semi-flat platform; two-post folding ROPS; 4WD with mechanical front-wheel drive Steering Hydrostatic power steering Power steering Brakes Wet disc Wet disk, left-hand pedal Seat Suspension & Adjustability Fore-and-aft adjustable operator seat Premium seat; adjusts fore/aft; seat flips forward; high seat back and armrests; retractable seat belt Front Axle Type Cast iron, selectable 4WD Four-wheel drive (mechanical front-wheel drive, on-the-go engagement) Front Axle Rating Not Published 1349 lb Drawbar Capacity Not Published 2165 lb ▶ Dimensions & ManeuverabilityOverall Length with 3-Point Hitch 105.8 in 108 in Overall Width 54.1 in (with R4 tires) 47.22 in (R3 tires); 47.32 in (R4 tires) Wheelbase 63.0 in 57.1 in Ground Clearance 9.9 in (with R4 tires) 9.0 in under the front axle (operator's manual); 7.7 in (Deere website) Min. Turn Radius without Brakes 8.5 ft 88.8 in Height to Top of ROPS 87.2 in (with R4 tires) 90 in Height to Top of ROPS (folded) 71.8 in (folded ROPS, top of steering wheel, R4 tires) 73 in Height to Top of Cab Model Not Published Not Published ▶ WeightTractor Weight (Base) 1,830 lb 1444 lb Weight with ROPS and Loader 2,338 lb Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options R3 Turf; R4 Industrial Standard R4, optional R3 R1 Agricultural - Front Not Published Not Published R1 Agricultural - Rear Not Published Not Published R3 Turf - Front 23x8.50-12 4PR 18x8.5-10 R3 Turf - Rear 36x14.00-15 4PR 26x12-12 R4 Industrial - Front 23x8.50-12 4PR 18x8.5-10 R4 Industrial - Rear 14-17.5 6PR 26x12-12 ▶ Loader & AttachmentsQuick Attach Loader System YL210: YANMAR quick attachment system Quik-Park (MSL option on 120R) Loader Model YL210 120R (NSL or MSL) or 120E (D120 and H120 on earlier units) Loader Lift Height YL210: 79 in to pivot pin (58 in under level bucket) 120R (NSL and MSL): 72 in; 120E: 71.2 in; D120 and H120: 71.2 in Loader Lift Capacity (Full Height) YL210: 1,200 lb at pivot pin 120R NSL: 752 lb (49 in bucket) or 704 lb (53 in bucket); 120R MSL: 548 lb (53 in bucket); D120: 825 lb; H120: 836 lb (all at pivot pin, max height) Loader Breakout Force YL210: 2,090 lb at pivot pin 120R NSL: 2008 lbf (49 in bucket) or 1816 lbf (53 in bucket); 120R MSL: 1591 lbf; D120: 1808 lbf; H120: 1819 lbf (at pivot pin) ▶ WarrantyWarranty Length & Coverage Tractor (private individual usage): 24 months or 2,000 hours; Powertrain (engine and transmission core components): 10 years or 3,000 hours; Attachments: 1-year limited warranty 6-Year / 2,000 Hour Limited Powertrain Warranty; standard at no cost, covers residential and commercial use
