▶ EngineEngine Manufacturer Yanmar Mahindra Engine Model 4TNV88C-XKITL Not Published Engine Type 4-cylinder, liquid-cooled diesel Four-stroke, direct-injection water-cooled, diesel No. of Cylinders 4 4 Displacement 133.6 in³ 166.7 in³ Rated Engine Speed Not Published 2300 rpm Engine Power (Gross) 41.4 hp 41 hp PTO Power 31 hp 31 hp Engine Emissions Constraints Not Published Tier 4 Cooling System Type Liquid cooled Water-cooled Air Cleaner Dual air cleaner element Not Published Fuel System Not Published Direct injection Alternator Not Published 45 A, 12 V ▶ HydraulicsPump Type Not Published Not Published Implement Flow 9.3 gpm 8.7 gpm Steering Flow 5.3 gpm 5.8 gpm Total Hydraulic Flow 14.6 gpm Not Published Overall Hydraulic Pump Flow 14.6 gpm Not Published Hydraulic System Type Not Published Open center, full-live hydraulic, with position and draft control Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves 1 None No. of Optional Remote Valves 2 1 ▶ Fluid CapacityFuel Tank Capacity 13.2 gal 14.55 gal Coolant Capacity 6.3 qt Not Published Crankcase Capacity 5.1 qt Not Published Transmission / Hydraulic System Capacity 9.0 gal Not Published Front Axle Fluid Capacity 2.4 gal Not Published ▶ PTO & HitchPTO Type Independent Live PTO Rear 540/540E rpm 540 rpm @ 2058 engine rpm Mid-PTO Availability Not Published Not Published Category, 3-Point Hitch Category I & II Category I & II adjustable, with telescopic stabilizers Hitch Lift Capacity 3,190 lb 3,525 lb Hitch Lift Capacity (at 24”) 2,750 lb Not Published Lift Control Type Not Published Position & draft control ▶ Transmission & DrivetrainTransmission Type Synchronized shuttle shift Sliding mesh No. of Speeds F8-R8 8F / 2R Max Travel Speed (Forward) 17.7 mph Not Published Max Travel Speed (Reverse) Not Published Not Published Clutch Dry Single Dual Differential Lock & Limited Slip Options Differential lock (foot pedal) Not Published ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Power steering Hydrostatic power steering Brakes Not Published Fully enclosed dry disc Seat Suspension & Adjustability Suspension seat mComfort mechanical suspension seat Front Axle Type Selectable 2WD/4WD engagement Not Published Front Axle Rating Not Published Not Published Drawbar Capacity Not Published Not Published ▶ Dimensions & ManeuverabilityOverall Width 70.9 in (with R4 tires) 69.4 in Wheelbase 74.8 in Not Published Ground Clearance 15.5 in Not Published Min. Turn Radius without Brakes 138 in 9.7 ft (with brake applied) Height to Top of ROPS 98.0 in (with R4 tires) 88 in Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model Not Published Not Published Overall Length 133.6 in (with 3PH and R4 tires) 115.3 in ▶ WeightTractor Weight (Base) 3,916 lb 4,191 lb (operating weight) Weight with ROPS and Loader 5,129 lb (3,916 + 1,213, computed; YL605 loader) Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options AG; Industrial; Turf Ag R1 Agricultural - Front 8.0 - 16.0 6X16 R1 Agricultural - Rear 14.9 - 24.0 12.4X28 R3 Turf - Front 27.0 - 10.5 Not Published R3 Turf - Rear 44 x 18 - 20.0 Not Published R4 Industrial - Front 10.0 - 16.5 Not Applicable R4 Industrial - Rear 17.5L - 24.0 Not Applicable ▶ Loader & AttachmentsQuick Attach Loader System YL605: Skid steer quick attach Skid-steer style quick-attach coupler Loader Model YL605 4550-2L Loader Lift Height YL605: 113.0 in 116.6 in Loader Lift Capacity (Full Height) YL605: 2,500 lb (at pivot pin) 2,866 lb at pivot pins to full height Loader Breakout Force YL605: 3,047 lb 4,978 lb at pivot pins ▶ WarrantyWarranty Length & Coverage Powertrain 10 years or 3,000 hours 7-Year Limited Powertrain Warranty
