▶ EngineEngine Manufacturer Yanmar Shibaura Engine Model 4TNV98C-XNITL N4LDI-TA Engine Type 4-cylinder, liquid-cooled diesel 4-cylinder turbocharged intercooled diesel, liquid-cooled No. of Cylinders 4 4 Displacement 202.4 in³ 135.2 in³ Rated Engine Speed 2500 rpm 2600 rpm Engine Power (Gross) 58.9 hp 59.9 hp PTO Power 47 hp 46.1 hp Engine Emissions Constraints Not Published Tier 4 Cooling System Type Liquid cooled Liquid-cooled Air Cleaner Dual air cleaner element Dry Fuel System Not Published Common rail direct injection Alternator Not Published Not Published ▶ HydraulicsPump Type Not Published Engine-driven gear-type pump Implement Flow 10.2 gpm Not Published Steering Flow 5.7 gpm Not Published Total Hydraulic Flow 15.9 gpm Not Published Overall Hydraulic Pump Flow 15.9 gpm 12x12 Power Shuttle: 12.7 gpm; HST: 12.6 gpm Hydraulic System Type Not Published Open center Rear Remote Hydraulic Flow Not Published 12.1 gpm No. of Standard Remote Valves 1 Not Published No. of Optional Remote Valves 2 Up to 3 ▶ Fluid CapacityFuel Tank Capacity 13.2 gal 14.0 gal Coolant Capacity 8.1 qt 7.08 qt Crankcase Capacity 9.2 qt 6.87 qt Transmission / Hydraulic System Capacity 9.0 gal 12x12 Power Shuttle: 11.35 gal; HST: 9.25 gal Front Axle Fluid Capacity 2.4 gal 9.0 qt ▶ PTO & HitchPTO Type Independent Independent, with soft-start feature PTO Rear 540/540E rpm 540 rpm (1-3/8 in 6-spline) Mid-PTO Availability Not Published Optional, 2,000 rpm (not offered with the 12x12 power shuttle) Category, 3-Point Hitch Category I & II Category I with extendable ball ends Hitch Lift Capacity 3,190 lb Not Published Hitch Lift Capacity (at 24”) 2,750 lb 12x12 Power Shuttle: 3,307 lb; HST: 3,086 lb Lift Control Type Not Published Position and draft control ▶ Transmission & DrivetrainTransmission Type Synchronized shuttle shift 12 x 12 power shuttle or 3-range hydrostatic No. of Speeds F8-R8 12x12 Power Shuttle: 12F / 12R; HST: 3-range infinite Max Travel Speed (Forward) 18.5 mph Not Published Max Travel Speed (Reverse) Not Published Not Published Clutch Dry Single Multiple stage wet type Differential Lock & Limited Slip Options Differential lock (foot pedal) Mechanical engagement via right side heel pedal ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Power steering Power steering Brakes Not Published Internal wet disc brakes, individual control via independent foot pedals Seat Suspension & Adjustability Suspension seat Deluxe suspended seat with armrests and seatbelts (vinyl seat on ROPS, cloth seat on cab), tilt steering Front Axle Type Selectable 2WD/4WD engagement Cast steel 4WD front axle with center drive line and bevel-gear final drives Front Axle Rating Not Published Not Published Drawbar Capacity Not Published Not Published ▶ Dimensions & ManeuverabilityOverall Length with 3-Point Hitch 133.9 in (with 3PH and R4 tires) 12x12 Power Shuttle: 170.1 in; HST: 132.3 in Overall Width 70.9 in (with R4 tires) 12x12 Power Shuttle: 71.1 in; HST: 65.4 in Wheelbase 77.5 in 12x12 Power Shuttle: 80.3 in; HST: 77.9 in Ground Clearance 15.5 in 14.8 in Min. Turn Radius without Brakes 142 in Not Published Height to Top of ROPS 98.0 in (with R4 tires) 12x12 Power Shuttle: 103.2 in; HST: 102.4 in Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model Not Published 12x12 Power Shuttle: 93.3 in; HST: 92.9 in ▶ WeightTractor Weight (Base) 4,158 lb 12x12 Power Shuttle: 4,233 lb Weight with ROPS and Loader 5,371 lb Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options R1 Agricultural; R3 Turf; R4 Industrial R1 Agricultural, R3 Turf, R4 Industrial R1 Agricultural - Front 210/95R16 (Radial) 9.5x16 R1 Agricultural - Rear 420/85R24 (Radial) 16.9x26 R3 Turf - Front 27.0 - 10.5 27x10.50-15 R3 Turf - Rear 44 x 18 - 20.0 44x18.00-20 R4 Industrial - Front 10.0 - 16.5 12-16.5 R4 Industrial - Rear 16.9 - 24.0 18.4-24 ▶ Loader & AttachmentsQuick Attach Loader System YL605: Skid steer quick attach DL135: Skid steer quick attach Loader Model YL605 DL135 Loader Lift Height YL605: 113.0 in DL135: 111 in Loader Lift Capacity (Full Height) YL605: 2,500 lb DL135: 2,610 lb Loader Breakout Force YL605: 3,047 lb (19.7 in forward of pivot pin) DL135: 4,000 lb ▶ WarrantyWarranty Length & Coverage 10-year limited powertrain warranty or 3,000 hours (whichever comes first) 5-year powertrain warranty
