▶ EngineEngine Manufacturer Yanmar Kubota Engine Model Not Published D1803-CR-E4-GL2 Engine Type Not Published Liquid-cooled, 4-cycle multi valve, diesel, Naturally Aspirated No. of Cylinders Not Published 3 Displacement Not Published 111.4 in³ Rated Engine Speed 3000 rpm 2600 rpm Engine Power (Gross) 36.9 hp 37 hp PTO Power 28.2 hp 28 hp Engine Emissions Constraints Not Published Tier 4 Cooling System Type Not Published Liquid-cooled Air Cleaner Not Published Dry paper, dual element Fuel System Not Published Electronic CRS (Common Rail System) Alternator Not Published 40 A, 12 V ▶ HydraulicsPump Type Not Published Tandem pump - gear type Implement Flow 6.1 gpm 8.1 gpm Steering Flow 4.4 gpm 4.7 gpm Total Hydraulic Flow 10.5 gpm 12.8 gpm Overall Hydraulic Pump Flow 10.5 gpm 12.8 gpm Hydraulic System Type Not Published Open center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves Not Published None standard (up to 3 optional) No. of Optional Remote Valves 1 or 2 Optional, up to 3 (double-acting valve or float detent valve options, any position) ▶ Fluid CapacityFuel Tank Capacity 9.0 gal 13.5 gal Coolant Capacity Not Published 7.9 qt Crankcase Capacity Not Published 7.1 qt Transmission / Hydraulic System Capacity Not Published 11.1 gal Front Axle Fluid Capacity Not Published 6.9 qt ▶ PTO & HitchPTO Type Independent Live independent (hydraulic clutch) PTO Rear 540 rpm 540 rpm @ 2476 engine rpm Mid-PTO Availability Not Published Optional Category, 3-Point Hitch Category I SAE Category I Hitch Lift Capacity 2,639 lb 3,750 lb Hitch Lift Capacity (at 24”) 1,558 lb 2646 lb Lift Control Type Not Published Position control ▶ Transmission & DrivetrainTransmission Type Synchro Shuttle Hydrostatic No. of Speeds Not Published 3-Range, 6 speeds (H-DS), infinitely variable in each Max Travel Speed (Forward) Not Published 16.5 mph Max Travel Speed (Reverse) Not Published 14.9 mph Clutch Dry Single Plate Not Published Differential Lock & Limited Slip Options Rear differential lock (foot pedal engagement) Rear differential lock, standard ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Not Published Hydrostatic power steering Brakes Not Published Wet disc type, mechanically activated Seat Suspension & Adjustability Comfortable, adjustable operator seat Deluxe suspension seat with swivel (standard); Air-Ride seat (optional) Front Axle Type Selectable 2WD/4WD engagement 4WD: Bevel gear front axle, non-adjustable tread spacing Front Axle Rating Not Published Not Published Drawbar Capacity Not Published 1,433 lb ▶ Dimensions & ManeuverabilityOverall Length with 3-Point Hitch Not Published 115.0 in (without 3-point hitch) Overall Width Not Published 59.8 in Wheelbase Not Published 71.1 in Ground Clearance 12.8 in 13.5 in Min. Turn Radius without Brakes Not Published 8.9 ft (with brake applied) Height to Top of ROPS Not Published 97.2 in Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model Not Published Not Published ▶ WeightTractor Weight (Base) 3,020 lb 3505 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options Not Published R1 Agricultural; R3 Turf; R4 Industrial R1 Agricultural - Front Not Published 7.0-16 R1 Agricultural - Rear Not Published 12.4-24 R3 Turf - Front Not Published 27x10.50-15 R3 Turf - Rear Not Published 41x18LL-16.1 R4 Industrial - Front Not Published 10-16.5 R4 Industrial - Rear Not Published 420/70-24 ▶ Loader & AttachmentsQuick Attach Loader System Not Published LA555: Mechanical 2-Lever Quick Coupler (standard); LA805: Mechanical 2-Lever Quick Coupler (standard); Hydraulic 2-Lever Quick Coupler (optional); Single Lever Hose Quick Coupler (optional) Loader Model RL505 LA555 or LA805 Loader Lift Height RL505: 101.5 in LA555: 96.4 in; LA805: 104.7 in Loader Lift Capacity (Full Height) RL505: 2,116 lb LA555: 1190 lb; LA805: 1715 lb Loader Breakout Force RL505: 3,435 lb LA555: 2030 lb; LA805: 2549 lb (19.7 in forward of pivot pin) ▶ WarrantyWarranty Length & Coverage Tractor: 24 months or 2,000 hours; Powertrain: 10 years or 3,000 hours Non-Commercial Home & Residential Use - Basic Standard Limited: 24 months or 1500 hours; Limited Powertrain: 72 months or 2000 hours. Commercial Use - Basic Standard Limited: 24 months or 1500 hours; Limited Powertrain: 36 months or 2000 hours. ▶ ITC Company AccessoriesAccessories that fit None tagged yet
