▶ EngineEngine Manufacturer YANMAR Mahindra Engine Model 4TNV88C DH45 Engine Type 4-cylinder, naturally aspirated diesel Four-stroke, naturally aspirated, direct injection, water-cooled diesel No. of Cylinders 4 4 Displacement 133.5 in³ 166.2 in³ Rated Engine Speed 2800 rpm 2300 rpm Engine Power (Gross) 46 hp 45 hp PTO Power 39 hp 38 hp Engine Emissions Constraints Tier 4 Tier 4 Cooling System Type Liquid cooled Water-cooled Air Cleaner Dual stage cyclonic (resin 5.5") Not Published Fuel System Common rail direct injection Direct injection Alternator 55 A, 12 V 55 A ▶ HydraulicsPump Type Not Published Not Published Implement Flow 10.1 gpm 8.71 gpm Steering Flow 5.7 gpm 4.62 gpm Total Hydraulic Flow 15.8 gpm (10.1 + 5.7, computed) 13.3 gpm Overall Hydraulic Pump Flow 15.8 gpm (10.1 + 5.7, computed) 13.3 gpm Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves 2 One No. of Optional Remote Valves 1 One (optional second rear valve) ▶ Fluid CapacityFuel Tank Capacity 12.7 gal 17.1 gal Coolant Capacity 6.2 qt Not Published Crankcase Capacity 7.0 qt Not Published Transmission / Hydraulic System Capacity 7.7 gal Not Published Front Axle Fluid Capacity 2.4 gal Not Published ▶ PTO & HitchPTO Type Independent (electro-hydraulic) Independent PTO Rear 540 rpm 540 rpm @ 2300 engine rpm; 540E rpm @ 1725 engine rpm Mid-PTO Availability Not Published Not Published Category, 3-Point Hitch Category I CAT I & II with telescopic stabilizers & flex links Hitch Lift Capacity 3,307 lb Not Published Hitch Lift Capacity (at 24”) 2,756 lb 3,748 lb Lift Control Type Position control Position control ▶ Transmission & DrivetrainTransmission Type I-HMT (Integrated Hydro Mechanical Transmission) Full synchromesh with forward/reverse synchro shuttle and constant-mesh range No. of Speeds 3 ranges (variable speed) 12F / 12R Max Travel Speed (Forward) 18 mph (with R1 tires) 17.9 mph Max Travel Speed (Reverse) 18 mph (with R1 tires) Not Published Clutch Clutch-less shifting (i-HMT) Dual dry with cerametallic lining Differential Lock & Limited Slip Options Rear differential lock (foot pedal engagement) Not Published ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Fully hydraulic power steering Power steering with tilt steering wheel Brakes Mechanical wet disc Fully-enclosed, 7-in diameter, dry disc Seat Suspension & Adjustability Not Published Adjustable seat with contoured cushions, armrests and a soft-coil suspension Front Axle Type 2WD/4WD selectable engagement Not Published Front Axle Rating Not Published Not Published Drawbar Capacity Not Published Not Published ▶ Dimensions & ManeuverabilityOverall Width 70.6 in (with R4 tires) 74.8 in Wheelbase 75.9 in 77.9 in Ground Clearance 12.8 in (with R4 tires) 15.2 in Min. Turn Radius without Brakes Not Published 10.8 ft (3.29 m) Height to Top of ROPS Not Published Not Published Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model 89.5 in (with R4 tires) Not Published Overall Length 130.9 in (with 3-point hitch and R4 tires) 136.6 in ▶ WeightTractor Weight (Base) 4,284 lb (cab, R4 tires, full fluid) 5,390 lb Weight with ROPS and Loader Not Published 6,690 lb Weight with Cab and Loader 5,380 lb (4,284 + 1,096, computed) Not Published ▶ Tire OptionsTire Size & Options R1 Agricultural; R3 Turf; R4 Industrial R1 Agricultural or R4 Industrial R1 Agricultural - Front 8-16 9.5 x 20 R1 Agricultural - Rear 14.9-24 14.9 x 28 R3 Turf - Front 27x10.5-15 Not Published R3 Turf - Rear 44x18-20 Not Published R4 Industrial - Front 10-16.5 10.5/80 x 18 R4 Industrial - Rear 17.5L-24 16.9 x 24 ▶ Loader & AttachmentsQuick Attach Loader System YL610: Skid-steer-style loader quick attachment system Skid-steer style quick-attach coupler Loader Model YL610 5155-4L (front loader); 65B (rear backhoe) Loader Lift Height YL610: 113 in (to bucket pivot pin) 122 in Loader Lift Capacity (Full Height) YL610: 2,500 lb at pivot pins 3,100 lb Loader Breakout Force YL610: 3,969 lb at pivot pins 5,200 lb ▶ WarrantyWarranty Length & Coverage Basic 24 months or 2,000 hours; powertrain 10 years or 3,000 hours; attachments 1 year 5-year limited powertrain warranty
