▶ EngineEngine Manufacturer YANMAR YANMAR Engine Model 3TNV80F 3TNV88F-EPLST Engine Type 4-cycle inline, water-cooled diesel, naturally aspirated 3-cylinder, liquid-cooled, diesel, naturally aspirated, DI No. of Cylinders 3 3 Displacement 77.2 in³ 100.2 in³ Rated Engine Speed 3200 rpm 2400 rpm Engine Power (Gross) 23.9 hp 23.9 hp PTO Power 18.1 hp 19 hp Engine Emissions Constraints Not Published Tier 4 Cooling System Type Liquid cooled Liquid-cooled Air Cleaner Not Published Dry Fuel System Not Published DI (direct injection) Alternator 40 A 55 A, 12 V ▶ HydraulicsPump Type Dual hydraulic pump Gear pump Implement Flow 4.3 gpm 6.1 gpm Steering Flow 3.7 gpm 4.6 gpm Total Hydraulic Flow 8.0 gpm (4.3 + 3.7, computed) 10.7 gpm Overall Hydraulic Pump Flow 8.0 gpm (4.3 + 3.7, computed) 10.7 gpm Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves Not Published 1 pair No. of Optional Remote Valves Not Published Not Published ▶ Fluid CapacityFuel Tank Capacity 6.1 gal 11.4 gal Coolant Capacity 3.0 qt Not Published Crankcase Capacity 3.6 qt Not Published Transmission / Hydraulic System Capacity 4.1 gal Not Published Front Axle Fluid Capacity 3.7 qt Not Published ▶ PTO & HitchPTO Type Independent, hydraulic clutch Independent PTO Rear 554 rpm @ 3,200 engine rpm; 1.4 in OD, 6 splines Standard (540 rpm) Mid-PTO Availability Independent mid-PTO, 2,057 rpm @ 3,200 engine rpm, SAE 16/32, 15 splines Available (option) Category, 3-Point Hitch Limited Category I Category I Hitch Lift Capacity Not Published 1,808 lb Hitch Lift Capacity (at 24”) 1,209 lb 1433 lb Lift Control Type Position control Position control ▶ Transmission & DrivetrainTransmission Type Hydrostatic transmission, dual range speeds HST No. of Speeds Infinite forward and reverse (hydrostatic); 2 ranges 3 ranges Max Travel Speed (Forward) 13.1 mph (high range, with R4 tires) Not Published Max Travel Speed (Reverse) 9.1 mph (high range, with R4 tires) Not Published Clutch Not Published Not Published Differential Lock & Limited Slip Options Differential lock Mechanical differential lock (pedal) ▶ Chassis, Steering & ControlsFrame Type Full-frame chassis Not Published Steering Hydrostatic power steering Hydrostatic power steering Brakes Wet disc Wet, multi-disc Seat Suspension & Adjustability Fore-and-aft adjustable operator seat Not Published Front Axle Type Cast iron, selectable 4WD Not Published Front Axle Rating Not Published Not Published Drawbar Capacity Not Published Not Published ▶ Dimensions & ManeuverabilityOverall Length with 3-Point Hitch 105.8 in 125 in Overall Width 54.1 in (with R4 tires) 66 in Wheelbase 63.0 in 69 in Ground Clearance 9.9 in (with R4 tires) Not Published Min. Turn Radius without Brakes 8.5 ft 11.5 ft (3.5 m) Height to Top of ROPS 87.2 in (with R4 tires) Not Published Height to Top of ROPS (folded) 71.8 in (folded ROPS, top of steering wheel, R4 tires) Not Published Height to Top of Cab Model Not Published 90 in ▶ WeightTractor Weight (Base) 1,830 lb 3,609 lb Weight with ROPS and Loader 2,338 lb Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options R3 Turf; R4 Industrial R1 agricultural, R4 industrial, R3 turf and VT (versa turf); VT same size as R4 R1 Agricultural - Front Not Published 7-14 R1 Agricultural - Rear Not Published 11.2-24 R3 Turf - Front 23x8.50-12 4PR 25x8.50-14 R3 Turf - Rear 36x14.00-15 4PR 41x14.00-20 R4 Industrial - Front 23x8.50-12 4PR 27x8.50-15 R4 Industrial - Rear 14-17.5 6PR 43x16.00-20 ▶ Loader & AttachmentsQuick Attach Loader System YL210: YANMAR quick attachment system LL3001, LL3002: ISO 24410 Quick Attaching Coupler Loader Model YL210 LL3002 Loader Lift Height YL210: 79 in to pivot pin (58 in under level bucket) LL3002: 94.3 in Loader Lift Capacity (Full Height) YL210: 1,200 lb at pivot pin LL3002: 1,599 lb Loader Breakout Force YL210: 2,090 lb at pivot pin LL3002: 2,962 lb ▶ WarrantyWarranty Length & Coverage Tractor (private individual usage): 24 months or 2,000 hours; Powertrain (engine and transmission core components): 10 years or 3,000 hours; Attachments: 1-year limited warranty 6-year limited powertrain warranty; 2-year bumper-to-bumper warranty
