▶ EngineEngine Manufacturer YANMAR Yanmar Engine Model 3TNV88C 3TNV88C-KJPT Engine Type 3-cylinder, naturally aspirated diesel 4-cycle, inline, water-cooled diesel, naturally aspirated No. of Cylinders 3 3 Displacement 100.1 in³ 100.2 in³ Rated Engine Speed 2800 rpm 2800 rpm Engine Power (Gross) 34.2 hp 34.2 hp PTO Power 27 hp 30.4 hp Engine Emissions Constraints Tier 4 Tier 4 Cooling System Type Liquid cooled Liquid Air Cleaner Dual stage cyclonic (resin 5.5 in.) Dry Fuel System Common rail direct injection Direct injection Alternator 55 A 55 A, 12 V ▶ HydraulicsPump Type Not Published 2 single-section external gear pumps, 1 on each side of the engine timing-gear cover Implement Flow 7.1 gpm 5.9 gpm Steering Flow 4.1 gpm 4.4 gpm Total Hydraulic Flow 11.2 gpm (7.1 + 4.1, computed) 10.3 gpm Overall Hydraulic Pump Flow 11.2 gpm (7.1 + 4.1, computed) 10.3 gpm Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves Not Published None No. of Optional Remote Valves Not Published Up to two (optional) ▶ Fluid CapacityFuel Tank Capacity 7.4 gal 9.7 gal Coolant Capacity 5.3 qt 1.2 gal Crankcase Capacity 4.6 qt 1.1 gal Transmission / Hydraulic System Capacity 8.2 gal 9.2 gal Front Axle Fluid Capacity 2.4 gal 1.0 gal ▶ PTO & HitchPTO Type Independent (electro-hydraulic) Mechanical control; transmission clutch; wet disk brake (mid/rear PTO) PTO Rear 540 rpm 540 rpm at 2800 rpm engine (rated) Mid-PTO Availability Standard Not Published Category, 3-Point Hitch Category I Category I Hitch Lift Capacity 2,205 lb Not Published Hitch Lift Capacity (at 24”) 1,764 lb 1,670 lb Lift Control Type Position control Position control ▶ Transmission & DrivetrainTransmission Type Hydrostatic (Dual Touch Pedal) 8F/8R synchromesh shuttle shift gear transmission No. of Speeds Hydrostatic; 3 ranges 8F/8R Max Travel Speed (Forward) 11.7 mph (with R4 tires) Not Published Max Travel Speed (Reverse) 8.2 mph (with R4 tires) Not Published Clutch N/A (hydrostatic) Single dry traction clutch Differential Lock & Limited Slip Options Rear differential lock (foot pedal engagement) Differential lock: Yes ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Fully hydraulic power steering Power steering Brakes Wet disc Wet disk Seat Suspension & Adjustability Not Published Not Published Front Axle Type 2WD/4WD selectable engagement MFWD (4WD) Front Axle Rating Not Published 1,940 lb Drawbar Capacity Not Published 1,102 lb (static vertical load) ▶ Dimensions & ManeuverabilityOverall Width 58.3 in (with R4 tires) 57.3 in Wheelbase 65 in 62 in Ground Clearance 10.8 in (with R4 tires) 14 in Min. Turn Radius without Brakes Not Published 6.9 ft (with brake applied) Height to Top of ROPS Not Published Not Published Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model 83.6 in (with R4 tires) Not Published Overall Length 116.9 in (with 3-point hitch and R4 tires) 111.2 in ▶ WeightTractor Weight (Base) 2,910 lb (cab, R4 tires, full fluid) 2,800 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader 3,825 lb (2,910 + 617 + 298, computed; YL310 loader with bucket) Not Published ▶ Tire OptionsTire Size & Options R1 Agricultural; R3 Turf; R4 Industrial R1 Bar, R3 Turf, R4 Industrial R1 Agricultural - Front 6-14 7-14 R1 Agricultural - Rear 9.5-22 11.2-24 R3 Turf - Front 25x8.5-14 27X8.5-15 R3 Turf - Rear 13.6x16 41X14-20 R4 Industrial - Front 25x8.5-14 25X8.5-14 R4 Industrial - Rear 15-19.6 15-19.5 ▶ Loader & AttachmentsQuick Attach Loader System YL310: Skid steer style bucket attachment Quick-change attachment carrier Loader Model YL310 300E Loader Lift Height YL310: 84 in (to bucket pivot pin) 84 in (at pivot pin) Loader Lift Capacity (Full Height) YL310: 1,300 lb at pivot pins 1,186 lb (at pivot pin) Loader Breakout Force YL310: 2,105 lb at pivot pins 1,704 lbf (at pivot pin) ▶ WarrantyWarranty Length & Coverage Basic 24 months or 2,000 hours; powertrain 10 years or 3,000 hours; attachments 1 year Basic 2 years or 2,000 hours; powertrain 6 years or 2,000 hours
