▶ EngineEngine Manufacturer Yanmar Yanmar Engine Model Not Published 3TNV86CT-NJT2 Engine Type Not Published Diesel No. of Cylinders Not Published 3 Displacement Not Published 95.7 in³ Rated Engine Speed 3000 rpm 2500 rpm Engine Power (Gross) 36.9 hp 36.7 hp PTO Power 28.2 hp 30 hp Engine Emissions Constraints Not Published Tier 4 Cooling System Type Not Published Water pump Air Cleaner Not Published Dry type with safety element Fuel System Not Published High pressure common rail direct injection Alternator Not Published 55 A, 12 V ▶ HydraulicsPump Type Not Published Implement/steering pump: Tandem gear; hydrostatic pump: PV axial piston Implement Flow 6.1 gpm 5.3 gpm Steering Flow 4.4 gpm 4.0 gpm Total Hydraulic Flow 10.5 gpm 9.3 gpm Overall Hydraulic Pump Flow 10.5 gpm 9.3 gpm Hydraulic System Type Not Published Open center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves Not Published Not Published No. of Optional Remote Valves 1 or 2 Up to 2 (optional) ▶ Fluid CapacityFuel Tank Capacity 9.0 gal 7.5 gal Coolant Capacity Not Published 1.37 gal Crankcase Capacity Not Published 4.5 qt Transmission / Hydraulic System Capacity Not Published 5.5 gal Front Axle Fluid Capacity Not Published 1.0 gal ▶ PTO & HitchPTO Type Independent Independent PTO Rear 540 rpm 540 rpm Mid-PTO Availability Not Published Optional Category, 3-Point Hitch Category I Category I Hitch Lift Capacity 2,639 lb 1,356 lb Hitch Lift Capacity (at 24”) 1,558 lb 1356 lb Lift Control Type Not Published Position control ▶ Transmission & DrivetrainTransmission Type Synchro Shuttle Hydrostatic transmission (HST) No. of Speeds Not Published Not Published Max Travel Speed (Forward) Not Published Not Published Max Travel Speed (Reverse) Not Published Not Published Clutch Dry Single Plate Not Published Differential Lock & Limited Slip Options Rear differential lock (foot pedal engagement) Differential lock: Yes; Limited slip: Not Published ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Not Published Power steering Brakes Not Published Wet disk Seat Suspension & Adjustability Comfortable, adjustable operator seat Not Published Front Axle Type Selectable 2WD/4WD engagement Not Published Front Axle Rating Not Published 1760 lb Drawbar Capacity Not Published 880 lb ▶ Dimensions & ManeuverabilityOverall Length with 3-Point Hitch Not Published 115.9 in Overall Width Not Published 56.9 in (min. rear tread, standard R1 tires); 61.7 in (max. rear tread, larger R4 tires) Wheelbase Not Published 62.8 in Ground Clearance 12.8 in 12.7 in (R4 tires) Min. Turn Radius without Brakes Not Published 9.4 ft (2.9 m) Height to Top of ROPS Not Published 95.3 in Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model Not Published Not Published ▶ WeightTractor Weight (Base) 3,020 lb 2266 lb Weight with ROPS and Loader Not Published 2972 lb Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options Not Published R1 Bar, R3 Turf, R4 Industrial R1 Agricultural - Front Not Published 7-14 R1 Agricultural - Rear Not Published 11.2-24 R3 Turf - Front Not Published 27X8.50-15 R3 Turf - Rear Not Published 41X14-20 R4 Industrial - Front Not Published 25X8.50-14 or 27X8.50-15 R4 Industrial - Rear Not Published 15.00-19.5 or 43X16-20 ▶ Loader & AttachmentsQuick Attach Loader System Not Published Quick-change attachment carrier Loader Model RL505 D160 Loader Lift Height RL505: 101.5 in 84 in Loader Lift Capacity (Full Height) RL505: 2,116 lb 1,186 lb Loader Breakout Force RL505: 3,435 lb 1,704 lb ▶ WarrantyWarranty Length & Coverage Tractor: 24 months or 2,000 hours; Powertrain: 10 years or 3,000 hours 6-year/2,000-hour powertrain; 2-year/2,000-hour basic (full machine)
