Yanmar SA425DHX vs TYM T254 | Side-by-side comparison | ITC Resource Center
ITC Resource Center
Tractor Comparison
Pick up to 4tractors and we'll lay every spec sheet out side by side. Same data we publish on the individual model pages, stacked in columns so you can compare numbers at a glance.
No photo
—
YanmarSA425DHX
No photo
—
TYMT254
Comparison loaded for 2 tractors.
Spec
YanmarSA425DHX
TYMT254
PTO Power
18.1 hp (13.5 kW)
18.8 hp (14.0 kW)
Alternator
12 V, 40 A
12 V, 40 A
Air Cleaner
Not Published
Single dry
Engine Type
3-cylinder, naturally aspirated diesel
3-cylinder, naturally aspirated diesel
Fuel System
Not Published
IDI
Displacement
77.2 in³ (1,266 cc)
77.3 in³ (1267 cc)
No. of Cylinders
3
3
Rated Engine Speed
3,200 rpm
3,000 rpm
Cooling System Type
Liquid cooled
Water-cooled
Engine Manufacturer
YANMAR
Yanmar
Engine Emissions Constraints
Not Published
Tier 4
Engine Power (Gross vs. Net HP)
Gross: 23.9 hp (17.8 kW); Net: 21.7 hp (16.2 kW)
Gross: 23.9 hp (17.8 kW)
Tractor Weight with Loader
2,338 lb (1,061 kg)
Not Published
Weight with Cab and Loader
Not Applicable
Not Published
Weight with ROPS and Loader
2,338 lb (1,061 kg)
Not Published
Pump Type
Not Published
Single gear pump
Steering Flow
14.1 L/min (3.7 gpm)
10.5 L/min (2.8 gpm)
Implement Flow
16.1 L/min (4.3 gpm)
15.8 L/min (4.2 gpm)
Total Hydraulic Flow
30.2 L/min (8.0 gpm)
26.3 L/min (6.9 gpm)
Hydraulic System Type
Open center
Open center
Rear Remote Hydraulic Flow
Not Published
Not Published
Overall Hydraulic Pump Flow
30.2 L/min (8.0 gpm)
26.3 L/min (6.9 gpm)
No. of Optional Remote Valves
Not Published
1
No. of Standard Remote Valves
Not Published
0
R3 Turf - Rear
36x14.00-15 4PR
29x12.50-15
R3 Turf - Front
23x8.50-12 4PR
20x8.00-10
Tire Size & Options
R3 Turf; R4 Industrial
R1 Agricultural, R3 Turf, R4 Industrial; R4 Lg Industrial (optional)
R4 Industrial - Rear
14-17.5 6PR
27x12.5-15; 12-16.5
R4 Industrial - Front
23x8.50-12 4PR
20x8.00-10; 23x8.50-12
R1 Agricultural - Rear
Not Applicable
9.5-16
R1 Agricultural - Front
Not Applicable
6.0-12
PTO Rear
554 rpm @ 3,200 engine rpm
540 rpm
PTO Type
Independent (hydraulic clutch)
Independent
Lift Control Type
Position control
Position control
Hitch Lift Capacity
Not Published
1,214 lb (551 kg)
Mid-PTO Availability
Standard
Available
Category, 3-Point Hitch
Limited Category I
Category I (Narrow)
Hitch Lift Capacity (at 24”)
1,209 lb (548 kg)
1,101 lb (499 kg)
Rear 3-Point Hitch Lift Capacity
Not Published
1,214 lb (551 kg)
Coolant Capacity
3.0 qt (2.8 L)
3.8 qt (3.6 L)
Crankcase Capacity
3.6 qt (3.4 L)
2.9 qt (2.7 L)
Fuel Tank Capacity
6.1 gal (23.0 L)
5.8 gal (22 L)
Front Axle Fluid Capacity
3.7 qt (3.5 L)
3.7 qt (3.5 L)
Transmission / Hydraulic System Capacity
4.1 gal (15.5 L)
3.7 gal (14 L)
Loader Lift Height
79 in (2,000 mm)
75 in (1905 mm)
Loader Breakout Force
2,090 lb (950 kg)
1,680 lb (720 kg)
Price for Backhoe Option
B65: $10,668
TB60
Price for Mid-Mount Mower
M60: 3,862
MM60R
Quick Attach Loader System
YL210: YANMAR quick attachment system
TX25P: Quick attach mechanism
Loader Lift Capacity (Full Height)
1,200 lb (545 kg)
948 lb (430 kg)
Clutch
Not Applicable
Not applicable
No. of Speeds
Unlimited (hydrostatic); 2 ranges (High/Low)
Infinite 2-Range
Transmission Type
Hydrostatic transmission, dual range speeds
HST
Max Travel Speed (Forward)
13.1 mph (21.0 km/h)
11.0 mph (17.7 km/h)
Max Travel Speed (Reverse)
9.1 mph (14.7 km/h)
Not Published
Differential Lock & Limited Slip Options
Differential lock
Differential lock
Brakes
Wet disc
Wet disc
Steering
Hydrostatic power steering
Hydrostatic
Frame Type
Full-frame chassis
Not Published
Front Axle Type
Not Published
Not Published
Drawbar Capacity
Not Published
Not Published
Front Axle Rating
Not Published
Not Published
Seat Suspension & Adjustability
Not Published
Ergonomic seating
Wheelbase
63.0 in (1,600 mm)
57.5 in (1460 mm)
Overall Width
54.1 in (1,373 mm)
45.8 in (1164 mm)
Ground Clearance
9.9 in (249 mm)
9.4 in (240 mm)
Height to Top of ROPS
87.2 in (2,215 mm)
91.3 in (2320 mm)
Height to Top of Cab Model
Not Published
Not Published
Height to Top of ROPS (folded)
71.8 in (1,824 mm)
Not Published
Min. Turn Radius without Brakes
8.5 ft (2.6 m)
100 in (2540 mm)
Overall Length with 3-Point Hitch
105.8 in (2,688 mm)
100.5 in (2553 mm)
Financing Options
See Exclusive Offers (promotions vary)
0% financing for up to 72 months and instant cash rebates. Contact dealer for more information.
Base Price with Loader
$24,599
Not Published
Warranty Length & Coverage
Tractor: 24 months or 2,000 hours; Powertrain: 10 years or 3,000 hours; Attachments: 1-year limited warranty
Up to 2 years or until the 2,000 hours mark, bumper-to-bumper warranty; 3000 hours maximum coverage period for parts and labour on drivetrains or powertrains; 12-months warranty period for implements, including loaders and backhoes.
