▶ EngineEngine Manufacturer Yanmar Kubota Engine Model 4TNV98C-XNITL V2403-CR-TE4 Engine Type 4-cylinder, liquid-cooled diesel 4-cylinder, turbocharged, common-rail diesel No. of Cylinders 4 4 Displacement 202.4 in³ 148.5 in³ Rated Engine Speed 2500 rpm 2600 rpm Engine Power (Gross) 58.9 hp 58.7 hp PTO Power 47 hp 50 hp Engine Emissions Constraints Not Published Tier 4 Cooling System Type Liquid cooled Liquid-cooled, pressurized radiator with recovery tank Air Cleaner Dual air cleaner element Dry paper dual element, 8 in diameter, pre-cleaner standard Fuel System Not Published Common rail direct injection Alternator Not Published 45 A ▶ HydraulicsPump Type Not Published Gear pump Implement Flow 10.2 gpm 10.6 gpm Steering Flow 5.7 gpm 6.1 gpm Total Hydraulic Flow 15.9 gpm 16.5 gpm Overall Hydraulic Pump Flow 15.9 gpm 16.5 gpm Hydraulic System Type Not Published Open center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves 1 1 (SCD) No. of Optional Remote Valves 2 2 optional (3 maximum) ▶ Fluid CapacityFuel Tank Capacity 13.2 gal 17.2 gal Coolant Capacity 8.1 qt 8.5 qt Crankcase Capacity 9.2 qt 7.6 qt Transmission / Hydraulic System Capacity 9.0 gal 50.7 qt Front Axle Fluid Capacity 2.4 gal No front axle oil, 2WD (M5660SUH); 6.9 qt front differential case plus 3.2 qt per bevel gear case (M5660SUHD) ▶ PTO & HitchPTO Type Independent Hydraulic, independent PTO, self-modulating multi-plate wet clutch with brake PTO Rear 540/540E rpm 540 rpm (540/540E optional) Mid-PTO Availability Not Published Not Published Category, 3-Point Hitch Category I & II Category I and II Hitch Lift Capacity 3,190 lb 4,189 lb Hitch Lift Capacity (at 24”) 2,750 lb 3,307 lb Lift Control Type Not Published Position control ▶ Transmission & DrivetrainTransmission Type Synchronized shuttle shift Fully synchronized 4-speed main gear shift with hi-lo range and hydraulic shuttle, 8F/8R No. of Speeds F8-R8 8F/8R Max Travel Speed (Forward) 18.5 mph 18.2 mph Max Travel Speed (Reverse) Not Published 18.6 mph Clutch Dry Single Multiple wet disc Differential Lock & Limited Slip Options Differential lock (foot pedal) Rear differential lock standard (mechanical) ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Power steering Hydrostatic power steering Brakes Not Published Mechanical wet disc Seat Suspension & Adjustability Suspension seat Fully adjustable suspension seat with retractable seat belt Front Axle Type Selectable 2WD/4WD engagement M5660SUH: adjustable tubular-steel 2WD axle; M5660SUHD: cast-iron bevel-pinion drive, 55-degree turning angle, 4WD Front Axle Rating Not Published 4,410 lb at 55.9 in tread spacing (M5660SUH); 5,290 lb at 55.9 in tread spacing (M5660SUHD) Drawbar Capacity Not Published 3,300 lb (maximum tongue weight) ▶ Dimensions & ManeuverabilityOverall Width 70.9 in (with R4 tires) 72.8 in Wheelbase 77.5 in 82 in (M5660SUH); 80.7 in (M5660SUHD) Ground Clearance 15.5 in (with R3 tires) 16.3 in Min. Turn Radius without Brakes 142 in 11.1 ft (M5660SUH); 12.8 ft (M5660SUHD) Height to Top of ROPS 98.0 in (with R4 tires) 95.3 in Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model Not Published Not Published Overall Length 133.9 in (with 3-point hitch and R4 tires) 138.7 in (M5660SUH); 136 in (M5660SUHD) ▶ WeightTractor Weight (Base) 4,158 lb 4,189 lb (M5660SUH); 4,387 lb (M5660SUHD) Weight with ROPS and Loader 5,371 lb (4,158 + 1,213, computed; YL605 loader) Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options R1 Agricultural; R3 Turf; R4 Industrial 2WD: 6.50-16, 7.5-16, 9.5L-15 fronts with 14.9-28 or 16.9-28 R1 rears; R3 29x12.50-15 / 21.5L-16.1 and LSW; 4WD: 9.5-22 or 280/85R20 fronts with 14.9-28 R1 rears; R3 29x12.50-15 / 21.5L-16.1; R4 12.5/80-18 / 16.9-24 R1 Agricultural - Front 210/95R16 (Radial) 9.5L-15 (M5660SUH); 9.5-22 (M5660SUHD) R1 Agricultural - Rear 420/85R24 (Radial) 14.9-28 R3 Turf - Front 27.0 - 10.5 29x12.50-15 R3 Turf - Rear 44 x 18 - 20.0 21.5L-16.1 R4 Industrial - Front 10.0 - 16.5 12.5/80-18 (M5660SUHD) R4 Industrial - Rear 16.9 - 24.0 16.9-24 (M5660SUHD) ▶ Loader & AttachmentsQuick Attach Loader System YL605: Skid steer quick attach LA1154SU: 2-lever quick attach coupler standard Loader Model YL605 LA1154SU Loader Lift Height YL605: 113.0 in LA1154SU: 130.9 in (height position); 115.7 in (power position) Loader Lift Capacity (Full Height) YL605: 2,500 lb (at pivot pin) LA1154SU: 2,469 lb (height position); 2,928 lb (power position) Loader Breakout Force YL605: 3,047 lb LA1154SU: 4,230 lbf (height position); 5,354 lbf (power position) ▶ WarrantyWarranty Length & Coverage Powertrain 10 years or 3,000 hours Basic 24 months or 2,000 hours, powertrain 36 months or 3,000 hours, all usage
