▶ EngineEngine Manufacturer YANMAR Shibaura Engine Model 3TNV80F N843T-F Engine Type 4-cycle inline, water-cooled diesel, naturally aspirated 3-cylinder diesel, liquid-cooled No. of Cylinders 3 3 Displacement 77.2 in³ 91.5 in³ Rated Engine Speed 3200 rpm 2600 rpm Engine Power (Gross) 23.9 hp 24 hp PTO Power 18.1 hp 19.2 hp Engine Emissions Constraints Not Published Tier 4 Cooling System Type Liquid cooled Liquid-cooled Air Cleaner Not Published Not Published Fuel System Not Published Indirect low-pressure injection Alternator 40 A Not Published ▶ HydraulicsPump Type Dual hydraulic pump Gear-type pump Implement Flow 4.3 gpm Not Published Steering Flow 3.7 gpm 3.8 gpm Total Hydraulic Flow 8.0 gpm (4.3 + 3.7, computed) 10.5 gpm Overall Hydraulic Pump Flow 8.0 gpm (4.3 + 3.7, computed) Not Published Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow Not Published 6.7 gpm No. of Standard Remote Valves Not Published Not Published No. of Optional Remote Valves Not Published Up to 2 ▶ Fluid CapacityFuel Tank Capacity 6.1 gal 10.0 gal Coolant Capacity 3.0 qt 1.32 gal Crankcase Capacity 3.6 qt 1.22 gal Transmission / Hydraulic System Capacity 4.1 gal 10.04 gal Front Axle Fluid Capacity 3.7 qt 1.48 gal ▶ PTO & HitchPTO Type Independent, hydraulic clutch Transmission driven PTO Rear 554 rpm @ 3,200 engine rpm; 1.4 in OD, 6 splines 540 rpm (1-3/8 in 6-spline) Mid-PTO Availability Independent mid-PTO, 2,057 rpm @ 3,200 engine rpm, SAE 16/32, 15 splines Not Published Category, 3-Point Hitch Limited Category I Category I Hitch Lift Capacity Not Published 2,205 lb Hitch Lift Capacity (at 24”) 1,209 lb 1,600 lb Lift Control Type Position control Not Published ▶ Transmission & DrivetrainTransmission Type Hydrostatic transmission, dual range speeds 9 x 3 mechanical shift constant mesh gears or 3-range hydrostatic No. of Speeds Infinite forward and reverse (hydrostatic); 2 ranges Gear: 9F / 3R; HST: 3-range infinite Max Travel Speed (Forward) 13.1 mph (high range, with R4 tires) Not Published Max Travel Speed (Reverse) 9.1 mph (high range, with R4 tires) Not Published Clutch Not Published Gear: dry single disc Differential Lock & Limited Slip Options Differential lock Mechanical engagement via heel pedal ▶ Chassis, Steering & ControlsFrame Type Full-frame chassis Not Published Steering Hydrostatic power steering Power steering Brakes Wet disc Internal wet brakes, single brake pedal on HST, two brake pedals on gear models Seat Suspension & Adjustability Fore-and-aft adjustable operator seat Suspended vinyl seat with retractable seatbelt, fixed steering wheel Front Axle Type Cast iron, selectable 4WD Cast steel 4WD front axle with center drive line and bevel-gear final drives Front Axle Rating Not Published Not Published Drawbar Capacity Not Published Not Published ▶ Dimensions & ManeuverabilityOverall Length with 3-Point Hitch 105.8 in 116.0 in (w/o 3-point linkage) (without 3-point hitch) Overall Width 54.1 in (with R4 tires) 52.4 in Wheelbase 63.0 in 65.9 in Ground Clearance 9.9 in (with R4 tires) Not Published Min. Turn Radius without Brakes 8.5 ft Not Published Height to Top of ROPS 87.2 in (with R4 tires) 97.6 in Height to Top of ROPS (folded) 71.8 in (folded ROPS, top of steering wheel, R4 tires) 63.8 in Height to Top of Cab Model Not Published Not Published ▶ WeightTractor Weight (Base) 1,830 lb HST: 2,657 lb Weight with ROPS and Loader 2,338 lb Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options R3 Turf; R4 Industrial Not Published R1 Agricultural - Front Not Published Not Published R1 Agricultural - Rear Not Published Not Published R3 Turf - Front 23x8.50-12 4PR Not Published R3 Turf - Rear 36x14.00-15 4PR Not Published R4 Industrial - Front 23x8.50-12 4PR Not Published R4 Industrial - Rear 14-17.5 6PR Not Published ▶ Loader & AttachmentsQuick Attach Loader System YL210: YANMAR quick attachment system L105E: skid steer or pin-type implement attachments Loader Model YL210 L105E Loader Lift Height YL210: 79 in to pivot pin (58 in under level bucket) L105E: 95.7 in Loader Lift Capacity (Full Height) YL210: 1,200 lb at pivot pin L105E: 1,210 lb Loader Breakout Force YL210: 2,090 lb at pivot pin L105E: 1,460 lb ▶ WarrantyWarranty Length & Coverage Tractor (private individual usage): 24 months or 2,000 hours; Powertrain (engine and transmission core components): 10 years or 3,000 hours; Attachments: 1-year limited warranty 5-year powertrain warranty
