▶ EngineEngine Manufacturer Yanmar YANMAR Engine Model Not Published 3TNV88C Engine Type Not Published 3-cylinder, naturally aspirated diesel No. of Cylinders Not Published 3 Displacement Not Published 100.1 in³ Rated Engine Speed 3000 rpm 2800 rpm Engine Power (Gross) 36.9 hp 34.2 hp PTO Power 28.2 hp 27 hp Engine Emissions Constraints Not Published Tier 4 Cooling System Type Not Published Liquid cooled Air Cleaner Not Published Dual stage cyclonic (resin 5.5 in.) Fuel System Not Published Common rail direct injection Alternator Not Published 55 A, 12 V ▶ HydraulicsPump Type Not Published Not Published Implement Flow 6.1 gpm 7.1 gpm Steering Flow 4.4 gpm 4.1 gpm Total Hydraulic Flow 10.5 gpm 11.2 gpm (7.1 + 4.1, computed) Overall Hydraulic Pump Flow 10.5 gpm 11.2 gpm (7.1 + 4.1, computed) Hydraulic System Type Not Published Open center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves Not Published Not Published No. of Optional Remote Valves 1 or 2 Not Published ▶ Fluid CapacityFuel Tank Capacity 9.0 gal 7.4 gal Coolant Capacity Not Published 5.3 qt Crankcase Capacity Not Published 4.6 qt Transmission / Hydraulic System Capacity Not Published 8.2 gal Front Axle Fluid Capacity Not Published 2.4 gal ▶ PTO & HitchPTO Type Independent Independent (electro-hydraulic) PTO Rear 540 rpm 540 rpm Mid-PTO Availability Not Published Standard Category, 3-Point Hitch Category I Category I Hitch Lift Capacity 2,639 lb 2,205 lb Hitch Lift Capacity (at 24”) 1,558 lb 1,764 lb Lift Control Type Not Published Position control ▶ Transmission & DrivetrainTransmission Type Synchro Shuttle Hydrostatic (Dual Touch Pedal) No. of Speeds Not Published Unlimited (hydrostatic); 3 ranges Max Travel Speed (Forward) Not Published 11.7 mph (with R4 tires) Max Travel Speed (Reverse) Not Published 8.2 mph (with R4 tires) Clutch Dry Single Plate N/A (hydrostatic) Differential Lock & Limited Slip Options Rear differential lock (foot pedal engagement) Rear differential lock (foot pedal engagement) ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Not Published Fully hydraulic power steering Brakes Not Published Wet disc Seat Suspension & Adjustability Comfortable, adjustable operator seat Not Published Front Axle Type Selectable 2WD/4WD engagement 2WD/4WD selectable engagement Front Axle Rating Not Published Not Published Drawbar Capacity Not Published Not Published ▶ Dimensions & ManeuverabilityOverall Length with 3-Point Hitch Not Published 116.9 in Overall Width Not Published 58.3 in (with R4 tires) Wheelbase Not Published 65 in Ground Clearance 12.8 in 10.8 in (with R4 tires) Min. Turn Radius without Brakes Not Published Not Published Height to Top of ROPS Not Published Not Published Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model Not Published 83.6 in (with R4 tires) ▶ WeightTractor Weight (Base) 3,020 lb 2,910 lb (cab, R4 tires, full fluid) Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published 3,823 lb ▶ Tire OptionsTire Size & Options Not Published R1 Agricultural; R3 Turf; R4 Industrial R1 Agricultural - Front Not Published 6-14 R1 Agricultural - Rear Not Published 9.5-22 R3 Turf - Front Not Published 25x8.5-14 R3 Turf - Rear Not Published 13.6x16 R4 Industrial - Front Not Published 25x8.5-14 R4 Industrial - Rear Not Published 15-19.6 ▶ Loader & AttachmentsQuick Attach Loader System Not Published YL310: Skid steer style bucket attachment Loader Model RL505 YL310 Loader Lift Height RL505: 101.5 in YL310: 84 in (to bucket pivot pin) Loader Lift Capacity (Full Height) RL505: 2,116 lb YL310: 1,300 lb at pivot pins Loader Breakout Force RL505: 3,435 lb YL310: 2,105 lb at pivot pins ▶ WarrantyWarranty Length & Coverage Tractor: 24 months or 2,000 hours; Powertrain: 10 years or 3,000 hours Tractor: 24 months or 2,000 hours; Powertrain: 10 years or 3,000 hours; Attachments: 1-year limited warranty
