▶ EngineEngine Manufacturer Yanmar KIOTI (Daedong) Engine Model 4TNV98C-XNITL 3F183T Engine Type 4-cylinder, liquid-cooled diesel KIOTI 3 Cylinder, In-Line Vertical, Water-Cooled 4-Cycle Turbo Diesel, CRDI No. of Cylinders 4 3 Displacement 202.4 in³ 111.4 in³ Rated Engine Speed 2500 rpm 2600 rpm Engine Power (Gross) 58.9 hp 60 hp PTO Power 47 hp 48.3 hp Engine Emissions Constraints Not Published Tier 4 Cooling System Type Liquid cooled Water-cooled Air Cleaner Dual air cleaner element Dry type element Fuel System Not Published Common Rail Direct Injection (CRDI) Alternator Not Published Not Published ▶ HydraulicsPump Type Not Published Gear Implement Flow 10.2 gpm 9.6 gpm Steering Flow 5.7 gpm 8.2 gpm Total Hydraulic Flow 15.9 gpm 17.9 gpm Overall Hydraulic Pump Flow 15.9 gpm 17.9 gpm Hydraulic System Type Not Published Open Center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves 1 1 No. of Optional Remote Valves 2 1 ▶ Fluid CapacityFuel Tank Capacity 13.2 gal 14.8 gal Coolant Capacity 8.1 qt 2.0 gal Crankcase Capacity 9.2 qt 1.58 gal Transmission / Hydraulic System Capacity 9.0 gal 11.89 gal Front Axle Fluid Capacity 2.4 gal 1.8 gal ▶ PTO & HitchPTO Type Independent Independent PTO Rear 540/540E rpm 540 rpm Mid-PTO Availability Not Published Optional (2,000 rpm) Category, 3-Point Hitch Category I & II Category I & II Hitch Lift Capacity 3,190 lb 3,538 lb Hitch Lift Capacity (at 24”) 2,750 lb 3,177 lb Lift Control Type Not Published Position with Draft Control ▶ Transmission & DrivetrainTransmission Type Synchronized shuttle shift Hydrostatic No. of Speeds F8-R8 3 Range Max Travel Speed (Forward) 18.5 mph 18.26 mph Max Travel Speed (Reverse) Not Published 18.26 mph Clutch Dry Single Not Published Differential Lock & Limited Slip Options Differential lock (foot pedal) Differential Lock: Rear (Standard) ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Power steering Hydrostatic Power Steering Brakes Not Published Wet Multi Disc Seat Suspension & Adjustability Suspension seat Adjustable Seat Front Axle Type Selectable 2WD/4WD engagement Not Published Front Axle Rating Not Published Not Published Drawbar Capacity Not Published 1,655 lb (max. drawbar vertical load) ▶ Dimensions & ManeuverabilityOverall Length with 3-Point Hitch 133.9 in (with 3PH and R4 tires) 139.6 in Overall Width 70.9 in (with R4 tires) 65.7 in Wheelbase 77.5 in 75.6 in Ground Clearance 15.5 in 15.7 in Min. Turn Radius without Brakes 142 in 10.0 ft Height to Top of ROPS 98.0 in (with R4 tires) 103.1 in Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model Not Published 94.1 in ▶ WeightTractor Weight (Base) 4,158 lb NX6010H: 4,198 lb; NX6010HC: 4,529 lb Weight with ROPS and Loader 5,371 lb Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options R1 Agricultural; R3 Turf; R4 Industrial R1 Agricultural, R3 Turf, R4 Industrial R1 Agricultural - Front 210/95R16 (Radial) 9.5-16 R1 Agricultural - Rear 420/85R24 (Radial) 16.9-24 R3 Turf - Front 27.0 - 10.5 29-12.5-15 R3 Turf - Rear 44 x 18 - 20.0 21.5L-16.1 R4 Industrial - Front 10.0 - 16.5 10-16.5 R4 Industrial - Rear 16.9 - 24.0 17.5-24 ▶ Loader & AttachmentsQuick Attach Loader System YL605: Skid steer quick attach Built-in parking stand; quick attach/detach; single-lever joystick control with float; bucket level indicator Loader Model YL605 KL6010 Loader Lift Height YL605: 113.0 in KL6010: 108.3 in (to pivot pin) Loader Lift Capacity (Full Height) YL605: 2,500 lb KL6010: 2,761 lb (at pivot pin, max height) Loader Breakout Force YL605: 3,047 lb (19.7 in forward of pivot pin) KL6010: 3,727 lb (at pivot pin) ▶ WarrantyWarranty Length & Coverage 10-year limited powertrain warranty or 3,000 hours (whichever comes first) Non-commercial tractor: 24 months, unlimited hours, parts & labor; non-commercial powertrain (engine and driveline): 72 months, unlimited hours, parts & labor
