▶ EngineEngine Manufacturer Yanmar Mitsubishi Engine Model 4TNV88C-XKITL K38 Engine Type 4-cylinder, liquid-cooled diesel 3-cylinder turbocharged and intercooled diesel No. of Cylinders 4 3 Displacement 133.6 in³ 101 in³ Rated Engine Speed Not Published 2500 rpm Engine Power (Gross) 41.4 hp 41.6 hp PTO Power 31 hp Gear: 32.8 hp; HST: 31.6 hp Engine Emissions Constraints Not Published Tier 4 Cooling System Type Liquid cooled Liquid-cooled Air Cleaner Dual air cleaner element Not Published Fuel System Not Published Common-rail, direct injection, electronic engine management Alternator Not Published Not Published ▶ HydraulicsPump Type Not Published Engine-driven gear-type pump Implement Flow 9.3 gpm 11.6 gpm Steering Flow 5.3 gpm 6.8 gpm Total Hydraulic Flow 14.6 gpm Not Published Overall Hydraulic Pump Flow 14.6 gpm Not Published Hydraulic System Type Not Published Open center Rear Remote Hydraulic Flow Not Published 11.6 gpm No. of Standard Remote Valves 1 1 No. of Optional Remote Valves 2 Up to 3 ▶ Fluid CapacityFuel Tank Capacity 13.2 gal 14.5 gal Coolant Capacity 6.3 qt Not Published Crankcase Capacity 5.1 qt Not Published Transmission / Hydraulic System Capacity 9.0 gal Not Published Front Axle Fluid Capacity 2.4 gal Not Published ▶ PTO & HitchPTO Type Independent Independent, electro-hydraulically engaged PTO Rear 540/540E rpm 540 rpm (1-3/8 in 6-spline) Mid-PTO Availability Not Published Optional, 2000 rpm Category, 3-Point Hitch Category I & II Category I Hitch Lift Capacity 3,190 lb Not Published Hitch Lift Capacity (at 24”) 2,750 lb 2,535 lb Lift Control Type Not Published Position control; draft control optional ▶ Transmission & DrivetrainTransmission Type Synchronized shuttle shift 12x12 power shuttle (4 gears, 3 ranges) or 3-range electronic Servo-HST No. of Speeds F8-R8 Power shuttle: 12F / 12R; Servo-HST: 3-range infinite Max Travel Speed (Forward) 17.7 mph Not Published Max Travel Speed (Reverse) Not Published Not Published Clutch Dry Single Wet multi-disc (power shuttle) Differential Lock & Limited Slip Options Differential lock (foot pedal) Mechanical engagement via heel pedal ▶ Chassis, Steering & ControlsFrame Type Not Published Drop-axle rear with bull gear final drives Steering Power steering Power steering, tilt steering wheel Brakes Not Published Internal wet disc brakes, independent foot pedals Seat Suspension & Adjustability Suspension seat Suspended seat with armrests and seat belt (vinyl on ROPS, cloth on cab) Front Axle Type Selectable 2WD/4WD engagement Cast-steel 4WD front axle, center driveline, bevel-gear final drives Front Axle Rating Not Published Not Published Drawbar Capacity Not Published Not Published ▶ Dimensions & ManeuverabilityOverall Width 70.9 in (with R4 tires) 64.2 in Wheelbase 74.8 in 71.1 in Ground Clearance 15.5 in Not Published Min. Turn Radius without Brakes 138 in Not Published Height to Top of ROPS 98.0 in (with R4 tires) Not Published Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model Not Published 91.3 in Overall Length 133.6 in (with 3PH and R4 tires) 130.7 in ▶ WeightTractor Weight (Base) 3,916 lb ROPS: 3,638 lb; Cab: 4,068 lb Weight with ROPS and Loader 5,129 lb (3,916 + 1,213, computed; YL605 loader) Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options AG; Industrial; Turf Ag: 8-16 front, 12.4-24 rear (13.6-24 optional); turf: 27x8.50-15 front, 41x14.00-20 rear; industrial: 10-16.5 front, 17.5L-24 rear (also 250/75R16 front, 400/80R24 rear) R1 Agricultural - Front 8.0 - 16.0 8-16 R1 Agricultural - Rear 14.9 - 24.0 12.4-24 (13.6-24 optional) R3 Turf - Front 27.0 - 10.5 27x8.50-15 R3 Turf - Rear 44 x 18 - 20.0 41x14.00-20 R4 Industrial - Front 10.0 - 16.5 10-16.5 or 250/75R16 R4 Industrial - Rear 17.5L - 24.0 17.5L-24 or 400/80R24 ▶ Loader & AttachmentsQuick Attach Loader System YL605: Skid steer quick attach DL125: universal skid steer or exclusive compact quick-attach implement tool carrier Loader Model YL605 DL125 Loader Lift Height YL605: 113.0 in DL125: 102.4 in (at pivot pin) Loader Lift Capacity (Full Height) YL605: 2,500 lb (at pivot pin) DL125: 1,840 lb (at pivot pin, full height) Loader Breakout Force YL605: 3,047 lb DL125: 2,190 lb (at pivot pin) ▶ WarrantyWarranty Length & Coverage Powertrain 10 years or 3,000 hours 5-year powertrain warranty
