▶ EngineEngine Manufacturer YANMAR Yanmar Engine Model 3TNV88C 4TNV88C-XKITL Engine Type 3-cylinder, naturally aspirated diesel 4-cylinder, liquid-cooled diesel No. of Cylinders 3 4 Displacement 100.1 in³ 133.6 in³ Rated Engine Speed 2800 rpm Not Published Engine Power (Gross) 34.2 hp 41.4 hp PTO Power 27 hp 31 hp Engine Emissions Constraints Tier 4 Not Published Cooling System Type Liquid cooled Liquid cooled Air Cleaner Dual stage cyclonic (resin 5.5 in.) Dual air cleaner element Fuel System Common rail direct injection Not Published Alternator 40 A, 12 V Not Published ▶ HydraulicsPump Type Not Published Not Published Implement Flow 7.1 gpm 9.3 gpm Steering Flow 4.1 gpm 5.3 gpm Total Hydraulic Flow 11.2 gpm (7.1 + 4.1, computed) 14.6 gpm Overall Hydraulic Pump Flow 11.2 gpm (7.1 + 4.1, computed) 14.6 gpm Hydraulic System Type Open center Not Published Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves Not Published 1 No. of Optional Remote Valves Not Published 2 ▶ Fluid CapacityFuel Tank Capacity 7.4 gal 13.2 gal Coolant Capacity 4.8 qt 6.3 qt Crankcase Capacity 4.6 qt 5.1 qt Transmission / Hydraulic System Capacity 8.2 gal 9.0 gal Front Axle Fluid Capacity 2.4 gal 2.4 gal ▶ PTO & HitchPTO Type Independent (electro-hydraulic) Independent PTO Rear 540 rpm 540/540E rpm Mid-PTO Availability Standard Not Published Category, 3-Point Hitch Category I Category I & II Hitch Lift Capacity 2,205 lb 3,190 lb Hitch Lift Capacity (at 24”) 1,764 lb 2,750 lb Lift Control Type Position control Not Published ▶ Transmission & DrivetrainTransmission Type Hydrostatic (Dual Touch Pedal) Synchronized shuttle shift No. of Speeds Unlimited (hydrostatic); 3 ranges F8-R8 Max Travel Speed (Forward) 11.7 mph (with R4 tires) 17.7 mph Max Travel Speed (Reverse) 8.2 mph (with R4 tires) Not Published Clutch N/A (hydrostatic) Dry Single Differential Lock & Limited Slip Options Rear differential lock (foot pedal engagement) Differential lock (foot pedal) ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Fully hydraulic power steering Power steering Brakes Wet disc Not Published Seat Suspension & Adjustability Not Published Suspension seat Front Axle Type 2WD/4WD selectable engagement Selectable 2WD/4WD engagement Front Axle Rating Not Published Not Published Drawbar Capacity Not Published Not Published ▶ Dimensions & ManeuverabilityOverall Length with 3-Point Hitch 116.9 in 133.6 in (with 3PH and R4 tires) Overall Width 58.3 in (with R4 tires) 70.9 in (with R4 tires) Wheelbase 65 in 74.8 in Ground Clearance 10.8 in (with R4 tires) 15.5 in Min. Turn Radius without Brakes Not Published 138 in Height to Top of ROPS 89.0 in (with R4 tires) 98.0 in (with R4 tires) Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model Not Published Not Published ▶ WeightTractor Weight (Base) 2,558 lb (with ROPS, R4 tires, full fluid) 3,916 lb Weight with ROPS and Loader 3,471 lb 5,129 lb Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options R1 Agricultural; R3 Turf; R4 Industrial R1 Agricultural; R3 Turf; R4 Industrial R1 Agricultural - Front 6-14 8.0 - 16.0 R1 Agricultural - Rear 9.5-22 14.9 - 24.0 R3 Turf - Front 25x8.5-14 27.0 - 10.5 R3 Turf - Rear 13.6x16 44 x 18 - 20.0 R4 Industrial - Front 25x8.5-14 10.0 - 16.5 R4 Industrial - Rear 15-19.6 17.5L - 24.0 ▶ Loader & AttachmentsQuick Attach Loader System YL310: Skid steer style bucket attachment YL605: Skid steer quick attach Loader Model YL310 YL605 Loader Lift Height YL310: 84 in (to bucket pivot pin) YL605: 113.0 in Loader Lift Capacity (Full Height) YL310: 1,300 lb at pivot pins YL605: 2,500 lb Loader Breakout Force YL310: 2,105 lb at pivot pins YL605: 3,047 lb (19.7 in forward of pivot pin) ▶ WarrantyWarranty Length & Coverage Tractor: 24 months or 2,000 hours; Powertrain: 10 years or 3,000 hours; Attachments: 1-year limited warranty 10-year limited powertrain warranty or 3,000 hours (whichever comes first)
