▶ EngineEngine Manufacturer YANMAR LS Mtron Engine Model 4TNV88C L3C19-T Engine Type 4-cylinder, naturally aspirated diesel Diesel, 3-cylinder, turbocharged No. of Cylinders 4 3 Displacement 133.5 in³ 116 in³ Rated Engine Speed 2800 rpm 2600 rpm Engine Power (Gross) 46 hp 45 hp PTO Power 39.5 hp 36 hp Engine Emissions Constraints Tier 4 Tier 4 Cooling System Type Liquid cooled Liquid-cooled Air Cleaner Dual stage cyclonic (resin 5.5") Replaceable dry element Fuel System Common rail direct injection Common rail direct injection Alternator 55 A, 12 V 70 A ▶ HydraulicsPump Type Not Published Not Published Implement Flow 10.1 gpm 8.2 gpm Steering Flow 5.7 gpm 5.3 gpm Total Hydraulic Flow 15.8 gpm (10.1 + 5.7, computed) 13.5 gpm (8.2 + 5.3, computed) Overall Hydraulic Pump Flow 15.8 gpm (10.1 + 5.7, computed) Not Published Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves 2 1 No. of Optional Remote Valves 1 2 ▶ Fluid CapacityFuel Tank Capacity 12.7 gal 10.5 gal Coolant Capacity 6.2 qt Not Published Crankcase Capacity 7.0 qt Not Published Transmission / Hydraulic System Capacity 7.7 gal Not Published Front Axle Fluid Capacity 2.4 gal Not Published ▶ PTO & HitchPTO Type Independent (electro-hydraulic) Independent rear PTO, electro-hydraulic engagement PTO Rear 540 rpm 540 rpm Mid-PTO Availability Not Published Optional, 2000 rpm Category, 3-Point Hitch Category I Category I Hitch Lift Capacity 3,307 lb 2,756 lb Hitch Lift Capacity (at 24”) 2,756 lb 2,469 lb Lift Control Type Position control Mechanical draft control (MDC) ▶ Transmission & DrivetrainTransmission Type I-HMT (Integrated Hydro Mechanical Transmission) 3-range hydrostatic (HST) No. of Speeds 3 ranges (variable speed) infinitely variable, 3 ranges Max Travel Speed (Forward) 18 mph (with R1 tires) 17.9 mph Max Travel Speed (Reverse) 18 mph (with R1 tires) Not Published Clutch Clutch-less shifting (i-HMT) Not Applicable Differential Lock & Limited Slip Options Rear differential lock (foot pedal engagement) Mechanical rear differential lock ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Fully hydraulic power steering Power steering Brakes Mechanical wet disc Wet multi-disc Seat Suspension & Adjustability Not Published Adjustable suspension seat Front Axle Type 2WD/4WD selectable engagement Mechanical Front Drive (MFD) Front Axle Rating Not Published Not Published Drawbar Capacity Not Published Not Published ▶ Dimensions & ManeuverabilityOverall Length with 3-Point Hitch 130.9 in 128.1 in Overall Width 70.6 in (with R4 tires) 69.1 in Wheelbase 75.9 in 73.2 in Ground Clearance 12.8 in (with R4 tires) Not Published Min. Turn Radius without Brakes Not Published Not Published Height to Top of ROPS 95.7 in (with R4 tires) 97.1 in Height to Top of ROPS (folded) Not Published 78.6 in Height to Top of Cab Model Not Published 93.3 in ▶ WeightTractor Weight (Base) 3,880 lb (with ROPS, R4 tires, full fluid) 3,770 lb Weight with ROPS and Loader 4,976 lb Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options R1 Agricultural; R3 Turf; R4 Industrial R1 Agricultural; R3 Turf; R4 Industrial R1 Agricultural - Front 8-16 9.5-16 R1 Agricultural - Rear 14.9-24 13.6-24 R3 Turf - Front 27x10.5-15 28x8.50-15 R3 Turf - Rear 44x18-20 41x14.00-20 R4 Industrial - Front 10-16.5 12-16.5 R4 Industrial - Rear 17.5L-24 17.5L-24 ▶ Loader & AttachmentsQuick Attach Loader System YL610: Skid-steer-style loader quick attachment system Quick-Attach faceplate; quick-connect loader mounting (L360A) Loader Model YL610 L360A Loader Lift Height YL610: 113 in (to bucket pivot pin) 112 in Loader Lift Capacity (Full Height) YL610: 2,500 lb at pivot pins 2,500 lb Loader Breakout Force YL610: 3,969 lb at pivot pins 3,114 lbf ▶ WarrantyWarranty Length & Coverage Tractor: 24 months or 2,000 hours; Powertrain: 10 years or 3,000 hours; Attachments: 1-year limited warranty 6-year (72-month) extended warranty: 2-year bumper-to-bumper plus 4 additional years powertrain
