▶ EngineEngine Manufacturer Deutz Deutz Engine Model Not Published TCD2.9 L4 Engine Type Not Published Turbocharged No. of Cylinders Not Published 4 Displacement Not Published 177.0 in³ Rated Engine Speed 2200 rpm 2200 rpm Engine Power (Gross) 74 hp 74 hp PTO Power 64.1 hp 64.1 hp Engine Emissions Constraints Not Published Tier 4 Cooling System Type Not Published Liquid-cooled Air Cleaner Not Published Not Published Fuel System Not Published Common Rail Direct Injection Alternator Not Published 95 A, 12 V ▶ HydraulicsPump Type Not Published Not Published Implement Flow 10.3 gpm 10.3 gpm Steering Flow 5.8 gpm 5.8 gpm Total Hydraulic Flow 16.1 gpm 16.1 gpm Overall Hydraulic Pump Flow 16.1 gpm 16.1 gpm Hydraulic System Type Not Published Open center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves 2 2 No. of Optional Remote Valves Not Published 1 (up to 3 total with the option) ▶ Fluid CapacityFuel Tank Capacity 23.8 gal 23.8 gal Coolant Capacity Not Published 10.6 qt Crankcase Capacity Not Published 8.5 qt Transmission / Hydraulic System Capacity Not Published 18.0 gal Front Axle Fluid Capacity Not Published 17.4 qt ▶ PTO & HitchPTO Type Independent Independent PTO Rear 540 rpm 540/750 rpm Mid-PTO Availability Not Published No mid-PTO offered Category, 3-Point Hitch Category II Category II Hitch Lift Capacity 5,115 lb 5,115 lb Hitch Lift Capacity (at 24”) 3,418 lb 3,414 lb Lift Control Type Not Published Position / Draft / Mechanical ▶ Transmission & DrivetrainTransmission Type Power Shuttle 16F/16R Power Shuttle w/creeper No. of Speeds Not Published 16 forward, 16 reverse (creeper interlock) Max Travel Speed (Forward) Not Published 18.9 mph Max Travel Speed (Reverse) Not Published Not Published Clutch Wet Multi Plate Single plate dry clutch (11.81 in diameter); hydraulic clutch assembly for Independent PTO models Differential Lock & Limited Slip Options Rear differential lock (foot pedal engagement) 4WD, differential lock ▶ Chassis, Steering & ControlsFrame Type Not Published Unit frame: engine, clutch housing, transmission and front axle support bolted into one rigid assembly Steering Power steering with tilt Hydrostatic power steering Brakes Not Published Wet disc Seat Suspension & Adjustability Mechanical suspension seat High-back suspension seat with extension Front Axle Type Selectable 2WD/4WD engagement Center-pivot, reverse Eliot type (4WD) Front Axle Rating Not Published Not Published Drawbar Capacity Not Published Not Published ▶ Dimensions & ManeuverabilityOverall Width Not Published 76.4 in Wheelbase Not Published 86.1 in Ground Clearance 18.3 in 18.3 in Min. Turn Radius without Brakes Not Published 162.8 in Height to Top of ROPS Not Published Not Published Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model Not Published 103.3 in Overall Length Not Published 157.5 in (with 3-point hitch) ▶ WeightTractor Weight (Base) 6,052 lb 6,052 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options Not Published Titan (USA): R4 Industrial (Std), R3 Turf (Opt), R1 Agricultural (Opt) R1 Agricultural - Front Not Published 11.2-24 R1 Agricultural - Rear Not Published 16.9-30 R3 Turf - Front Not Published 12.0-20.5 R3 Turf - Rear Not Published 22.4-25.5 R4 Industrial - Front Not Published 15-19.5 R4 Industrial - Rear Not Published 18.4-24 ▶ Loader & AttachmentsQuick Attach Loader System Not Published L135SL: Skid-steer compatible quick coupler, self-leveling Loader Model RL705 L135SL Loader Lift Height RL705: 133.8 in (at pivot pin) L135SL: 135.5 in Loader Lift Capacity (Full Height) RL705: 3,325 lb (at pivot pin) L135SL: 3,223 lb at pivot pin to full height Loader Breakout Force RL705: 5,485 lb (at pivot pin, ground level) L135SL: 5,335 lb at pivot pin ▶ WarrantyWarranty Length & Coverage Basic 24 months or 2,000 hours; powertrain 10 years or 3,000 hours Government and non-institutional: basic 24 months or 2,000 hours, powertrain 60 months or 3,000 hours; all other use: basic 24 months or 2,000 hours, powertrain 36 months or 3,000 hours
