Yanmar YM342 vs TYM 4215 | Side-by-side comparison

ITC Company

Good things come to those who wait.


PTO Power	31 hp (23.1 kW)	36 hp (26.8 kW)
Alternator	Not Published	12 V, 50 A
Air Cleaner	Dual air cleaner element	Dry element
Engine Type	4-cylinder, liquid-cooled diesel	4-cylinder, naturally aspirated diesel
Fuel System	Not Published	IDI
Displacement	133.6 in³ (2,189 cc)	139.5 in³ (2,287 cc)
No. of Cylinders	4	4
Rated Engine Speed	Not Published	2,600 rpm
Cooling System Type	Liquid cooled	Not Published
Engine Manufacturer	YANMAR	TYM
Engine Emissions Constraints	Not Published	Tier 4
Engine Power (Gross vs. Net HP)	Gross: 41.4 hp (30.9 kW)	Gross: 42 hp (31.3 kW)

Tractor Weight with Loader	5,129 lb (2,326 kg)	HST: 4,266 lb (1,935 kg); Gear: 4,286 lb (1,944 kg)
Weight with Cab and Loader	Not Applicable	Not Applicable
Weight with ROPS and Loader	5,129 lb (2,326 kg)	HST: 4,266 lb (1,935 kg); Gear: 4,286 lb (1,944 kg)

Pump Type	Not Published	Single gear pump
Steering Flow	20.1 L/min (5.3 gpm)	37.5 L/min (9.9 gpm)
Implement Flow	35.2 L/min (9.3 gpm)	16.6 L/min (4.4 gpm)
Total Hydraulic Flow	55.3 L/min (14.6 gpm)	54.1 L/min (14.3 gpm)
Hydraulic System Type	Not Published	Open center
Rear Remote Hydraulic Flow	Not Published	Not Published
Overall Hydraulic Pump Flow	55.3 L/min (14.6 gpm)	54.1 L/min (14.3 gpm)
No. of Optional Remote Valves	2	Up to 4
No. of Standard Remote Valves	1	0

R3 Turf - Rear	44 x 18 - 20.0	Not Published
R3 Turf - Front	27.0 - 10.5	Not Published
Tire Size & Options	R1 Agricultural; R3 Turf; R4 Industrial	R1 Agricultural, R4 Industrial
R4 Industrial - Rear	17.5L - 24.0	43x16.00-20
R4 Industrial - Front	10.0 - 16.5	28x8.50-15
R1 Agricultural - Rear	14.9 - 24.0	12.4-24
R1 Agricultural - Front	8.0 - 16.0	8.0-16

PTO Rear	540/540E rpm	560 rpm
PTO Type	Independent	Independent
Lift Control Type	Not Published	Position control
Hitch Lift Capacity	3,190 lb (1,447 kg)	3,306 lb (1,500 kg)
Mid-PTO Availability	Not Published	Not Published
Category, 3-Point Hitch	Category I & II	Category I
Hitch Lift Capacity (at 24”)	2,750 lb (1,247 kg)	2,425 lb (1,100 kg)
Rear 3-Point Hitch Lift Capacity	3,190 lb (1,447 kg)	3,306 lb (1,500 kg)

Coolant Capacity	Not Published	6.2 qt (5.9 L)
Crankcase Capacity	Not Published	4.8 qt (4.5 L)
Fuel Tank Capacity	13.2 gal (50.0 L)	7.1 gal (27 L)
Front Axle Fluid Capacity	Not Published	1.7 qt (1.6 L)
Transmission / Hydraulic System Capacity	Not Published	HST: 9.8 gal (37.1 L); Gear: 8.9 gal (33.7 L)

Loader Lift Height	113 in (2,870 mm)	104.9 in (2,665 mm)
Loader Breakout Force	3,047 lb (1,382 kg) (500 mm forward)	3,422 lb (1,552 kg)
Price for Backhoe Option	B85: $18,524	BH150
Price for Mid-Mount Mower	Not Published	Not Published
Quick Attach Loader System	YL605: Skid steer quick attach	BL150: Quick attachment assembly
Loader Lift Capacity (Full Height)	2,500 lb (1,134 kg) (pivot pin)	2,200 lb (998 kg)

Clutch	Dry single	HST: No; Gear: Dry single type
No. of Speeds	8F/8R	HST: 3-Range; Gear: F12 x R12
Transmission Type	Synchronized shuttle shift	HST: HST; Gear: Synchromesh
Max Travel Speed (Forward)	17.7 mph (28.5 km/h)	HST: 18.8 mph (30.2 km/h); Gear: 14.4 mph (23.2 km/h)
Max Travel Speed (Reverse)	Not Published	Not Published
Differential Lock & Limited Slip Options	Not Published	Differential lock

Brakes	Not Published	Wet, multi-disc
Steering	Power steering	Hydrostatic
Frame Type	Not Published	Not Published
Front Axle Type	Not Published	Not Published
Drawbar Capacity	Not Published	Not Published
Front Axle Rating	Not Published	Not Published
Seat Suspension & Adjustability	Suspension seat	Comfortable suspension seat

Wheelbase	74.8 in (1,900 mm)	65.7 in (1,670 mm)
Overall Width	70.9 in (1,801 mm) (with R4 tires)	56.3 in (1,430 mm)
Ground Clearance	15.5 in (394 mm)	14.4 in (366 mm)
Height to Top of ROPS	98 in (2,489 mm) (with R4 tires)	97.3 in (2,471 mm)
Height to Top of Cab Model	Not Applicable	Not Applicable
Height to Top of ROPS (folded)	Not Published	Not Published
Min. Turn Radius without Brakes	11.5 ft (3.5 m)	104.7 in (2,659.4 mm)
Overall Length with 3-Point Hitch	133.6 in (3,393 mm) (with 3PH and R4 tires)	120.9 in (3,071 mm)

Financing Options	See Exclusive Offers (promotions vary)	0% financing for up to 72 months and instant cash rebates. Contact dealer for more information.
Base Price with Loader	$31,026	Not Published
Warranty Length & Coverage	10-year limited powertrain warranty or 3,000 hours (whichever comes first)	Up to 2 years or until the 2,000 hours mark, bumper-to-bumper warranty; 3000 hours maximum coverage period for parts and labour on drivetrains or powertrains; 12-months warranty period for implements, including loaders and backhoes.
Base Price with Loader + Cab	Not Applicable	Not Applicable

Spec sheet sources	[1] yanmartractor.com [2] yanmartractor.com [3] yanmartractor.com	[1] tym.world [2] tym-new.euwest01.umbraco.io [3] tym-new.euwest01.umbraco.io

PTO Power

31 hp (23.1 kW)

36 hp (26.8 kW)

Alternator

Not Published

12 V, 50 A

Air Cleaner

Dual air cleaner element

Dry element

Engine Type

4-cylinder, liquid-cooled diesel

4-cylinder, naturally aspirated diesel

Fuel System

Not Published

IDI

Displacement

133.6 in³ (2,189 cc)

139.5 in³ (2,287 cc)

No. of Cylinders

Rated Engine Speed

Not Published

2,600 rpm

Cooling System Type

Liquid cooled

Not Published

Engine Manufacturer

YANMAR

TYM

Engine Emissions Constraints

Not Published

Tier 4

Engine Power (Gross vs. Net HP)

Gross: 41.4 hp (30.9 kW)

Gross: 42 hp (31.3 kW)

Tractor Weight with Loader

5,129 lb (2,326 kg)

HST: 4,266 lb (1,935 kg); Gear: 4,286 lb (1,944 kg)

Weight with Cab and Loader

Not Applicable

Weight with ROPS and Loader

5,129 lb (2,326 kg)

HST: 4,266 lb (1,935 kg); Gear: 4,286 lb (1,944 kg)

Pump Type

Not Published

Single gear pump

Steering Flow

20.1 L/min (5.3 gpm)

37.5 L/min (9.9 gpm)

Implement Flow

35.2 L/min (9.3 gpm)

16.6 L/min (4.4 gpm)

Total Hydraulic Flow

55.3 L/min (14.6 gpm)

54.1 L/min (14.3 gpm)

Hydraulic System Type

Not Published

Open center

Rear Remote Hydraulic Flow

Not Published

Overall Hydraulic Pump Flow

55.3 L/min (14.6 gpm)

54.1 L/min (14.3 gpm)

No. of Optional Remote Valves

Up to 4

No. of Standard Remote Valves

R3 Turf - Rear

44 x 18 - 20.0

Not Published

R3 Turf - Front

27.0 - 10.5

Not Published

Tire Size & Options

R1 Agricultural; R3 Turf; R4 Industrial

R1 Agricultural, R4 Industrial

R4 Industrial - Rear

17.5L - 24.0

43x16.00-20

R4 Industrial - Front

10.0 - 16.5

28x8.50-15

R1 Agricultural - Rear

14.9 - 24.0

12.4-24

R1 Agricultural - Front

8.0 - 16.0

8.0-16

PTO Rear

540/540E rpm

560 rpm

PTO Type

Independent

Lift Control Type

Not Published

Position control

Hitch Lift Capacity

3,190 lb (1,447 kg)

3,306 lb (1,500 kg)

Mid-PTO Availability

Not Published

Category, 3-Point Hitch

Category I & II

Category I

Hitch Lift Capacity (at 24”)

2,750 lb (1,247 kg)

2,425 lb (1,100 kg)

Rear 3-Point Hitch Lift Capacity

3,190 lb (1,447 kg)

3,306 lb (1,500 kg)

Coolant Capacity

Not Published

6.2 qt (5.9 L)

Crankcase Capacity

Not Published

4.8 qt (4.5 L)

Fuel Tank Capacity

13.2 gal (50.0 L)

7.1 gal (27 L)

Front Axle Fluid Capacity

Not Published

1.7 qt (1.6 L)

Transmission / Hydraulic System Capacity

Not Published

HST: 9.8 gal (37.1 L); Gear: 8.9 gal (33.7 L)

Loader Lift Height

113 in (2,870 mm)

104.9 in (2,665 mm)

Loader Breakout Force

3,047 lb (1,382 kg) (500 mm forward)

3,422 lb (1,552 kg)

Price for Backhoe Option

B85: $18,524

BH150

Price for Mid-Mount Mower

Not Published

Quick Attach Loader System

YL605: Skid steer quick attach

BL150: Quick attachment assembly

Loader Lift Capacity (Full Height)

2,500 lb (1,134 kg) (pivot pin)

2,200 lb (998 kg)

Clutch

Dry single

HST: No; Gear: Dry single type

No. of Speeds

8F/8R

HST: 3-Range; Gear: F12 x R12

Transmission Type

Synchronized shuttle shift

HST: HST; Gear: Synchromesh

Max Travel Speed (Forward)

17.7 mph (28.5 km/h)

HST: 18.8 mph (30.2 km/h); Gear: 14.4 mph (23.2 km/h)

Max Travel Speed (Reverse)

Not Published

Differential Lock & Limited Slip Options

Not Published

Differential lock

Brakes

Not Published

Wet, multi-disc

Steering

Power steering

Hydrostatic

Frame Type

Not Published

Front Axle Type

Not Published

Drawbar Capacity

Not Published

Front Axle Rating

Not Published

Seat Suspension & Adjustability

Suspension seat

Comfortable suspension seat

Wheelbase

74.8 in (1,900 mm)

65.7 in (1,670 mm)

Overall Width

70.9 in (1,801 mm) (with R4 tires)

56.3 in (1,430 mm)

Ground Clearance

15.5 in (394 mm)

14.4 in (366 mm)

Height to Top of ROPS

98 in (2,489 mm) (with R4 tires)

97.3 in (2,471 mm)

Height to Top of Cab Model

Not Applicable

Height to Top of ROPS (folded)

Not Published

Min. Turn Radius without Brakes

11.5 ft (3.5 m)

104.7 in (2,659.4 mm)

Overall Length with 3-Point Hitch

133.6 in (3,393 mm) (with 3PH and R4 tires)

120.9 in (3,071 mm)

Financing Options

See Exclusive Offers (promotions vary)

0% financing for up to 72 months and instant cash rebates. Contact dealer for more information.

Base Price with Loader

$31,026

Not Published

Warranty Length & Coverage

10-year limited powertrain warranty or 3,000 hours (whichever comes first)

Up to 2 years or until the 2,000 hours mark, bumper-to-bumper warranty; 3000 hours maximum coverage period for parts and labour on drivetrains or powertrains; 12-months warranty period for implements, including loaders and backhoes.

Base Price with Loader + Cab

Not Applicable

Spec sheet sources

[1] yanmartractor.com [2] yanmartractor.com [3] yanmartractor.com

[1] tym.world [2] tym-new.euwest01.umbraco.io [3] tym-new.euwest01.umbraco.io
