▶ EngineEngine Manufacturer YANMAR LS Mtron Engine Model 4TNV88C L3CRV-T9A Engine Type 4-cylinder, naturally aspirated diesel 3-cylinder, turbocharged, liquid-cooled diesel No. of Cylinders 4 3 Displacement 133.5 in³ 114.7 in³ Rated Engine Speed 2800 rpm 2600 rpm Engine Power (Gross) 46 hp 45 hp PTO Power 39 hp Gear: 38.2 hp; HST: 36 hp Engine Emissions Constraints Tier 4 Tier 4B (final) Cooling System Type Liquid cooled Liquid cooled Air Cleaner Dual stage cyclonic (resin 5.5") Replaceable primary and inner elements Fuel System Common rail direct injection Electronically controlled common rail direct injection Alternator 55 A, 12 V ROPS: 70 A, 12 V; Cab: 85 A, 12 V ▶ HydraulicsPump Type Not Published Gear Implement Flow 10.1 gpm 8.2 gpm Steering Flow 5.7 gpm Gear: 4.2 gpm; HST: 5.3 gpm Total Hydraulic Flow 15.8 gpm (10.1 + 5.7, computed) Gear: 12.4 gpm; HST: 13.5 gpm Overall Hydraulic Pump Flow 15.8 gpm (10.1 + 5.7, computed) Gear: 12.4 gpm; HST: 13.5 gpm Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves 2 1 No. of Optional Remote Valves 1 Up to 2 (second valve optional) ▶ Fluid CapacityFuel Tank Capacity 12.7 gal ROPS: 10.5 gal; Cab: 12.4 gal Coolant Capacity 6.2 qt 2.3 gal Crankcase Capacity 7.0 qt 5.8 qt Transmission / Hydraulic System Capacity 7.7 gal 11.4 gal Front Axle Fluid Capacity 2.4 gal 2.2 gal ▶ PTO & HitchPTO Type Independent (electro-hydraulic) Independent, electro-hydraulic engagement PTO Rear 540 rpm 540 rpm Mid-PTO Availability Not Published Standard (2000 rpm) Category, 3-Point Hitch Category I Category I Hitch Lift Capacity 3,307 lb 2,756 lb Hitch Lift Capacity (at 24”) 2,756 lb 2,116 lb Lift Control Type Position control Position control (draft control optional) ▶ Transmission & DrivetrainTransmission Type I-HMT (Integrated Hydro Mechanical Transmission) Gear: 16x16 synchronized shuttle shift (SSS); HST: 3-range hydrostatic, dual pedal No. of Speeds 3 ranges (variable speed) Gear: 16F/16R; HST: 3-range Max Travel Speed (Forward) 18 mph (with R1 tires) Gear: 17.0 mph; HST: 17.9 mph Max Travel Speed (Reverse) 18 mph (with R1 tires) Gear: 15.3 mph; HST: 11.37 mph Clutch Clutch-less shifting (i-HMT) Gear: dry single disc (10.8 in); HST: n/a Differential Lock & Limited Slip Options Rear differential lock (foot pedal engagement) Mechanical rear differential lock (pedal) ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Fully hydraulic power steering Power steering Brakes Mechanical wet disc Wet multi-disc Seat Suspension & Adjustability Not Published ROPS: adjustable suspension seat (fore/aft, weight and height adjustment); Cab: cloth suspension seat with weight control, fore/aft adjustment and adjustable armrests Front Axle Type 2WD/4WD selectable engagement Four-wheel drive (FWD) Front Axle Rating Not Published Not Published Drawbar Capacity Not Published Short position: 2,317 lb; Regular position: 1,598 lb; Extended position: 1,091 lb ▶ Dimensions & ManeuverabilityOverall Width 70.6 in (with R4 tires) 69.1 in Wheelbase 75.9 in 73.2 in Ground Clearance 12.8 in (with R4 tires) 15 in Min. Turn Radius without Brakes Not Published 111.8 in (right turn); 123.2 in (left turn) (with brake applied) Height to Top of ROPS Not Published 97.1 in Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model 89.5 in (with R4 tires) 94 in Overall Length 130.9 in (with 3-point hitch and R4 tires) 128.1 in ▶ WeightTractor Weight (Base) 4,284 lb (cab, R4 tires, full fluid) ROPS Gear: 3,424 lb; ROPS HST: 3,490 lb; Cab: 4,194 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader 5,380 lb (4,284 + 1,096, computed) Not Published ▶ Tire OptionsTire Size & Options R1 Agricultural; R3 Turf; R4 Industrial R1 Agricultural, R3 Turf, R4 Industrial R1 Agricultural - Front 8-16 9.5-16 R1 Agricultural - Rear 14.9-24 13.6-24 R3 Turf - Front 27x10.5-15 28x8.50-15 R3 Turf - Rear 44x18-20 41x14.00-20 R4 Industrial - Front 10-16.5 12x16.5 R4 Industrial - Rear 17.5L-24 17.5Lx24 ▶ Loader & AttachmentsQuick Attach Loader System YL610: Skid-steer-style loader quick attachment system Tool-free loader mount; optional skid-steer quick-attach plates Loader Model YL610 260TLA Loader Lift Height YL610: 113 in (to bucket pivot pin) 260TLA: 109 in (at pivot pin) Loader Lift Capacity (Full Height) YL610: 2,500 lb at pivot pins 260TLA: 2,371 lb (at bucket pivot pin, max height) Loader Breakout Force YL610: 3,969 lb at pivot pins 260TLA: 4,081 lb (at bucket pivot pin) ▶ WarrantyWarranty Length & Coverage Basic 24 months or 2,000 hours; powertrain 10 years or 3,000 hours; attachments 1 year Basic 2 years or 750 hours; powertrain 4 more years (6 years or 1,500 hours total)
