▶ EngineEngine Manufacturer YANMAR KIOTI (Daedong) Engine Model 3TNV88C 3A165LXE Engine Type 3-cylinder, naturally aspirated diesel Not Published No. of Cylinders 3 3 Displacement 100.1 in³ 100.5 in³ Rated Engine Speed 2800 rpm 2600 rpm Engine Power (Gross) 34.2 hp 34 hp PTO Power 27 hp 28.3 hp Engine Emissions Constraints Tier 4 Not Published Cooling System Type Liquid cooled Not Published Air Cleaner Dual stage cyclonic (resin 5.5 in.) Dual stage air filter cartridge Fuel System Common rail direct injection Not Published Alternator 55 A Not Published ▶ HydraulicsPump Type Not Published Not Published Implement Flow 7.1 gpm 7.8 gpm Steering Flow 4.1 gpm 4.7 gpm Total Hydraulic Flow 11.2 gpm (7.1 + 4.1, computed) 12.5 gpm Overall Hydraulic Pump Flow 11.2 gpm (7.1 + 4.1, computed) 12.5 gpm Hydraulic System Type Open center Not Published Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves Not Published 1 No. of Optional Remote Valves Not Published 1 ▶ Fluid CapacityFuel Tank Capacity 7.4 gal 11.5 gal Coolant Capacity 5.3 qt Not Published Crankcase Capacity 4.6 qt Not Published Transmission / Hydraulic System Capacity 8.2 gal Not Published Front Axle Fluid Capacity 2.4 gal Not Published ▶ PTO & HitchPTO Type Independent (electro-hydraulic) Hydraulic independent PTO Rear 540 rpm 540 rpm Mid-PTO Availability Standard Optional (2,000 rpm) Category, 3-Point Hitch Category I Category I Hitch Lift Capacity 2,205 lb 2,270 lb Hitch Lift Capacity (at 24”) 1,764 lb Not Published Lift Control Type Position control Position, Draft and Mixed control ▶ Transmission & DrivetrainTransmission Type Hydrostatic (Dual Touch Pedal) Synchronized shuttle No. of Speeds Hydrostatic; 3 ranges 8F/8R (16F/16R with optional creeper gear) Max Travel Speed (Forward) 11.7 mph (with R4 tires) 13.93 mph Max Travel Speed (Reverse) 8.2 mph (with R4 tires) Not Published Clutch N/A (hydrostatic) Dry single plate Differential Lock & Limited Slip Options Rear differential lock (foot pedal engagement) Rear differential lock (mechanical) ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Fully hydraulic power steering Hydraulic power steering Brakes Wet disc Wet disc Seat Suspension & Adjustability Not Published Adjustable seat Front Axle Type 2WD/4WD selectable engagement 4WD (MFWD) Front Axle Rating Not Published Not Published Drawbar Capacity Not Published Not Published ▶ Dimensions & ManeuverabilityOverall Width 58.3 in (with R4 tires) 57.1 in Wheelbase 65 in 65.7 in Ground Clearance 10.8 in (with R4 tires) 11.4 in Min. Turn Radius without Brakes Not Published 125.9 in Height to Top of ROPS Not Published 92.5 in Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model 83.6 in (with R4 tires) Not Published Overall Length 116.9 in (with 3-point hitch and R4 tires) 126.3 in (with 3-point hitch) ▶ WeightTractor Weight (Base) 2,910 lb (cab, R4 tires, full fluid) 3,475 lb (with ag tires) Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader 3,825 lb (2,910 + 617 + 298, computed; YL310 loader with bucket) Not Published ▶ Tire OptionsTire Size & Options R1 Agricultural; R3 Turf; R4 Industrial R1 Agricultural, R3 Turf, R4 Industrial R1 Agricultural - Front 6-14 7-16 R1 Agricultural - Rear 9.5-22 12.4-24 R3 Turf - Front 25x8.5-14 27x8.5-15 R3 Turf - Rear 13.6x16 41x14-20 R4 Industrial - Front 25x8.5-14 27x10.5-15 R4 Industrial - Rear 15-19.6 43x16-20 ▶ Loader & AttachmentsQuick Attach Loader System YL310: Skid steer style bucket attachment Not Published Loader Model YL310 KL1450 Loader Lift Height YL310: 84 in (to bucket pivot pin) KL1450: 103.5 in Loader Lift Capacity (Full Height) YL310: 1,300 lb at pivot pins KL1450: 1,350 lb (at pivot pin) Loader Breakout Force YL310: 2,105 lb at pivot pins KL1450: 2,100 lb (at pivot pin) ▶ WarrantyWarranty Length & Coverage Basic 24 months or 2,000 hours; powertrain 10 years or 3,000 hours; attachments 1 year Not Published ▶ ITC Company AccessoriesAccessories that fit None tagged yet
