▶ EngineEngine Manufacturer YANMAR YANMAR Engine Model 3TNV80F 3TNV80F Engine Type 4-cycle inline, water-cooled diesel, naturally aspirated 4-cycle inline, water-cooled diesel, naturally aspirated No. of Cylinders 3 3 Displacement 77.2 in³ 77.2 in³ Rated Engine Speed 3200 rpm 3200 rpm Engine Power (Gross) 23.9 hp 23.9 hp PTO Power 18.1 hp 18.1 hp Engine Emissions Constraints Not Published Tier 4 Cooling System Type Liquid cooled Liquid cooled Air Cleaner Not Published Not Published Fuel System Not Published Diesel Alternator 40 A 40 A ▶ HydraulicsPump Type Dual hydraulic pump Not Published Implement Flow 4.3 gpm 4.3 gpm Steering Flow 3.7 gpm 3.7 gpm Total Hydraulic Flow 8.0 gpm (4.3 + 3.7, computed) 8.0 gpm (4.3 + 3.7, computed) Overall Hydraulic Pump Flow 8.0 gpm (4.3 + 3.7, computed) 8.0 gpm (4.3 + 3.7, computed) Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves Not Published Not Published No. of Optional Remote Valves Not Published Not Published ▶ Fluid CapacityFuel Tank Capacity 6.1 gal 6.1 gal Coolant Capacity 3.0 qt 3.0 qt Crankcase Capacity 3.6 qt 3.6 qt Transmission / Hydraulic System Capacity 4.1 gal 4.1 gal Front Axle Fluid Capacity 3.7 qt 3.7 qt ▶ PTO & HitchPTO Type Independent, hydraulic clutch Independent, hydraulic clutch PTO Rear 554 rpm @ 3,200 engine rpm; 1.4 in OD, 6 splines 554 rpm @ 3,200 engine rpm; 1.4 in OD, 6 splines Mid-PTO Availability Independent mid-PTO, 2,057 rpm @ 3,200 engine rpm, SAE 16/32, 15 splines Independent mid-PTO, 2,057 rpm @ 3,200 engine rpm, SAE 16/32, 15 splines Category, 3-Point Hitch Limited Category I Limited Category I Hitch Lift Capacity Not Published Not Published Hitch Lift Capacity (at 24”) 1,209 lb 1,209 lb Lift Control Type Position control Position control ▶ Transmission & DrivetrainTransmission Type Hydrostatic transmission, dual range speeds Hydrostatic transmission, dual range speeds No. of Speeds Infinite forward and reverse (hydrostatic); 2 ranges Infinite forward and reverse (hydrostatic); 2 ranges Max Travel Speed (Forward) 13.1 mph (high range, with R4 tires) 12.3 mph (high range, with R4 tires) Max Travel Speed (Reverse) 9.1 mph (high range, with R4 tires) 8.5 mph (high range, with R4 tires) Clutch Not Published Not Published Differential Lock & Limited Slip Options Differential lock Differential lock ▶ Chassis, Steering & ControlsFrame Type Full-frame chassis Full-frame chassis Steering Hydrostatic power steering Hydrostatic power steering Brakes Wet disc Wet disc Seat Suspension & Adjustability Fore-and-aft adjustable operator seat Fore-and-aft adjustable operator seat Front Axle Type Cast iron, selectable 4WD Yanmar-designed 4WD front axle with oscillation Front Axle Rating Not Published Not Published Drawbar Capacity Not Published Not Published ▶ Dimensions & ManeuverabilityOverall Length with 3-Point Hitch 105.8 in 105.8 in Overall Width 54.1 in (with R4 tires) 54.6 in (with R4 tires) Wheelbase 63.0 in 63.0 in Ground Clearance 9.9 in (with R4 tires) 8.5 in (with R4 tires) Min. Turn Radius without Brakes 8.5 ft 8.5 ft Height to Top of ROPS 87.2 in (with R4 tires) 85.8 in (with R4 tires) Height to Top of ROPS (folded) 71.8 in (folded ROPS, top of steering wheel, R4 tires) 70.4 in (folded ROPS, top of steering wheel, R4 tires) Height to Top of Cab Model Not Published Not Published ▶ WeightTractor Weight (Base) 1,830 lb 1,715 lb Weight with ROPS and Loader 2,338 lb Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options R3 Turf; R4 Industrial R3 Turf; R4 Industrial R1 Agricultural - Front Not Published Not Published R1 Agricultural - Rear Not Published Not Published R3 Turf - Front 23x8.50-12 4PR 23x8.50-12 4PR R3 Turf - Rear 36x14.00-15 4PR 33x12.5-16.5 4PR R4 Industrial - Front 23x8.50-12 4PR 23x8.50-12 4PR R4 Industrial - Rear 14-17.5 6PR 12-16.5 10PR ▶ Loader & AttachmentsQuick Attach Loader System YL210: YANMAR quick attachment system YL210: YANMAR quick attachment system Loader Model YL210 YL210 Loader Lift Height YL210: 79 in to pivot pin (58 in under level bucket) YL210: 79 in to pivot pin (58 in under level bucket) Loader Lift Capacity (Full Height) YL210: 1,200 lb at pivot pin YL210: 1,200 lb at pivot pin Loader Breakout Force YL210: 2,090 lb at pivot pin YL210: 2,090 lb at pivot pin ▶ WarrantyWarranty Length & Coverage Tractor (private individual usage): 24 months or 2,000 hours; Powertrain (engine and transmission core components): 10 years or 3,000 hours; Attachments: 1-year limited warranty Tractor (private individual usage): 24 months or 2,000 hours; Powertrain (engine and transmission core components): 10 years or 3,000 hours; Attachments: 1-year limited warranty
