▶ EnginePTO Power 18.1 hp 18.8 hp Alternator 40 A, 12 V 40 A, 12 V Air Cleaner Not Published Single element Engine Type 3-cylinder, naturally aspirated diesel Water cooled, 4-cycle Diesel Fuel System Not Published Indirect Fuel Injection Displacement 77.3 in³ 77.3 in³ No. of Cylinders 3 3 Rated Engine Speed 3200 rpm 3000 rpm Cooling System Type Liquid cooled Water cooled, forced circulation Engine Manufacturer YANMAR Yanmar Engine Power (Gross) 23.9 hp 23.9 hp Engine Emissions Constraints Not Published Tier 4 Engine Model — 3TNV80F-SDKTFF ▶ WeightWeight with ROPS and Loader 2,338 lb 2,091 lb Weight with Cab and Loader Not Applicable Not Published ▶ WarrantyWarranty Length & Coverage Tractor: 24 months or 2,000 hours; Powertrain: 10 years or 3,000 hours; Attachments: 1-year limited warranty Full-machine: 24 months/2,000 hours; Powertrain: 96 months/3,000 hours (whichever comes first) ▶ HydraulicsPump Type Not Published Gear Pump Steering Flow 3.7 gpm Not Published Implement Flow 4.3 gpm Not Published Total Hydraulic Flow 8 gpm 6.95 gpm Hydraulic System Type Open center Hydrostatic Rear Remote Hydraulic Flow Not Applicable Not Published Overall Hydraulic Pump Flow 8 gpm 26.3 lpm (6.95 US gpm) No. of Optional Remote Valves Not Published NOT FOUND — no source explicitly states the number of optional remote valves available for the RK24. Sources confirm 1 standard rear remote set is included, but do not specify optional add-on valve counts. No. of Standard Remote Valves Not Published 1 ▶ PTO & HitchPTO Rear 554 rpm @ 3,200 engine rpm 540 rpm PTO Type Independent (hydraulic clutch) Independent PTO Lift Control Type Position control Position control Hitch Lift Capacity Not Published 1,323 lb Mid-PTO Availability Standard Standard, 2,000 rpm @ 2,875 rpm Category, 3-Point Hitch Limited Category I Category I Hitch Lift Capacity (at 24”) 1,209 lb Not Published ▶ Tire OptionsR3 Turf - Rear 36x14.00-15 4PR 29X12.5-15 R3 Turf - Front 23x8.50-12 4PR 20X8-10 Tire Size & Options R3 Turf; R4 Industrial R4 Industrial (Std), R3 Turf (Opt) R1 Ag (Opt), Goodyear R14 (Opt) R4 Industrial - Rear 14-17.5 6PR 27X12.5-15 R4 Industrial - Front 23x8.50-12 4PR 20X8-10 R1 Agricultural - Rear Not Applicable 9.5-16 R1 Agricultural - Front Not Applicable 6-12 ▶ Fluid CapacityCoolant Capacity 3.0 qt 3.6 ℓ (0.96US gal) Crankcase Capacity 3.6 qt 2.7 ℓ ( 0.71 US gal) Fuel Tank Capacity 6.1 gal 5.81 gal Front Axle Fluid Capacity 3.7 qt 3.2ℓ (0.85 US gal) Transmission / Hydraulic System Capacity 4.1 gal 14.5ℓ (3.83 US gal) ▶ Loader & AttachmentsLoader Lift Height 79 in 75.3 Loader Breakout Force 2,090 lb 1,680 lb Quick Attach Loader System YL210: YANMAR quick attachment system Skid-Steer Compatible Quick-Attach Loader Lift Capacity (Full Height) 1,200 lb 947 lb ▶ Transmission & DrivetrainClutch Not Applicable Not Published No. of Speeds Unlimited (hydrostatic); 2 ranges (High/Low) 2 Range (High/Low) Transmission Type Hydrostatic transmission, dual range speeds Hydraulic + Mechanical H/L with constant-mesh Max Travel Speed (Forward) 13.1 mph 10.5 mph Max Travel Speed (Reverse) 9.1 mph Not Published Differential Lock & Limited Slip Options Differential lock Differential lock (bevel gears with diff-lock) ▶ Chassis, Steering & ControlsBrakes Wet disc Wet Disc, Foot operated, independent with provision of inter lock for simultaneous operation Steering Hydrostatic power steering Hydrostatic Power steering system Frame Type Full-frame chassis Not Published Front Axle Type Not Published Center-pivot, reverse Eliot type Drawbar Capacity Not Published Not Published Front Axle Rating Not Published Not Published Seat Suspension & Adjustability Not Published Not Published ▶ Dimensions & ManeuverabilityWheelbase 63 in 57.5 in Overall Width 54.1 in 45.8 in Ground Clearance 9.9 in 9.4 in Height to Top of ROPS 87.2 in 91.3 in Height to Top of Cab Model Not Applicable Not Published Height to Top of ROPS (folded) 71.8 in Not Published Min. Turn Radius without Brakes 8.5 ft (2.6 m) Not Published Overall Length with 3-Point Hitch 105.8 in 100.5 in ▶ ITC Company AccessoriesAccessories that fit None tagged yet
