▶ EngineEngine Manufacturer Deutz FPT Engine Model Not Published F5C Engine Type Not Published 4-cylinder diesel, turbocharged No. of Cylinders Not Published 4 Displacement Not Published 207 in³ Rated Engine Speed 2200 rpm 2300 rpm Engine Power (Gross) 74 hp 74 hp PTO Power 64.1 hp 65 hp Engine Emissions Constraints Not Published US EPA Tier 4B Cooling System Type Not Published Liquid-cooled Air Cleaner Not Published Dry Fuel System Not Published Common rail fuel injection Alternator Not Published 120 A ▶ HydraulicsPump Type Not Published Open center, dual pumps: implement pump plus dedicated steering and services pump Implement Flow 10.3 gpm 12.5 gpm Steering Flow 5.8 gpm 7.3 gpm (mechanical shuttle); 9.5 gpm (power shuttle) Total Hydraulic Flow 16.1 gpm 19.8 gpm (mechanical shuttle; 12.5 + 7.3, computed); 22.0 gpm (power shuttle; 12.5 + 9.5, computed) Overall Hydraulic Pump Flow 16.1 gpm 19.8 gpm (mechanical shuttle; 12.5 + 7.3, computed); 22.0 gpm (power shuttle; 12.5 + 9.5, computed) Hydraulic System Type Not Published Open center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves 2 Not Published No. of Optional Remote Valves Not Published Up to 3 rear remotes ▶ Fluid CapacityFuel Tank Capacity 23.8 gal 23.8 gal Coolant Capacity Not Published Not Published Crankcase Capacity Not Published Not Published Transmission / Hydraulic System Capacity Not Published Not Published Front Axle Fluid Capacity Not Published Not Published ▶ PTO & HitchPTO Type Independent Fully independent PTO Rear 540 rpm 540 rpm at 1,958 engine rpm (standard); 540E at 1,592 engine rpm (optional) Mid-PTO Availability Not Published Not Published Category, 3-Point Hitch Category II Category II / I Hitch Lift Capacity 5,115 lb Not Published Hitch Lift Capacity (at 24”) 3,418 lb 3,664 lb Lift Control Type Not Published Mechanical draft control; top link draft sensing ▶ Transmission & DrivetrainTransmission Type Power Shuttle 8x8 mechanical synchro shuttle (standard); 8x8 hydraulic power shuttle, 12x12 mechanical synchro shuttle or 12x12 hydraulic power shuttle (optional); creeper available with the power shuttle transmissions No. of Speeds Not Published 8F/8R (standard); 12F/12R (optional); 12F/12R or 20F/20R with creeper (optional) Max Travel Speed (Forward) Not Published 20.1 mph (8x8 and 12x12, 20 mph transmissions); 24.1 mph (optional 24 mph 12x12 transmission, 4WD only) Max Travel Speed (Reverse) Not Published 20.1 mph Clutch Wet Multi Plate Mechanical dry disc (mechanical shuttle); wet disc (power shuttle) Differential Lock & Limited Slip Options Rear differential lock (foot pedal engagement) Mechanical rear differential lock ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Power steering with tilt Hydrostatic power steering Brakes Not Published Hydraulic wet disc Seat Suspension & Adjustability Mechanical suspension seat Optional deluxe air suspension seat with fully integrated armrest and 10° swivel to the right; full-size instructor seat with seatbelt Front Axle Type Selectable 2WD/4WD engagement Heavy-duty 2WD front axle; electronic 4WD front axle (optional) Front Axle Rating Not Published Not Published Drawbar Capacity Not Published Not Published ▶ Dimensions & ManeuverabilityOverall Width Not Published Not Published Wheelbase Not Published 85.8 in (2WD); 83.9 in (4WD) Ground Clearance 18.3 in Not Published Min. Turn Radius without Brakes Not Published 134 in (2WD front axle) Height to Top of ROPS Not Published Not Published Height to Top of ROPS (folded) Not Published 76 to 78.9 in Height to Top of Cab Model Not Published 94.8 to 97.8 in Overall Length Not Published 151 in ▶ WeightTractor Weight (Base) 6,052 lb 5,027 lb (2WD ROPS); 5,952 lb (4WD ROPS) Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options Not Published Not Published R1 Agricultural - Front Not Published Not Published R1 Agricultural - Rear Not Published Not Published R3 Turf - Front Not Published Not Published R3 Turf - Rear Not Published Not Published R4 Industrial - Front Not Published Not Published R4 Industrial - Rear Not Published Not Published ▶ Loader & AttachmentsQuick Attach Loader System Not Published Skid-steer-style or Euro-style quick attach faceplate Loader Model RL705 Factory-fit: 655TL (NSL or MSL); field-fit: 622TL (NSL), 627TL (MSL) Loader Lift Height RL705: 133.8 in (at pivot pin) 655TL NSL: 126 in; 655TL MSL: 125 in; 622TL: 121 in; 627TL: 121 in Loader Lift Capacity (Full Height) RL705: 3,325 lb (at pivot pin) 655TL NSL: 2,478 lb; 655TL MSL: 3,179 lb; 622TL: 1,830 lb; 627TL: 2,557 lb (to max height, at 31.5 in from pivot point) Loader Breakout Force RL705: 5,485 lb (at pivot pin, ground level) 655TL NSL: 3,739 lb; 655TL MSL: 4,665 lb; 622TL: 3,042 lb; 627TL: 3,307 lb ▶ WarrantyWarranty Length & Coverage Basic 24 months or 2,000 hours; powertrain 10 years or 3,000 hours Not Published
