Pick up to 4tractors and we'll lay every spec sheet out side by side. Same data we publish on the individual model pages, stacked in columns so you can compare numbers at a glance.
No photo
—
YanmarYM342
No photo
—
YanmarSM240H
Comparison loaded for 2 tractors.
Spec
YanmarYM342
YanmarSM240H
PTO Power
31 hp (23.1 kW)
27.5 hp (20.2 kW)
Alternator
Not Published
Not Published
Air Cleaner
Dual air cleaner element
Not Published
Engine Type
4-cylinder, liquid-cooled diesel
Not Published
Fuel System
Not Published
Not Published
Displacement
133.6 in³ (2,189 cc)
Not Published
No. of Cylinders
4
Not Published
Rated Engine Speed
Not Published
3,000 rpm
Cooling System Type
Liquid cooled
Not Published
Engine Manufacturer
YANMAR
YANMAR
Engine Emissions Constraints
Not Published
Not Published
Engine Power (Gross vs. Net HP)
Gross: 41.4 hp (30.9 kW)
Gross: 36.9 hp (27.5 kW)
Tractor Weight with Loader
5,129 lb (2,326 kg)
Not Published
Weight with Cab and Loader
Not Applicable
Not Applicable
Weight with ROPS and Loader
5,129 lb (2,326 kg)
Not Published
Pump Type
Not Published
Not Published
Steering Flow
20.1 L/min (5.3 gpm)
16.66 L/min (4.4 gpm)
Implement Flow
35.2 L/min (9.3 gpm)
23.09 L/min (6.1 gpm)
Total Hydraulic Flow
55.3 L/min (14.6 gpm)
39.75 L/min (10.5 gpm)
Hydraulic System Type
Not Published
Not Published
Rear Remote Hydraulic Flow
Not Published
Not Published
Overall Hydraulic Pump Flow
55.3 L/min (14.6 gpm)
39.75 L/min (10.5 gpm)
No. of Optional Remote Valves
2
1 or 2
No. of Standard Remote Valves
1
Not Published
R3 Turf - Rear
44 x 18 - 20.0
Not Published
R3 Turf - Front
27.0 - 10.5
Not Published
Tire Size & Options
R1 Agricultural; R3 Turf; R4 Industrial
Not Published
R4 Industrial - Rear
17.5L - 24.0
Not Published
R4 Industrial - Front
10.0 - 16.5
Not Published
R1 Agricultural - Rear
14.9 - 24.0
Not Published
R1 Agricultural - Front
8.0 - 16.0
Not Published
PTO Rear
540/540E rpm
540 rpm
PTO Type
Independent
Independent
Lift Control Type
Not Published
Not Published
Hitch Lift Capacity
3,190 lb (1,447 kg)
2,639 lb (1,197 kg)
Mid-PTO Availability
Not Published
Not Published
Category, 3-Point Hitch
Category I & II
Category I
Hitch Lift Capacity (at 24”)
2,750 lb (1,247 kg)
1,558 lb (707 kg)
Rear 3-Point Hitch Lift Capacity
3,190 lb (1,447 kg)
2,639 lb (1,197 kg)
Coolant Capacity
Not Published
Not Published
Crankcase Capacity
Not Published
Not Published
Fuel Tank Capacity
13.2 gal (50.0 L)
9.0 gal (34 L)
Front Axle Fluid Capacity
Not Published
Not Published
Transmission / Hydraulic System Capacity
Not Published
Not Published
Loader Lift Height
113 in (2,870 mm)
101.5 in (2,578 mm)
Loader Breakout Force
3,047 lb (1,382 kg) (500 mm forward)
3,435 lb (1,558 kg)
Price for Backhoe Option
B85: $18,524
Not Published
Price for Mid-Mount Mower
Not Published
Not Published
Quick Attach Loader System
YL605: Skid steer quick attach
Not Published
Loader Lift Capacity (Full Height)
2,500 lb (1,134 kg) (pivot pin)
2,116 lb (960 kg)
Clutch
Dry single
Not Applicable
No. of Speeds
8F/8R
Not Published
Transmission Type
Synchronized shuttle shift
Hydrostatic
Max Travel Speed (Forward)
17.7 mph (28.5 km/h)
Not Published
Max Travel Speed (Reverse)
Not Published
Not Published
Differential Lock & Limited Slip Options
Not Published
Rear differential lock (foot pedal engagement)
Brakes
Not Published
Dual brakes
Steering
Power steering
Not Published
Frame Type
Not Published
Not Published
Front Axle Type
Not Published
Selectable 2WD/4WD engagement
Drawbar Capacity
Not Published
Not Published
Front Axle Rating
Not Published
Not Published
Seat Suspension & Adjustability
Suspension seat
Not Published
Wheelbase
74.8 in (1,900 mm)
Not Published
Overall Width
70.9 in (1,801 mm) (with R4 tires)
Not Published
Ground Clearance
15.5 in (394 mm)
12.8 in (325 mm)
Height to Top of ROPS
98 in (2,489 mm) (with R4 tires)
Not Published
Height to Top of Cab Model
Not Applicable
Not Applicable
Height to Top of ROPS (folded)
Not Published
Not Published
Min. Turn Radius without Brakes
11.5 ft (3.5 m)
Not Published
Overall Length with 3-Point Hitch
133.6 in (3,393 mm) (with 3PH and R4 tires)
Not Published
Financing Options
See Exclusive Offers (promotions vary)
See Exclusive Offers (offer valid through April 30, 2026; eligibility varies)
Base Price with Loader
$31,026
Not Published
Warranty Length & Coverage
10-year limited powertrain warranty or 3,000 hours (whichever comes first)
Tractor: 24 months or 2,000 hours; Powertrain: 10 years or 3,000 hours
