▶ EngineEngine Manufacturer Yanmar Yanmar Engine Model Not Published Not Published Engine Type Not Published Not Published No. of Cylinders Not Published Not Published Displacement Not Published Not Published Rated Engine Speed 3000 rpm 3000 rpm Engine Power (Gross) 36.9 hp 36.9 hp PTO Power 28.2 hp 27.5 hp Engine Emissions Constraints Not Published Not Published Cooling System Type Not Published Not Published Air Cleaner Not Published Not Published Fuel System Not Published Not Published Alternator Not Published Not Published ▶ HydraulicsPump Type Not Published Not Published Implement Flow 6.1 gpm 6.1 gpm Steering Flow 4.4 gpm 4.4 gpm Total Hydraulic Flow 10.5 gpm 10.5 gpm Overall Hydraulic Pump Flow 10.5 gpm 10.5 gpm Hydraulic System Type Not Published Not Published Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves Not Published Not Published No. of Optional Remote Valves 1 or 2 1 or 2 ▶ Fluid CapacityFuel Tank Capacity 9.0 gal 9.0 gal Coolant Capacity Not Published Not Published Crankcase Capacity Not Published Not Published Transmission / Hydraulic System Capacity Not Published Not Published Front Axle Fluid Capacity Not Published Not Published ▶ PTO & HitchPTO Type Independent Independent PTO Rear 540 rpm 540 rpm Mid-PTO Availability Not Published Not Published Category, 3-Point Hitch Category I Category I Hitch Lift Capacity 2,639 lb 2,639 lb Hitch Lift Capacity (at 24”) 1,558 lb 1,558 lb Lift Control Type Not Published Not Published ▶ Transmission & DrivetrainTransmission Type Synchro Shuttle Hydrostatic No. of Speeds Not Published Not Published Max Travel Speed (Forward) Not Published Not Published Max Travel Speed (Reverse) Not Published Not Published Clutch Dry Single Plate Not Published Differential Lock & Limited Slip Options Rear differential lock (foot pedal engagement) Rear differential lock (foot pedal engagement) ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Not Published Not Published Brakes Not Published Dual brakes Seat Suspension & Adjustability Comfortable, adjustable operator seat Not Published Front Axle Type Selectable 2WD/4WD engagement Selectable 2WD/4WD engagement Front Axle Rating Not Published Not Published Drawbar Capacity Not Published Not Published ▶ Dimensions & ManeuverabilityOverall Width Not Published Not Published Wheelbase Not Published Not Published Ground Clearance 12.8 in 12.8 in Min. Turn Radius without Brakes Not Published Not Published Height to Top of ROPS Not Published Not Published Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model Not Published Not Published Overall Length Not Published Not Published ▶ WeightTractor Weight (Base) 3,020 lb 3,020 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options Not Published Not Published R1 Agricultural - Front Not Published Not Published R1 Agricultural - Rear Not Published Not Published R3 Turf - Front Not Published Not Published R3 Turf - Rear Not Published Not Published R4 Industrial - Front Not Published Not Published R4 Industrial - Rear Not Published Not Published ▶ Loader & AttachmentsQuick Attach Loader System Not Published Not Published Loader Model RL505 RL505 Loader Lift Height RL505: 101.5 in (at pivot pin) RL505: 101.5 in (at pivot pin) Loader Lift Capacity (Full Height) RL505: 2,116 lb (at pivot pin) RL505: 2,116 lb (at pivot pin) Loader Breakout Force RL505: 3,435 lb (at pivot pin, ground level) RL505: 3,435 lb (at pivot pin, ground level) ▶ WarrantyWarranty Length & Coverage Basic 24 months or 2,000 hours; powertrain 10 years or 3,000 hours Basic 24 months or 2,000 hours; powertrain 10 years or 3,000 hours
