Pick up to 4tractors and we'll lay every spec sheet out side by side. Same data we publish on the individual model pages, stacked in columns so you can compare numbers at a glance.
No photo
—
YanmarYT347C
No photo
—
TYMT454
Comparison loaded for 2 tractors.
Spec
YanmarYT347C
TYMT454
PTO Power
39.5 hp (29.1 kW)
37.3 hp (27.4 kW)
Alternator
12 V, 55 A
12 V, 70 A
Air Cleaner
Dual stage cyclonic (resin 5.5")
Dual dry
Engine Type
4-cylinder, naturally aspirated diesel
4-cylinder, naturally aspirated diesel
Fuel System
Common rail direct injection
CRDI
Displacement
133.5 in³ (2,189 cc)
133.6 in³ (2,189 cc)
No. of Cylinders
4
4
Rated Engine Speed
2,800 rpm
2,800 rpm
Cooling System Type
Liquid cooled
Not Published
Engine Manufacturer
YANMAR
Yanmar
Engine Emissions Constraints
Tier 4
Not Published
Engine Power (Gross vs. Net HP)
Gross: 46 hp (34.3 kW)
Gross: 46.6 hp (34.3 kW)
Tractor Weight with Loader
5,380 lb (2,440 kg)
Not Published
Weight with Cab and Loader
5,380 lb (2,440 kg)
Not Applicable
Weight with ROPS and Loader
Not Applicable
Not Published
Pump Type
Not Published
Dual gear pump
Steering Flow
21.7 L/min (5.7 gpm)
17.3 L/min (4.6 gpm)
Implement Flow
38.3 L/min (10.1 gpm)
35.7 L/min (9.5 gpm)
Total Hydraulic Flow
60.0 L/min (15.8 gpm)
53.0 L/min (14.1 gpm)
Hydraulic System Type
Open center
Open center
Rear Remote Hydraulic Flow
Not Published
Not Published
Overall Hydraulic Pump Flow
60.0 L/min (15.8 gpm)
53.0 L/min (14.1 gpm)
No. of Optional Remote Valves
1
Not Published
No. of Standard Remote Valves
2
2
R3 Turf - Rear
44 x 18 - 20.0
Multi-Trac CS 44x18.00-20 NHS TL 4PR
R3 Turf - Front
27.0 - 10.5
Multi-Trac CS 27x10.50-15 NHS TL 4PR
Tire Size & Options
R1 Agricultural; R3 Turf; R4 Industrial
R1 Agricultural, R3 Turf, R4 Industrial
R4 Industrial - Rear
17.5L - 24.0
Xtra Grip 17.5-24 NHS TL 6PR
R4 Industrial - Front
10.0 - 16.5
Trac Chief 12-16.5 NHS TL 6PR
R1 Agricultural - Rear
14.9 - 24.0
Farm Specialist 13.6-26 NHS TL 6PR
R1 Agricultural - Front
8.0 - 16.0
Farm Specialist 9.5-16 NHS TL 6PR
PTO Rear
540 rpm
540 rpm
PTO Type
Independent (electro-hydraulic)
Independent
Lift Control Type
Position control
Position/Draft
Hitch Lift Capacity
3,307 lb (1,500 kg)
3,314 lb (1,503 kg)
Mid-PTO Availability
Not Published
Not Published
Category, 3-Point Hitch
Category I
Category I
Hitch Lift Capacity (at 24”)
2,756 lb (1,250 kg)
2,945 lb (1,336 kg)
Rear 3-Point Hitch Lift Capacity
3,307 lb (1,500 kg)
3,314 lb (1,503 kg)
Coolant Capacity
6.2 qt (5.9 L)
9 qt (8.5 L)
Crankcase Capacity
7.0 qt (6.6 L)
7.4 qt (6.7 L)
Fuel Tank Capacity
12.7 gal (48 L)
17.0 gal (60 L)
Front Axle Fluid Capacity
2.4 gal (9 L)
10.5 qt (9.9 L)
Transmission / Hydraulic System Capacity
7.7 gal (29 L)
9.2 gal (34.8 L)
Loader Lift Height
113 in (2,870 mm)
Not Published
Loader Breakout Force
3,969 lb (1,800 kg)
Not Published
Price for Backhoe Option
B90: $17,560
BY85
Price for Mid-Mount Mower
Not Published
Not Published
Quick Attach Loader System
YL610: Skid-steer-style loader quick attachment system
TX55: Quick attachment assembly
Loader Lift Capacity (Full Height)
2,500 lb (1,134 kg)
Not Published
Clutch
Clutch-less shifting (i-HMT)
Dry single plate
No. of Speeds
3 ranges (variable speed)
F16 x R16
Transmission Type
I-HMT (Integrated Hydro Mechanical Transmission)
Synchro-shuttle
Max Travel Speed (Forward)
18 mph (29 km/h)
18.4 mph (29.7 km/h)
Max Travel Speed (Reverse)
18 mph (29 km/h)
Not Published
Differential Lock & Limited Slip Options
Rear differential lock (foot pedal engagement)
Not Published
Brakes
Mechanical wet disc
Wet disc
Steering
Fully hydraulic power steering
Hydrostatic
Frame Type
Not Published
Not Published
Front Axle Type
Selectable 2WD/4WD engagement
Not Published
Drawbar Capacity
Not Published
Not Published
Front Axle Rating
Not Published
Not Published
Seat Suspension & Adjustability
Not Published
Not Published
Wheelbase
75.9 in (1,927 mm)
76.2 in (1,935 mm)
Overall Width
70.6 in (1,793 mm)
63.8 in (1,620 mm)
Ground Clearance
12.8 in (326 mm)
13.8 in (350 mm)
Height to Top of ROPS
Not Applicable
102.1 in (2,594 mm)
Height to Top of Cab Model
89.5 in (2,274 mm)
Not Applicable
Height to Top of ROPS (folded)
Not Published
Not Published
Min. Turn Radius without Brakes
Not Published
150.4 in (3,820 mm)
Overall Length with 3-Point Hitch
130.9 in (3,325 mm)
141.3 in (3,590 mm)
Financing Options
See Exclusive Offers (promotions vary)
0% financing for up to 72 months and instant cash rebates. Contact dealer for more information.
Base Price with Loader
Not Applicable
Not Published
Warranty Length & Coverage
Tractor: 24 months or 2,000 hours; Powertrain: 10 years or 3,000 hours; Attachments: 1-year limited warranty
Up to 2 years or until the 2,000 hours mark, bumper-to-bumper warranty; 3000 hours maximum coverage period for parts and labour on drivetrains or powertrains; 12-months warranty period for implements, including loaders and backhoes.
