▶ EngineEngine Manufacturer Yanmar TYM Engine Model 4TNV98C-XNITL T2300T1-UTC_4 Engine Type 4-cylinder, liquid-cooled diesel 4-cylinder, turbocharged diesel No. of Cylinders 4 4 Displacement 202.4 in³ 139.5 in³ Rated Engine Speed 2500 rpm 2600 rpm Engine Power (Gross) 58.9 hp 58 hp PTO Power 47 hp 48 hp Engine Emissions Constraints Not Published Tier 4 Cooling System Type Liquid cooled Not Published Air Cleaner Dual air cleaner element Dry element Fuel System Not Published IDI Alternator Not Published 70 A, 12 V ▶ HydraulicsPump Type Not Published Single gear pump Implement Flow 10.2 gpm 11.4 gpm Steering Flow 5.7 gpm 5.13 gpm Total Hydraulic Flow 15.9 gpm 16.5 gpm Overall Hydraulic Pump Flow 15.9 gpm 16.5 gpm Hydraulic System Type Not Published Not Published Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves 1 Loader: 6; Rear: 6 No. of Optional Remote Valves 2 Not Published ▶ Fluid CapacityFuel Tank Capacity 13.2 gal 15.3 gal Coolant Capacity 8.1 qt 6.2 qt Crankcase Capacity 9.2 qt 4.8 qt Transmission / Hydraulic System Capacity 9.0 gal 11.62 gal Front Axle Fluid Capacity 2.4 gal 6.8 qt ▶ PTO & HitchPTO Type Independent Independent PTO Rear 540/540E rpm 540 rpm Mid-PTO Availability Not Published Not Published Category, 3-Point Hitch Category I & II Category II Hitch Lift Capacity 3,190 lb 4,409 lb Hitch Lift Capacity (at 24”) 2,750 lb 3,748 lb Lift Control Type Not Published Position and draft control (electronic) ▶ Transmission & DrivetrainTransmission Type Synchronized shuttle shift Power shuttle No. of Speeds F8-R8 F12 x R12 Max Travel Speed (Forward) 18.5 mph 24.04 mph Max Travel Speed (Reverse) Not Published Not Published Clutch Dry Single Wet, multi-disc Differential Lock & Limited Slip Options Differential lock (foot pedal) Standard differential lock ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Power steering Hydrostatic Brakes Not Published Wet, multi-disc Seat Suspension & Adjustability Suspension seat Suspension seat Front Axle Type Selectable 2WD/4WD engagement 4WD (selectable 2WD/4WD) Front Axle Rating Not Published Not Published Drawbar Capacity Not Published Not Published ▶ Dimensions & ManeuverabilityOverall Width 70.9 in (with R4 tires) 68.9 in Wheelbase 77.5 in 78.7 in Ground Clearance 15.5 in (with R3 tires) 18.1 in Min. Turn Radius without Brakes 142 in L: 139.7 in; R: 141.9 in Height to Top of ROPS 98.0 in (with R4 tires) Not Published Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model Not Published 99.2 in Overall Length 133.9 in (with 3-point hitch and R4 tires) 141.5 in (with 3-point hitch) ▶ WeightTractor Weight (Base) 4,158 lb 4,952 lb (weight with cab) Weight with ROPS and Loader 5,371 lb (4,158 + 1,213, computed; YL605 loader) Not Published Weight with Cab and Loader Not Published 6,252 lb (4,952 + 1,300, computed; L4058PC loader total weight) ▶ Tire OptionsTire Size & Options R1 Agricultural; R3 Turf; R4 Industrial R1 Agricultural, R4 Industrial, Golf tires R1 Agricultural - Front 210/95R16 (Radial) 9.5-20 R1 Agricultural - Rear 420/85R24 (Radial) 14.9-28 R3 Turf - Front 27.0 - 10.5 29x12.5-15 (golf tire) R3 Turf - Rear 44 x 18 - 20.0 44x18.00-20 (golf tire) R4 Industrial - Front 10.0 - 16.5 10.5/80-18 R4 Industrial - Rear 16.9 - 24.0 16.9-24 ▶ Loader & AttachmentsQuick Attach Loader System YL605: Skid steer quick attach L4058PC: Quick attach mechanism Loader Model YL605 L4058PC Loader Lift Height YL605: 113.0 in L4058PC: 117.5 in Loader Lift Capacity (Full Height) YL605: 2,500 lb (at pivot pin) L4058PC: 3,437 lb (at pivot pin) Loader Breakout Force YL605: 3,047 lb L4058PC: 4,742 lb (at pivot pin, ground level) ▶ WarrantyWarranty Length & Coverage Powertrain 10 years or 3,000 hours Basic 2 years or 2,000 hours; powertrain 3,000 hours maximum, parts and labor; loaders and backhoes 12 months
